Summary of Contents for Williams Sound SORIN
- Page 1 u s e r m a n u a l...
-
Page 2: Table Of Contents
Contents System Components System Features & Benefits Safety Information Operating Instructions Battery Installation Turning power on/off Charging the speaker Checking the Battery Using the Microphone Connecting External Devices Using the Stand Belt Clip Using the Shoulder Strap Using the Microphone Troubleshooting Recycling Instructions Limited Warranty... -
Page 3: System Components
System components (1) SORIN amplified speaker (SPK 025) (1) Button microphone (MIC 043) (1) Headset microphone (MIC 042) (1) Control cable with USB connector. (WCA 044) (1) Li-ion Battery pack (BAT 040) (1) Power supply, switcher US plug (TFP 040) (1) Auxiliary input cable, 3.5mm-3.5mm, 120 cm (WCA 042) -
Page 4: System Features & Benefits
System features & benefits · Powerful digital amplifier with 12V, 20W DC/DC converter technology · Main speaker has an output of 5W (max 10W) and mini woofer of 1W (Max 2W) · Connects to external devices such as an MP3 player through the AUX input ·... -
Page 5: Safety Information
Safety information · Do not push multiple buttons at one time · Keep out of reach of children and pets · If the product is not used for a long period, discon- · If the product becomes wet: do not use. Call Wil- nect the battery from the speaker. -
Page 6: Battery Installation
Battery installation IMPORTANT The battery shipped with this unit was disconnected at the factory. Prior to using the Sorin product, connect the battery as shown: 1. Pull down the battery cover 2. The battery will be visible after opening the cover. -
Page 7: Turning Power On/Off
Turning power on/off Speaker Power · Individual power buttons located on speaker, and microphone control cable · Speaker turns ON after pushing the button for 1 second · Speaker turns OFF after pushing the button for 1 second 800.843.3544 • williamssound.com... -
Page 8: Charging The Speaker
Charging the speaker Charging terminal 1. Open the rubber cap on the 2. Connect charging cable to left side of the speaker the lower slot · Prior to use, charge the unit for at least 3 hours. Note: Charger can be used to power the speaker provided the battery is fully charged. -
Page 9: Checking The Battery
Checking the battery Battery indicator BATTERy INDICATOR ChART Green Green Green (FULL) Green Green Green (LOW) Power (red) Charged (green) Charging (yellow) · Users can verify if the battery is charged, charging, and if the power is on/off. · If the indicator shows “GGGR,” the battery is full charged and ready for use. ·... -
Page 10: Using The Microphone
Using the microphone Mic connection terminal 1. Open the rubber cap on 2. Connect microphone top-left side of the speaker cable to the speaker · Connect control cable with microphone to the microphone terminal. · Turn the power on by pressing the power button for 1 second ·... -
Page 11: Connecting External Devices
Connecting external devices 1. Connect MP3 player or CD player with AUX cable and to the AUX input on the left side of the speaker MP3 Player CD Player Computer AUX Input · Users may connect external audio devices such as an MP3 or CD player to the AUX input on the speaker. -
Page 12: Using The Stand
Using the stand Set the Sorin on a flat surface such as a table or desk. 1. Set the stand on the three o’clock position on the back side of the speaker and turn 90 degrees to lock into place... -
Page 13: Belt Clip
Using the belt clip 1. Place the belt clip at a three o’clock position on top of the metal plate on the back of the speaker. Turn the belt clip 90 degrees to lock into place. 800.843.3544 • williamssound.com... -
Page 14: Using The Shoulder Strap
Using the shoulder strap 1. Install strap clips on both 2. Connect the shoulder sides of the speaker strap to the strap clip · The shoulder strap can also be used with the carry case. -
Page 15: Using The Microphone
Using the microphone (MIC 042) · Place the rear wear microphone over ears 800.843.3544 • williamssound.com... -
Page 16: Troubleshooting
A: Disconnect the battery, then reinstall and charge again. If you have used the battery for more than a year, the battery may need to be replaced. Call Williams Sound customer service to order a replacement battery (part no.: BAT 040): 800-843-3544 or 1-952-943-2252. -
Page 17: Recycling Instructions
Recycling instructions Battery Safety and Disposal Help Williams Sound protect the environment! Please take the time to dispose of your equipment properly. Product Recycling for Customers in the European Union: Please do NOT dispose of your Williams Sound equipment in the household trash. -
Page 18: Limited Warranty
Williams Sound products are engineered, designed, and manufactured under carefully controlled conditions to provide you with many years of reliable service. Williams Sound warrants the Sorin system against defects in ma- terials and workmanship for TWO (2) years. During the first two years from the purchase date, we will promptly repair or replace the Sorin. -
Page 19: System Specifications
Specifications Dimensions: 3.25” W x 5.4” H x 1.02” D. Weight: 9.7 oz (with battery) Color: Black with silver sides Battery Power: Type: 7.4 V, rechargeable, 1800 mAHr (custom) Lithium ion Life: Up to 30 hours (contingent upon speaker output level) Current drain: 1.5 amps (at nominal listen level), 2.5 amps maximum Battery Charger: Type: Switcher, input 110 to 220 VAC at 50 to 60 Hz., output 9 VDC at 1.5 amps with a 2.5 mm DC plug... - Page 20 With SORIN, your voice will never get tired. ©2010, Williams Sound Corp. MAN 141C...
