SOMMAIRE FRANCAIS ............................3 2. COFFRET ELECTRONIQUE ............................. 4 2.1. Interface ................................4 2.2. Mise en .......................... 4 2.3..........................4 2.4. Réglage de la consigne de production ......................... 4 2.5. nversion (en option) ....................4 2.6. Mode Boost (en option)............................5 2.7.
Page 3
1. SCHEMA -ci. 1 : Cellule 2 : Coffret électronique ELEMENTS NON FOURNIS : 3 : Alimentation électrique 4 : Filtre 5 : Pompe à chaleur 6 : Pompe de filtration...
2. COFFRET ELECTRONIQUE 2.1. Interface Visuel non contractuel 2 : Voyant de production 3 : Ecran Si affichage clignotant : information en attente de validation. Si affichage figé : information validée. Affichage par défaut : consigne de production. 4 : Touches de commande 2.2.
2.6. Mode Boost (en option) Le mode Boost règle la consigne de production à son maximum durant 24 heures, arrêtable à tout moment. Cette fonction permet de répondre à un besoin de chlore. baignade. Pour lancer le mode Boost : 1) La consigne de production ne doit pas être à...
2.8. Alarmes 2.8.1. Descriptif général Toute alarme qui se déclenche : - Toute alarme qui se déclenche : - stoppe Toute alarme qui se déclenche : appui long sur la touche du bas. Message Défaut Cause Vérifications et remèdes affiché détecté...
3. GARANTIE Avant tout contact avec votre revendeur, merci de bien vouloir vous munir : - du n° de série du coffret électronique. - de la date d'installation de l'équipement. - des paramètres de votre piscine (salinité, pH, taux de chlore, température d'eau, taux de stabilisant, volume de la piscine, temps de filtration journalier, etc.).
Page 8
TABLE OF CONTENTS ENGLISH 1. INSTALLATION DIAGRAM ............................. 3 2. ELECTRONICS UNIT ............................... 4 2.1. Interface ................................4 2.2. Switching on chlorination ............................. 4 2.3. Switching off chlorination ............................ 4 2.4. Setting the production setpoint ........................... 4 2.5. Setting the inversion frequency (optional) ......................4 2.6.
1. INSTALLATION DIAGRAM The electrical connections at cell-level must not point upwards, to avoid any deposits of water or humidity on them. 1 : Cell 2 : Electronics unit ELEMENTS NOT SUPPLIED : 3 : Electrical power supply 4 : Filter 5 : Heat pump 6 : Filtration pump...
2. ELECTRONICS UNIT 2.1. Interface Non-binding image 1 : Alarm LED 2 : Production LED 3 : Screen If display flashing : information awaiting confirmation. If display frozen : information confirmed. Default display : production setpoint. 4 : Control keys 2.2.
2.6. Boost mode (optional) Boost mode sets the production setpoint to its maximum for 24 hours, but can be stopped at any point. This function can be used when chlorine is urgently needed. To launch Boost mode : 1) The production setpoint must not be at 0. 2) Press the bottom key : the message will remain displayed all through Boost mode.
2.8. Alarms 2.8.1. General description Any alarm that is activated : - will immediately be displayed on the screen. Any alarm that is activated : - automatically and immediately stops chlorination. Any alarm that is activated : - can be manually cleared by pressing and holding the bottom key. Message Fault detected Cause...
3. GUARANTEE Before contacting your dealer, please have the following to hand : - your purchase invoice. - the serial no. of the electronics unit. - the installation date of the equipment. - the parameters of your pool (salinity, pH, chlorine levels, water temperature, stabilizer level, pool volume, daily filtration time, etc.). Every effort and all our technical experience has gone into designing this equipment.
