To check the Jeweller signal strength between the range extender and device,
go to the settings of the device connected to ReX, and select Jeweller Signal
Strength Test.
Jeweller Signal Strength Test

Device installation

Selection of the installation site

The location of ReX determines its distance from the hub, the devices
connected to the extender, and the presence of obstacles preventing the
passage of the radio signal: walls, inter oor bridgings, and large objects located
in the facility.
Check the signal strength at the installation site!
If the signal strength reaches just one bar on the indicator, the stable operation
of the security system can not be guaranteed. Take whatever action is
necessary to improve the quality of the signal! At the very least, move ReX or
hub — relocation even by 20 cm can signi cantly improve the reception quality.

Installation procedure

Before installing ReX, be sure to choose the best location that meets the
requirements of this guide! It is desirable for the extender to be hidden from
direct view.
During mounting and operating, follow the general electrical safety rules when
using electrical appliances as well as the requirements of electrical safety laws
and regulations.
Device mounting
