Shire 8x6 Value Overlap Manual page 18

RIGHT HAND HUNG DOOR POSITION SHOWN
GB-IE
Align the A2456 hinge strip flush with the inside face of the doorway framework (widest side against
framework )and fix with 40mm nails.
07
46mm
Hinge Strip
(A2546)x01
40mm Nails
(A0025)x04
18
Building
Photographs
It will be greatly
appreciated if you could
forward images of your
completed building to -
sales@shiregb.co.uk.
A2546
FIT THIS TO THE
SIDE YOU WISH
TO HANG THE
DOOR HINGES
