Festool DURADRIVE DWC 18-2500 Original Operating Manual page 17

► To activate the tool, press on the screw with
the drill bit.
It is not necessary to press the switch [1-2].
The top speed is set automatically.
c)
► Set the tool's rotational direction to anti­
clockwise using the right/left switch [1-3].
► Switch the tool on using the switch [1-2].
The MAN/AUTO selector switch [1-4] is in
either position.
By pressing on the switch [1-2], the speed can
be infinitely adjusted.
The drywall screwdriver rotates anti­
clockwise
switch [1-2] only, without also having
to press on the bit.
To unscrew screws fully, the depth
stop does therefore not need to be re­
moved.
9.2 Depth stop
Turning on the depth stop [1-5] sets the screw­
ing depth, as shown in figure [4]. The setting is
accurate to approx. ± 0.1 mm.
Anticlockwise rota­
tion
Clockwise rotation
Once the depth setting is made, drive in a test
screw then, if necessary, correct the depth.
Attaching the depth stop
► Place the depth stop [3-1] on the transmis­
sion housing [3-5].
► Then, apply pressure until the depth stop
audibly clicks into place.
Removing the depth stop
► Take the depth stop out of the transmission
housing by pulling firmly.
9.3 Frame hook and belt clip
The belt clip [5-1] can be used to attach the tool
to working clothes temporarily – it can be af­
fixed to the left or right-hand side of the tool
using a screw [5-2], making it suitable for
right-handed and left-handed operators – see
figure [5].
The tool also has a hook [6-1], by which the tool
can be hung, as required. It can be affixed to the
left or right-hand side of the housing using the
screw [6-2] – see figure [6].
by pressing on
Screw is countersunk
further out.
Screw is countersunk
further in.
9.4 Magazine attachment
The magazine attachment enables the operator
to work continuously without unnecessary pau­
ses.
Fitting the magazine attachment
► Remove the depth stop [3-1] on the bit
holder [3-2] using the bit, as described in
section 8
► Move the selector switch [1-4] to the MAN
position.
► Push the long bit [7-1] into the tool hold­
er [3-4] until it clicks into place.
► Then affix the magazine attachment to the
transmission housing. The magazine at­
the
tachment must audibly click into place.
► The magazine attachment can be positioned
at 30° increments.
Removing the magazine attachment
► Take the magazine attachment out of the
transmission housing by pulling firmly.
Adjusting the screw length
► Pressing on the button [8-1] slides the
depth stop [8-2] in or out, so that it can be
adjusted to the required screw length.
The screw length setting is visible on the sides
of the depth stop [8-3].
Inserting collated screws
► Firstly, draw the belt of collated
screws [9-3] through the lower magazine
guide and then thread them into the car­
riage guide until a screw clicks into the
working position.
Make sure that the screws are correctly
positioned and secure by pulling gently on
the belt of collated screws.
Check that the first screw is lined up in the
screwing axis – see figure [9].
► Use the adjusting wheel [9-1] to set the re­
quired insertion depth.
► Clockwise rotation will countersink the
screws further in, while anticlockwise rota­
tion will countersink the screws further out.
The current setting can be read off the pre­
setting display [9-2]
Once the setting is made, drive in a test screw,
then, if necessary, correct the depth setting us­
ing the adjusting wheel [9-1]. Each setting ad­
justment shifts the stop by ± 0.1 mm.
We recommend screwdriving in the
automatic mode – see section
.
English
9.1 b).
17
