Internal Fault x
The table below details the internal fault code associated with trip code 17.
Table 6-6 Internal fault X
Internal fault
70 to 72
73
74 to 76
77 to 79
80 to 82
83
84 to 98
6.3.4 Motor current
Bytes 6 and 7 report motor current in amperes. For models D3-1x-0053-B and smaller this value will be
10 times greater than the value displayed on the keypad.
6.3.5 Motor temperature
Bytes 8 and 9 report motor temperature as a percentage of the motor service factor (calculated by the
soft starter's thermal model).
14
Current Read Err Lx
ATTENTION! Remove Mains Volts
Motor Connection Tx
Firing Fail Px
VZC Fail Px
Low Control Volts
Internal fault X
Contact your local supplier with the fault code (X).
Message displayed on the keypad
