Sherwood Scuba gemini Manual

Breathable inflator repair program
Hide thumbs Also See for gemini:
Table of Contents

Advertisement

Quick Links

Download this manual
Breathable Inflator Repair Program

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the gemini and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sherwood Scuba gemini

Summary of Contents for Sherwood Scuba gemini

  • Page 1 Breathable Inflator Repair Program...
  • Page 3 Regulator/ Reduce Diver’s Profile Power Inflator and Underwater Inflator Back-Up 2nd Stage Permits Diver to Single Ergonomic Gemini Case Suits Handedly: Power Inflate, Divers Hand Body Deflate, Orally Inflate and Naturally Purge Without Difficulty Low Work Offers Diver Ease of...
  • Page 4 Disassembly Procedures...
  • Page 5 ITEM PART# DESCRIPTION GEMINI BREATHABLE INFLATOR 9000-1 Housing 9000-2 Power Inflator Button Assembly 9000-52 Power Inflator Spring 006-B O-ring 9000-22 Power Inflator Retainer 016B O-ring 9000-21 Power Inflator Poppet 9000-7 Power Inflator Valve Cap 9000-3 Oral Inflator Button 9000-7 Oral Inflator Washer...
  • Page 6 USE WIRE PLIERS...
  • Page 7 Repair Program USE NEEDLE NOSE PLIERS...
  • Page 9 Disassembly Procedures POWER INFLATOR ASSEMBLY...
  • Page 10 Repair Program USE NEEDLE NOSE PLIERS...
  • Page 11 “SQUEEZE OR PINCH METHOD” WITH PLASTIC PICK...
  • Page 12 CAUTION Power Inflator Button is Spring Loaded Place Hand Over Button when Removing Poppet...
  • Page 13 USE SMALL FLAT BLADE SCREWDRIVER REMOVE POPPET...
  • Page 14 DISCARD O-RINGS...
  • Page 15 USE NEEDLE NOSE PLIERS TO REMOVE RETAINER...
  • Page 16 USE O-RING TOOL SET (P/N 11-090-500) PLASTIC PICK...
  • Page 17 Disassembly Procedures ORAL INFLATOR ASSEMBLY...
  • Page 19 IF MINERAL DEPOSITS PRESENT, GENTLY REMOVE WITH PLIERS...
  • Page 20 REMOVE EXHAUST VALVE ASSEMBLY...
  • Page 21 REMOVE DISCARD 1/4-INCH LOCK NUT...
  • Page 22 REMOVE WASHER...
  • Page 23 REMOVE BUTTON ASSEMBLY...
  • Page 25 REMOVE ORAL INFLATOR SEAL...
  • Page 26 DISCARD OLD O-RINGS...
  • Page 27 Disassembly Procedures DEMAND REGULATOR ASSEMBLY...
  • Page 28 LOCATE NOTCH IN COVER USE SMALL FLAT BLADE SCREWDRIVER...
  • Page 29 BLADE 90˚ SLIDE AS SHOWN...
  • Page 30 Repair Program GENTLY PRY...
  • Page 31 REMOVE DIAPHRAGM RETAINER...
  • Page 33 USE SMALL FLAT BLADE SCREWDRIVER REMOVE RETAINING RING COVER...
  • Page 34 REMOVE RETAINING RING...
  • Page 35 PUSH OUT REGULATOR VALVE BODY...
  • Page 37 UNSCREW LEVER ASSEMBLY TO SEPARATE FROM BODY...
  • Page 38 REMOVE O-RING...
  • Page 39 REMOVE SEAT CROWN FROM REGULATOR BODY...
  • Page 40 IF NECESSARY USE 3/16-INCH HEX KEY WRENCH TO REMOVE SEAT CROWN...
  • Page 42 CAUTION Parts are Spring Loaded Place Finger Over Open End of Lever Support...
  • Page 43 USE A 1/4-INCH NUT DRIVER TO DISASSEMBLE...
  • Page 45 REMOVE AND DISCARD L.P. SEAT...
  • Page 46 USE WIRE PLIERS...
  • Page 47 USE WIRE PLIERS...
  • Page 48 Disassembly Procedures HOSE ASSEMBLY...
