PLA 90
Counter Loop
User MANUAL
MAN 173D

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PLA 90 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Williams Sound PLA 90

  • Page 1 PLA 90 Counter Loop User MANUAL MAN 173D...
  • Page 2 The induction loop system is already completely installed and set up in the housing. All you have to do is to place the PLA 90 at the desired position between you and the person you are talking to and connect the power supply unit.
  • Page 3 Controls and Indicators Front View Front View Color signal strip Color signal strip “Power on” light “Power on” light Rear View Rear View Built-in Status light microphone “loop signal” Built-in Status light microphone “loop signal” “Power on” Microphone light “Power on” adjustment Microphone light...
  • Page 4 Volume control The volume control adjusts the volume of the headphone jack. Automatic switch off The PLA 90 will switch off automatically after 2 minutes if no signal is received, from either the internal or external microphone. Charging control light...
  • Page 5 Wall mounting 1. Screw in two screws (not included) 14.1 cm apart at the place you would like to mount the PLA 90 on the wall (see figure). 2. Now set the PLA 90 on the screws and slide it down slightly to secure it in place.
  • Page 6 Changing the color signal strip You can change the color signal strip of the PLA 90, as shown below. Maintenance and care The PLA 90 does not require any maintenance. If the unit becomes dirty, simply wipe it clean with a soft, damp cloth. Never use spirits, thinners or other organic solvents.
  • Page 7 Warranty The PLA 90 is a very reliable product. Should a malfunction occur despite the unit having been set up and operated correctly, please contact your dealer. The warranty covers the repair of the product and returning it to you free of charge during the warranty period.
  • Page 8 info@williamsav.com / www.williamsav.com 800-843-3544 / INTL: +1-952-943-2252 ©2019 Williams AV • All Rights Reserved MAN 173D...
