AJAX ReX User Manual page 11

1. Fix the SmartBracket attachment panel with the bundled screws. If you
choose to use other fasteners, make sure that they do not damage or
deform the panel.
It is not recommended to use double-sided adhesive tape for installation. This can
result in ReX falling that can lead to malfunctioning of the device.
2. Slide ReX onto the attachment panel. After installation, check the tamper
status in the Ajax application and then the panel tightness.
3. In order to ensure higher reliability, x ReX to the SmartBracket panel with
the bundled screws.
Do not ip the range extender when attaching vertically (for instance, on a wall).
When properly xed, the Ajax logo can be read horizontally.
You will receive a noti cation if an attempt to detach the extender from the
surface or remove it from the attachment panel is detected.
It is strictly forbidden to disassemble the device connected to the power supply! Do not
use the device with a damaged power cable. Do not disassemble or modify ReX or its
individual parts — this may interfere with the normal operation of the device or lead to its
failure.
Don't place ReX:
1. Outside the room (outdoors).
2. Near metal objects and mirrors that cause attenuation or screening of radio
signals.
3. In rooms characterized by humidity and temperature levels beyond the
permissible limits.
