- Page 1 ZH 用户手册 / 组装说明 EN Instructions for use / assembly instructions Metris 31471007...
- Page 2 中文 安全技巧 技术参数 装配时为避免挤压和切割受伤，必须戴上手 1 MPa 工作压强： 最大 0,1 - 0,5 MPa 套。 推荐工作压强： 1,6 MPa 测试压强： 不得让儿童和肢体、精神和/或意识有障碍的成 (1 MPa = 10 bar = 147 PSI) 人在不受监管的情况下使用淋浴系统。受酒精 70°C 热水温度： 最大 或毒品影响的人员不得使用淋浴系统。 65°C 推荐热水温度： 淋浴系统只允许作为洗浴、卫生和洁身之用。 70°C / 4 分钟 热力消毒: 最大 必须避免让身体敏感部位（如眼睛）接触到莲 • 自动防止回流 蓬头喷水。必须保持莲蓬头与人头之间有足够 • 该产品专为饮用水设计！ 的距离。 该产品不得作扶柄使用。必须安装单独的扶 柄。 符号说明 冷热水管间过大的压力差必须予以平衡。 请勿使用含有乙酸的硅胶！ 安装提示 • 安装前必须检查产品是否受到运输损害。 安装 调节 (参见第页 6) 后将不认可运输损害或表面损伤。 热水温度调节。如果使用即热式喷头， • 管道和阀门必须根据通用标准进行安装、冲洗...
-
Page 3: Safety Notes
English Safety Notes Technical Data Gloves should be worn during installation to prevent Operating pressure: max. 1 MPa crushing and cutting injuries. Recommended operating pressure: 0,1 - 0,5 MPa Test pressure: 1,6 MPa Children as well as adults with physical, mental and/ (1 MPa = 10 bar = 147 PSI) or sensoric impairments must not use this product Hot water temperature: max. 70°C without proper supervision. Persons under the influ- Recommended hot water temp.: 65°C ence of alcohol or drugs are prohibited from using Thermal disinfection: max. 70°C / 4 min this product. The shower system may only be used for bathing, • Safety against backflow hygienic and body cleaning purposes. • The product is exclusively designed for drinking water! Do not allow the streams of the shower touch sensi- tive body parts (such as your eyes). An adequate Symbol description distance must be kept between the shower and you. The product may not be used as a holding handle. A Do not use silicone containing acetic acid! separate handle must be installed. The hot and cold supplies must be of equal pres- Adjustment (see page 6) sures. To adjust the hot water limiter. Using a hot Installation Instructions water limiter in combination with a continu- ous flow water heater is not recommended. - Page 4 Montage 10452187 SW 8 mm M10x35 SW 8 mm...
- Page 5 Montage SW 22 mm > 2 min SW 22 mm (2 Nm)
- Page 6 0,3 MPa 60 °C 10 °C 0,3 МПа 0,3 MPa 0,3 لﺎﻜﺴﺑﺎﺠﻴﻣ 36°C 38°C 50°C 60°C 43°C 55°C 17 x...
- Page 7 Wartung...
- Page 8 Maße Maße Metris 31471007 2 4 5 10 0 2 0 9 max. 100 Ø Ø 12 4 min. 70 G ½ Ø 14 8 普丽唯 PuraVida 28558007 15 0...
- Page 9 Durchflussdiagramm Durchflussdiagramm 0,60 0,55 0,50 0,45 0,40 0,35 0,30 0,25 0,20 0,15 0,10 0,05 0,00 9 12 15 18 21 24 27 30 Q = l/min Q = l/sec...
