Byte Description
36-37
Current 4
38-39 Reserved
40-41 Reserved
42-41 Reserved
44-45 Parameter list version
number
46-47 Digital Input state
48-73 Reserved
Product type code:
1
4 = Digistart D2
8 = Digistart D3
Reading register 3 (Changed parameter value) will reset registers 2 (Changed parameter number) and 4
2
(Parameters have changed). Always read registers 2 and 4 before reading register 3.
Bits 10 to 15 of register 4 report the soft starter's trip or warning code. If the value of bits 0 to 4 is 6, the
3
soft starter has tripped. If bit 5 = 1, a warning has activated and the starter is continuing to operate.
For models D3-1x-0053-B and smaller this value will be 10 times greater than the value displayed on the
4
keypad.
Powerscale functions as follows:
5
0 = multiply Power by 10 to get W
1 = multiply Power by 100 to get W
2 = Power is represented in kW
3 = multiply Power by 10 to get kW
16
Bits
0 to 13 Phase 3 current (rms)
14 to 15 Reserved
0 to 7 Parameter list minor revision
8 to 15 Parameter list major version
0 to 15 For all inputs, 0 = open, 1 = closed (shorted)
0 = Start
1 = Stop
2 = Reset
3 = Input A
4 = Input B
5 = Input C, if fitted
6 = Input D, if fitted
7 to 15 = Reserved
