Croydex Norton WC010322 Instruction Leaflet

Norton Column Storage Unit
storage
This installation guide applies to the following vanity unit:
WC010322 - Norton Column Storage Unit
Tools required - not supplied
Pencil;Tape Measure; Philips Screwdriver; Mallet; Drill; 8mm Drill Bit (Ceramic drill bit optional).
KEEP DIY TOOLS OUT OF THE REACH OF CHILDREN
Home Safety Advice
.
- Always take care when using power tools, particularly in the bathroom.
- Always check for hidden cables and pipework before drilling and take extreme care if there is any
water in the working area.
- It is advisable to use a residual current circuit breaker (RCCB).
- Always wear suitable eye protection when drilling.
- Always ensure that the drill hole passes through the central tiled area rather than through the grouted
area. To prevent damage to the tile, mask the area around the hole with tape before drilling.
- Do not strike the product with hard or sharp objects.
Product Care
Do not use abrasive or chemical cleaners as these will damage the product.
Product Location
The addition of backboards on the outside of the wall or appropriate strengthening of internal structures may be
required to provide adequate wall strength.
NOTE: If the wall is made of lightweight thermal blocks, aerated hollow brickwork or prefabricated partitions
the storage unit.
Vanity Unit Components Vanity Unit Fixing Components
A. Mounting Plate Screws B. Mounting Plates
(H004) x 8 (H005) x 2
D. Wall Screws (H008) x 2
C. Wall Plugs (H007) x 2
E. Vanity Unit Feet F. Vanity Unit Feet Screws
A. Side Panels (P001) x 2 B. Centre Panels (P002) x 4
x 16
(H006) x 4
1
