United Technologies Interlogix TruVision NVR 10 Connecting Manual

External switch poe ports

Connecting an external

switch to the TVN 10 PoE

ports

P/N 1072867A • REV 01 • ISS 28AUG14

Introduction

Some configurations may require connecting an external switch to the PoE ports

of the TruVision NVR 10 (TNV 10). This technical note describes how to add an

external switch to the PoE ports of a TNV 10.

These steps must be followed in order to successfully add the cameras to the

TVN 10.

•

Start with the TVN 10 powered up and connected to the LAN.

•

Do not connect anything to the PoE ports at this time.

•

Do not connect the external switch to the TVN 10 until the last step.

1. Plug in all cameras that will be directly connected to the TVN 10 PoE ports.

2. Manually add any cameras connected to the LAN that will be connected to the

TVN 10.

3. Power up the external PoE switch and connect the IP cameras and a PC with

TruVision Device Finder installed.

DO NOT connect the external switch to the TVN 10 at this time.

4. Using a PC with TruVision Device Finder installed, set the IP address of the

cameras on the external switch into the IP address range of the TVN 10 PoE

switch. By default this range is 192.168.254.x.

5. Manually add the cameras that are on the external switch to the TVN 10 using

the Camera Management page.

1 / 2

Table of Contents

Do you have a question about the Interlogix TruVision NVR 10 and is the answer not in the manual?

Page 1 5. Manually add the cameras that are on the external switch to the TVN 10 using the Camera Management page. © 2014 United Technologies Corporation. Interlogix is part of UTC Building & Industrial Systems, a unit of United Technologies Corporation. All rights reserved.
Page 2 6. Manually add a dummy address for any unused channels. Do not leave any open channels on the TVN 10. Caution: Failure to do this will cause all the TruVision cameras on the external switch to be readdressed to a single IP address by the TVN 10. 7.
