Summary of Contents for Lorentz PS2-100
- Page 2 Congratulations Look after your pump to ensure it has a long life Only connect equipment that was provided by the manufacturer or supplier to this pump. Do not try to power the pump from batteries, generators or a grid connection. Keep the controller out of water or direct rain, this reduces the chances of short circuit of cable connections.
- Page 3 Getting started Setting up your pump Position the PV modules facing the sun, avoid shading. Connect a hose or pipe to the pump outlet Connect the cables Connect either accessories or jumpers to A1 and A2. Connect the solar (PV) cable last.
- Page 4 Pumping Water Operation Ensure the pump is fully submerged in water Switch on the pump System will run LEDs (lights) on the controller tell you: Pump is running Use the switch to turn off the pump Pump is turned off Use the switch to start the pump An accessory has stopped the pump Check the float switch / dry run sensor...
- Page 5 Troubleshooting The following reasons will cause the pump not to start or to stop unexpectedly • Not enough irradiation • PV modules: dirty/not facing towards the sun/ are shaded • Input A1 or A2 is activated, check the LED status •...
