3. You can connect a 3-Pin Internal USB Cable to the USB Connectors on the PC's
Motherboard. (Allowed for DC Output Voltage only)
VCC
(white)
DM (D-)
(green)
DP (D+)
5
(black)
GND
Connects to the USB Connectors on
the PC's motherboard
Note: It is required to install the USB driver. For details, see Installing USB Driver later in the
Installation Guide.
Switching Modes
The GV-NET/IO Card provides two modes for users to expand its capability: I/O Box Mode
and NET/IO Card Mode. With a mode-switch jumper to insert on the 2-pin header, you can
switch between modes.
•
NET/IO Card Mode (default): With the switch jumper inserted, this default mode acts as
a GV-NET/IO Card. It is required to connect the GV-NET/IO Card to the GV-Video
Capture Card for usage.
•
I/O Box Mode: Without the switch jumper inserted, the GV-NET/IO Card can work as an
independent device. It is NOT necessary to connect to the GV-Video Capture Card for
usage.
Chaining together with
GV-NET/IO Card V3.1
or later / GV-IO USB
Box
3-pin Internal
RS-485+
DM
(white)
USB Cable
DP
(green)
RS-485-
GND
(black)
GV Video Capture Card
O
O
N
N
O
1
1
1
2
N
6
Without
2-pin header
