CWM 5
Wall Mount Monitor
Product Summary
The B&W CWM 5 is the compact solution for in-wall speakers. It is completely versatile -
demanding little wall space - and is easy to accommodate in virtually any home or
commercial application.
Benefiting from B&W's in-house technology throughout, the CWM 5 makes few sonic
compromises. The sound quality easily exceeds most competitively priced conventional
loudspeakers.
Drive Units
1 x 125mm (5in) polypro p y l e n e
b a s s / m i d r a n g e
1 x 25mm (1in) polymer diaphragm -
tweeter
F requency Response
75Hz - 20kHz ± 3dB on re f e rence axis
S e n s i t i v i t y
87dB spl (2.83V 1m)
Nominal Impedance
8 ohms
Power Handling
20 - 70W into 8 ohms on unclipped
p rogramme
B&W Loudspeakers Ltd reserves the right to amend details of the specifications without notice in line with technical developments. E & OE. All trademarks acknowledged.
D i m e n s i o n s
Height: 227mm Width: 160mm
Min depth req: 75mm (3in) from wall
s u rface.
Semi-matt white suitable for
F i n i s h
customising or pre-painting
www.bwspeakers.com
