6.3.3 Trip Codes
Table 6-5 Trip messages
Trip Code
1 Excess start time
2 Motor overload
3 Motor thermistor
4 Current imbalance
5 Frequency
6 Phase sequence
7 Instantaneous overcurrent
8 Power loss
10 Heatsink overtemperature
11 Motor Connection Tx
12 Input A trip
13 FLC too high
14 Unsupported option (function not available in inside delta)
15 Starter communication (between module and soft starter)
16 Network communication (between module and network)
17 Internal fault x (where x is the fault code detailed in the table
below)
20 Ground fault
1
23 Parameter out of range
24 Input B trip
26 L1 phase loss
27 L2 phase loss
28 L3 phase loss
29 L1-T1 shorted
30 L2-T2 shorted
31 L3-T3 shorted
32 Motor 2 overload
33 Time-overcurrent (Bypass overload)
2
35 Battery/clock
36 Thermistor circuit
37 RTD/PT100 A
38 RTD/PT100 B
1
39 RTD/PT100 C
1
40 RTD/PT100 D
1
41 RTD/PT100 E
1
42 RTD/PT100 F
1
43 RTD/PT100 G
1
45 RTD/PT100 X Circt
46 Analog input trip
47 Overpower
48 Underpower
255 No trip
Available with Digistart D3 only if the appropriate option card is fitted.
1
For Digistart D3, time-overcurrent protection is only available on internally bypassed models.
2
