Owner's Manual
ASW 3000
™
Active Subwoofer
Product Summary
Together with the technical innovations for which B&W are famous, we have achieved this
supreme audio quality only by use of the very highest quality components. These include
B&W's unique Flowport™ system, new ultra-low frequency 15-inch drive unit which utilises
a stiffer, lighter die cast chassis to minimise unwanted resonances.
High power is essential in reproducing the exceptional bass demands of today's digital
audio recordings and movie sound tracks. The active 3rd order high pass and 4th-order
low pass line level filters with selectable crossover frequency, combined with variable gain
control and a phase reversal switch, allow tight matching between any other loudspeakers.
A passive 1st order speaker level filter gives flexibility for systems without preamp outlets.
Technical highlights
Flowport™: Golf ball aerodynamics theory points the way towards lower
distortion reflex ports. Dimples improve the way the air flows over the surface of
any object. In the case of reflex ports, they offer a significant improvement over
simply flaring the port ends in reducing air flow turbulence at each end of the
port; so you get less chuffing noise and less compression at high sound levels.
D e s c r i p t i o n
Active vented-box subwoofer system with
magnetic shielding
Drive Unit
1 x 375mm (15-in) dia long-throw drive
unit
F requency re s p o n s e
± 3dB at 18Hz - 40/140Hz adjustable
A m p l i f i e r
300W continuous
I n t e rnal Vo l u m e
100 litres
B&W Loudspeakers Ltd reserves the right to amend details of the specifications without notice in line with technical developments. E & OE. All trademarks acknowledged.
Net Weight
50kg (110lb)
D i m e n s i o n s
Height: 580mm Width: 610mm
Depth: 600mm
F i n i s h e s
Cabinet: Black Ash vinyl
Grille: Black cloth
www.bwspeakers.com
