Page 1
Item # 760274 Model # HS1060.2A ASSEMBLY INSTRUCTIONS Bench Questions, problems, missing parts? Before returning to the store, call Customer Service 8 a.m. – 6 p.m., EST, Monday - Friday 1-877-527-0313 WWW.HOMEDEPOT.COM THANK YOU We appreciate the trust and confidence you have placed through the products of this bench. We strive to continually create quality products designed to enhance your home.
Page 2
Table of Contents Table of Contents……………………………….………2 Hardware Included…………………………………..3 Safety Information…………………...…………………2 Package Contents……………………………………4 Warranty………………………………………………….2 Assembly…………………………………………………5 Pre-Assembly……………………………………………3 Weight Limits…………………………………………….8 Tools Required…………………………….…………3 Planning Assembly………………………………….3 Safety Information Please read and understand these instructions WARNING: Anchor the bench to the wall after before assembling and using this bookcase. Save assembly to prevent accidental tipping and injury.
Page 3
Pre-Assembly PLANNING ASSEMBLY Compare all parts with the Hardware Included and Package Contents list. If any part appears missing or damaged, do not assemble this product and contact the Customer Service Team at 1-877-527-0313 or visit www.homedepot.com. TOOLS REQUIRED Phillips screwdriver (not provided) HARDWARE INCLUDED...
Page 4
Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity Top panel Bottom panel Side panel Side vertical Partition Foot Support foot Back panel...
Page 5
Assembly Preparing the top panel and bottom panel Securely screw cam bolts (J) into the designated small holes on the bottom panel (B). Follow the same step to assemble the top panel (A). Preparing the side panel, partition and side vertical ...
Page 6
Assembly (continued) Installing the feet and the side vertical Screw four feet (F) and supporting foot (G) into the bottom of the bottom panel (B). Fasten the side vertical (D) to the side panel (C) with two cam locks (K). ...
Page 7
Assembly (continued) Attaching the top panel Position the top panel (A) onto the side panel (C) and partition (E), and fasten it in place with eight cam locks (K). Attaching the back panel Pick up the back panel (H) and align the drilled holes against the upper long edge with the pilot holes ...
Page 8
Assembly (continued) WEIGHT LIMITS This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. WARNING: Please ensure that all the objects are removed before moving the assembled unit. The unit must be lifted by more than one person, not dragged or pushed.