  • Page 49 USE 11/16-INCH 13/16-INCH OPEN END WRENCH USE WIRE PLIERS...
  • Page 52 CLEANING PROCEDURES Degrease: Warm water (100˚ to 120˚ F). 1 quart mixed 3-4 tablespoons household dish soap. Scrub: Nylon brush (toothbrush works well). Rinse: Fresh tap water. Ultra Sonic Clean: Acid bath 1. Vinegar/water 50/50 2. Lawrence Factor Wash (LFW™) or other Ultra Sonic cleaning agent Rinse: Fresh tap water.
  • Page 53 INSPECTION PROCEDURES Check For: Magnifier: Scratches O-ring Grooves Dings Threads Nicks Sealing Surfaces Damaged Plating Burrs Fillings Corrosion Replace if Needed...
  • Page 55 SERVICE KIT 9000-PK Part Number Includes: 006B 2 O-Rings 008B 1 O-Ring 016B 2 O-Rings 9000-14 L.P. Seat 9000-47 2 Lock Nuts PP-18 3 Cable Ties...
  • Page 56 Reassembly Procedures ORAL INFLATOR ASSEMBLY...
  • Page 57 INSTALL NEW O-RING...
  • Page 59 INSTALL WASHER...
  • Page 62 CONICAL SIDE DOWN...
  • Page 64 INSTALL NEW LOCK NUT...
  • Page 65 USE 1/4-INCH NUT DRIVER CAUTION HAND TIGHTEN ONLY...
  • Page 67 FINGER TIGHT...
  • Page 68 Reassembly Procedures POWER INFLATOR ASSEMBLY...
  • Page 71 USE NEEDLE NOSE PLIERS...
  • Page 72 INSTALL NEW O-RING...
  • Page 75 WIDE SPACE UNDER “S” LOGO...
  • Page 76 INSTALL NEW O-RING...
  • Page 78 USE SMALL FLAT BLADE SCREWDRIVER HANDTIGHT...
  • Page 81 USE NEEDLE NOSE PLIERS HANDTIGHT...
  • Page 82 Reassembly Procedures DEMAND VALVE ASSEMBLY...
  • Page 83 NEW L.P. SEAT...
  • Page 86 USE Q.D. END OF REGULATOR VALVE BODY...
  • Page 87 COMPRESS SPRING EXPOSE POPPET THREADS...
  • Page 89 CATCH TREADS OF NEW LOCK NUT ON POPPET...
  • Page 90 INSTALL LEVER CURVED END TOWARDS LEVER SUPPORT INDEX INDEX FEATURE...
  • Page 92 USE 1/4-INCH NUT DRIVER THREAD LOCKNUT UNTIL POPPET FLUSH WITH END OF NUT...
  • Page 93 INSTALL NEW O-RING...
  • Page 98 INSTALL “GENTLY” WITH PLIERS...
  • Page 100 USE SMALL FLAT BLADE SCREWDRIVER...
  • Page 104 USE 11/13 AND 13/16-INCH OPEN END WRENCHES HAND TIGHT ONLY...
  • Page 105 CONNECT QD HOSE TO A PROPERLY ADJUSTED FIRST- STAGE REGULATOR USING A 9/16-INCH OPEN END WRENCH...
  • Page 107 Regulator Adjustment and Testing Procedures...
  • Page 108 ADJUST LOCKNUT USE 1/4-INCH NUT DRIVER...
  • Page 109 LEVER HEIGHT ADJUSTMENT EVEN WITH EDGE OF HOUSING USE TL123 SPECIALTY TOOL...
  • Page 110 REGULATOR TEST APPLY AIR PRESSURE TO REGULATOR FIRST-STAGE (2700 to 3500PSI) CHECK FOR LEAKS FROM DEMAND VALVE NO LEAKS LEAKS PROCEED TO FINAL CHECK LEVER HEIGHT Reassembly and Final Adjust Locknut if Required Bench Testing Procedures (1/4-inch nut drive) ADJUST SEAT CROWN IF REQUIRED (3/16-inch hex key)
  • Page 112 TURN CROWN “IN” 1/4 TURN USING 3/16-INCH HEX KEY IF STILL LEAKS NO MORE THEN ONE MORE 1/4 TURN (CLOCKWISE) IF AFTER ADJUSTMENT IT STILL LEAKS DISASSEMBLE AND INSPECT FOR PROBLEM...
  • Page 113 Final Reassembly and Bench Test Procedures...
  • Page 116 ALIGN NOTCH WITH BACK OF REGULATOR HOUSING...
  • Page 117 SECOND STAGE INTERMEDIATE OPENING EFFORT PRESSURE RANGE 1.4-2.4 INCHES OF 125-155 PSI WATER...
  • Page 127 THE END...
