Summary of Contents for Ashley Signature EF19-42A
- Page 1 Fireplace User Guide MODEL#: EF19-42A ® SAVE THESE INSTRUCTIONS THIS PRODUCT WAS MANUFACTURED BY PAITE FOR ASHLEY FURNITURE INDUSTRIES, INC. All Rights Reserved. Page 1 of 14...
-
Page 2: Table Of Contents
Table Of Contents Table of Contents ..........................IMPORTANT SAFETY INFORMATION ................PREPARATION ............................GROUNDING INSTRUCTIONS ....................SITE PREPARATION ........................Locating Your fireplace ......................Specifications ............................ FCC STATEMENT ..........................OPERATIONS AND FEATURES ....................Using the Remote Control ..................... Using the Fireplace Control Panel ................... -
Page 3: Important Safety Information
If you have any questions regarding the use of this unit, or find that your fireplace unit needs service, please contact Ashley Furniture Industries at the below number. - Page 4 IMPORTANT SAFETY INSTRUCTIONS Read all instructions before using this fireplace. When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electrical shock, injury or death and property damage. Such precautions include, but are not limited to, the following: 1.
-
Page 5: Preparation
PREPARATION GROUNDING INSTRUCTIONS This product must be grounded. This product is equipped with a cord having an equipment- grounding conductor and a grounding plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances. This fireplace is for use on 120 volts circuit and has a grounded plug that looks like the one illustrated on Figure 1. -
Page 6: Site Preparation
SITE PREPARATION Ensure the power cord is not installed so that it is pinched or against a sharp edge and ensure that the power cord is stored and secured to avoid tripping or snagging to reduce the risk of fire, eletric shock,property damage, serious injury or death. Locating Your Fireplace Read and follow the important safety instruction in this user guide. -
Page 7: Fcc Statement
FCC STATEMENT NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 8: Operations And Features
OPERATIONS AND FEATURES Using the Remote Control Power This will turn the unit ON and OFF. When it is turn OFF, the fan will continue to continue to run after turning off the heating function to cool and protect heating function to cool and protect period of 3 minutes .When the unit is turned back ON, the system will recall the last heat setting used. -
Page 9: Using The Fireplace Control Panel
Using the Fireplace Touch Control Panel Adjust Temperature Adjust Brightness Power Thermostat This allows programming This will turn the unit ON ℉ and ℃ will be displayed along This function will cycle of the thermostat. The and OFF. When the unit is with the temperature on the through the five fireplace can be used... -
Page 10: Using The Wireless Control Panel
Using the Wireless Touch Control Panel Power This will turn the Wireless Connection ON and OFF. Volume + This allows you to turn up the volume. Volume － This allows you to turn down the volume. Pause This allows you to pause the player. Note: Hold the button for 3 seconds you can enter AUX, USB, wireless selection mode, then select the right mode for playing.. -
Page 11: The Fireplace Remote Control
The Fireplace Remote Control The remote combines all the functions of the front panel controls for flexibility and convenience when changing desired settings. The first thing to do with the remote control is to remove the plastic sheet insulated the battery. (The battery is supplied with the remote control.) Replacement batteries can be purchase at any electronics store. -
Page 12: Care And Maintenance
Do not use abrasive cleaners. Use a standard non-flammable glass cleaner for the glass panel of the unit. IN NO EVENT WILL ASHLEY FURNITURE INDUSTRIES, INC. OR ITS SUBSIDIARIES, AFFILIATES, DIRECTORS, OFFICERS, OR AGENTS (COLLECTIVELY “AFI”), BE LIABLE TO THE... -
Page 13: Circuit Diagram
CIRCUIT DIAGRAM If the fireplace appears to malfunction, turn the unit off and unplug the fireplace from the wall immediately. Please contact the store that this was purchased from with the original purchase receipt or call 1 (800) 477-2222 for service related questions or concerns. Please do not attempt to repair the electric fireplace. -
Page 14: Trouble Shooting Guide
Warranty & Return Policies Please refer to the included warranty card. Be sure to keep this manual and warranty card for possible future use. Manufactured by Guangdong Paite Electrical Technology Co. LTD for Ashley Furniture Industries, Inc. MODEL#: EF19-42A Page 14 of 14... - Page 15 FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