- Page 10 Reinigung 中文 汉斯格雅产品的清洁建议 重要说明 肥皂，洗发水、沐浴液、染发剂、香水、刮胡水、 现代的卫浴龙头、厨房龙头、花洒、配件、盥洗 指甲油的残留也会对产品造成损伤。 台、浴盆和加热器采用的制造材料非常迥异，以适 此处：使用后要小心地用清水将剩余物冲洗干净。 应产品外形设计和使用功能的市场需求。 同样在产品下方不得存放洗涤剂和化学药品，例如 为了避免产品损坏和由此引发的投诉及争议，必须 不可放在用于洗脸盆的梳洗柜中否则挥发气体将 在使用和清洁产品时遵循有关规程。 损坏产品。 在已经损伤的表面继续使用清洁剂会给表面造成更 在保养汉斯格雅产品时，原则上必须注意： 大的损伤。 表面损坏的部件必须更换，否则会有受伤 • 只能使用那些有明确注明是适用于本产品的清 的危险。 洁剂。 • 不允许使用含有盐酸、蚁酸、氯漂或醋酸的清 洁剂，因为这些清洁剂会给产品表面造成严重的 不按规定进行清洁而造成的任何损坏不在本公司产 损伤。 品保修范围之内。 • 含磷酸的清洁剂必须在特定条件下使用。 QuickClean • 不允许将两种以上清洁剂混合使用。 有了QuickClean，手工清洁功能，要去掉喷头上的 • 不允许使用具有研磨作用的清洁工具和设备，如 水垢，只需简单地搓除即可。 不适合的清洁粉末、海绵垫或超细麦克布。 • 必须严格遵守清洁剂生产厂商的使用说明。 担保 • 严格遵守清洁剂的用量和作用时间，决不允许清 洁剂的作用时间长于规定值。 Hansgrohe 向用户保证，该产品无制造 缺陷。如 • 定期的清洁以预防水垢。 果自购买之日起五年内出现缺 陷，Hansgrohe 将...
-
Page 11: Warranty
English Cleaning Recommendation for • After cleaning rinse thoroughly with clean water to remove any cleaner residue. Hansgrohe Products • The use of steam cleaners is not permitted. The high Today, modern sanitary and kitchen tapware, showers, temperatures can damage the products. accessories, washstands, tubs and radiators consist of Important very different materials to comply with the needs of the Residues of toiletries such as liquid soaps, shampoos and market with regard to design and functionality. shower gels, hair dyes, perfumes, aftershave and nail To avoid damage and reclamations, it is necessary to varnish can also cause damage. consider certain criteria when cleaning. Here too: Carefully rinse with water after use to remove residues. With regard to caring for the Likewise, do not store any cleaning agents or chemicals Hansgrohe products, the following under the products, for example in a vanity unit, as the must in principle be heeded: vapours may damage the products. The damage of already damaged surfaces will • Only use cleaning material which is explicitly provided deteriorate under the effect of the cleansers. for this type of application. Components with damaged surfaces • Never use cleaning materials, which contain hydrochloric acid, formic acid, chlorine pale lye or must be exchanged, otherwise there acetic acid, as they cause considerable damage. could be an injury danger. Damage caused by improper treatment will not be • Phosphorus acidic cleaners are only conditionally applicable. covered by our guarantee. • Mixing cleaning agents is not permitted, generally. QuickClean • Never use cleaning materials or appliances with an abrasive effect, such as unsuitable cleaning powders, The QuickClean cleaning function only needs a small... - Page 12 Reinigung 94246000 93339000 > 1 min...
- Page 13 Bedienung 开 / open 关 / close 热 / hot 冷 / cold...
- Page 14 Serviceteile 95519000 96338000 97406000 97209000 98193000 (M 37x1,5) (32x2) SW 30 mm 95008000 92730000 95140000 (M 4x20) SW 4 mm 95284000 97979000 28558007 95871000 93339000 (M24x1) 94246000 (SW 22 mm) 97978000 96295000 (SW 19 mm) (M4x4) 94074000 SW 3 mm 98058000 28282000 97670000 (M 10x35) SW 8 mm 98117000 (9x1,5) 97686000 98371000 98162000 (29x3) (44x2,5) 98419000 (7x2)
- Page 16 Hansgrohe · Auestraße 5 - 9 · D-77761 Schiltach · Telefon +49 (0) 78 36/51-1282 · Telefax +49 (0) 7836/511440 E-Mail: info@hansgrohe.com · Internet: www.hansgrohe.com...
