Onboard AC'97 CODEC
CD-IN Connector
Green: AUX-IN Connector
Red: MODEM-CN Connector
Front Audio Connector
FAN3 Connector
CNR Expansion Slot
32-bit PCI Expansion Slot x5
IrDA Connector
2Mbit Flash ROM
JP14 CMOS Clear Jumper
Chassis Intrusion Connector
WOL Connector
nd
Supports 2
USB Connector
Front Panel Connector
ATA/33/66/100 IDE Connector x2
FDD Connector
RJ45 10/100
LAN Jack
PS/2 Mouse
SPP/EPP/ECP Parallel Port
(AX4G-B2N only)
Connector
PS/2 Keyboard
USB Port
COM 1 Port
Connector
MIDI/Game Port
COM 2 Port
MIC-In
Line-In
Speaker Out
Resetable Fuse
JP28 Keyboard/Mouse Wakeup
Enable/Disable Jumper
Intel 82562ET PHY (For AX4B-G2N only)
2200
μ
F Low ESR Capacitors
4-pin 12V. ATX Power Connector
AGP 4x Expansion Slot
(for 1.5V AGP card)
FAN2 Connector
478-pin CPU socket with Voltage and
Frequency Auto-detection that supports
®
®
Intel
Pentium
4 1.4~2.4GHz+ CPU
(Northwood and Willamette are supported)
®
Intel
845D chipset (Brookdale)
CPU Fan Connector with H/W
Monitoring Function
184-pin DIMM Socket x2 supports
DDR266 DDR SDRAM
maximum up to 2 GB
ATX Power Connector
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for AOpen AX4B-G2
Summary of Contents for AOpen AX4B-G2
- Page 1 RJ45 10/100 LAN Jack PS/2 Mouse SPP/EPP/ECP Parallel Port MIDI/Game Port (AX4G-B2N only) Connector PS/2 Keyboard USB Port COM 2 Port COM 1 Port Connector Onboard AC’97 CODEC MIC-In CD-IN Connector Line-In Green: AUX-IN Connector Speaker Out Resetable Fuse Red: MODEM-CN Connector Front Audio Connector JP28 Keyboard/Mouse Wakeup Enable/Disable Jumper...
-
Page 2: Jp14 Clear Cmos
1. JP14 Clear CMOS You can clear CMOS to restore system default setting. To clear the CMOS, follow the procedure below. 1. Turn off the system and unplug the AC power. 2. Remove ATX power cable from connector PWR2. Everything you need to boot this 3. - Page 3 3. Installing Processor 5. Setting CPU Voltage & Frequency This socket supports Micro-FC-PGA2 package CPU, which is the latest CPU package Setting CPU Core Voltage The CPU core voltage will be automatically detected. It is not necessary to set CPU core developed by Intel.
-
Page 4: Connecting Ide And Floppy Cables
6. Support 2 USB Port 8. Connecting IDE and Floppy Cables This motherboard provides four connectors to connect USB devices, such as mouse, Connect 34-pin floppy cable and 40-pin, 80-wire IDE cable to floppy connector FDD and keyboard, modem, printer, etc. There are two connectors on the PC99 back panel. You IDE connector. - Page 5 12. Connecting CD / MODEM / AUX Connector 10. Front Audio Connector If the housing has been designed with an audio port on the front panel, you’ll be able to The AUX-IN connector is used to connect MPEG MODEM-CN connect onboard audio to front panel through this connector. By the way, please remove Audio cable from MPEG card to onboard sound.
- Page 6 STRONGLY RECOMMMANDED to close all the applications before you start the model name. upgrading. Download the new version of BIOS package zip file from AOpen official web site. (ex: http://www.aopen.com) Unzip the download BIOS package (ex: WAX4BG2102.ZIP) with WinZip (http://www.winzip.com) in Windows environment.
-
Page 7: Part Number And Serial Number
IDE cable. The problem should be caused by the Check if the system can IDE cables or HDD itself. reboot successfully. Re-install Windows 95, Windows 98 or Windows NT. AX4B-G2 is model name of motherboard; R1.02 is BIOS version... - Page 8 Dear Customer, Test Report: We recommend to choose board/card/device from the Thanks for choosing AOpen products. To provide the best and fastest service to compatibility test reports for assembling your PC. our customer is our first priority. However, we receive numerous emails and http://www.aopen.com/tech/report/default.htm...
