Table Saw
Operator's Manual
65062
65066
FOR YOUR SAFETY
OPERATING MACHINE
Save This Manual for Future Reference
65063
65067
Original Instruction
2020/5/27 9:38:40
Advertisement
Table of Contents
Related Manuals for TOPMAQ 65062
Summary of Contents for TOPMAQ 65062
- Page 1 Save This Manual for Future Reference Original Instruction Table Saw Operator’s Manual MODEL NUMBER : 65062 65063 65066 65067 SERIAL NUMBER : Both model number and serial number may be found on the main label. You should record both of them in a safe place for future use.
-
Page 2: Table Of Contents
Parts List humidity should less than 50% at 40°C. It can be stored or transported under ambient temperatures between -25°C and 55°C. Specifications Model Number 65062 65063 65066 65067 AC Motor 400V 3~ 50Hz 230-240V~ 50Hz 400V 3~ 50Hz 230-240V~ 50Hz... -
Page 3: Symbols
SYMBOLS Sound emission level (LpA) 94.9 db(A) k=3 db(A) Sound pressure level (LpA) 89.9 db(A) k=3 db(A) Sound power level (LwA) 103.9 db(A) k=3 db(A) T h e r a t i n g p l a t e o n y o u r m a c h i n e m a y show symbols. -
Page 4: Safety
Wear appropriate hearing protection. Wear SAFETY respiratory protection to avoid the risk of General Safety Rules inhaling harmful dust. Always keep hands and feet away from all moving parts during operation. Moving parts Understand your Machine can cut or crush body parts. Read this manual and labels affixed to the Always keep hands and feet away from all machine to understand its limitations and... - Page 5 Keep attention when changing the saw blade. Protect yourself from electric shock. Do not plug or unplug the motor while standing in or The cutting width is not smaller and the main blade thickness of the saw blade is not greater around damp or wet ground.
- Page 6 Use the push stick or handle with sliding Refitting, including adjusting and measuring wood, to pass the workpiece securely out off works, and cleaning must be carried out only the saw blade. when the motor is switched off. Disconnect the main power plug. Make sure that the riving knife is always used, and set up is correctly.
-
Page 7: Application Conditions
All parts must be correctly mounted and all Handle insertion tool with caution. They are ideally stored in the originally package or conditions must be fulfilled to ensure fault- free operation of the electric tool. The moving special containers. Wear protective gloves in order to improve grip and to further reduce protective hood may not be fixed in the open position. -
Page 8: Contents Supplied
(× 2, for model 65066 & 65067) (for model 65066 & 65067) (× 2) (× 2) (× 2) (× 1, for model 65062 & 65063) (× 2, for model 65066 & 65067) (× 4) (× 4) (× 2) (× 2) -
Page 9: Assembly
Rear Bench Extension ASSEMBLY 1. Align the rear bench extension flush with the saw bench. This table saw was partially assembled at the 2. Pushing the rear extension onto the sawing factory. To assemble your machine follow the bench using bolts M6×12 and loosely fasten below instructions. - Page 10 Side Bench Extension (Only Model 65066, 65067 use) × × 1. Align the other side bench extension extension flush with the saw bench. 2. Pushing the side bench extension onto the sawing bench using bolts M6×12 and loosely fasten the flat washers and nuts M6. 3.
- Page 11 Miter Gauge 3. The two transport handles are attached at the left and right leg at the front of the saw 1. Remove the two nuts and washers from the using four hexagon bolts M6×12, washers 6 side rail. See illustration 1. and nuts M6.
- Page 12 Rip Fence Locker Cutting Height Indication 1. Slide the locker seats to the locker shaft. See illustration 1. 2. Fasten the whole rip fence locker to the bench table using two bolts M6×30 and nuts. See illustration 2. 2. Fasten the switch to the bench table using Riving Knife two hexagon bolts M6×12, washers 6 and nuts M6.
-
Page 13: Know Your Machine
KNOW YOUR MACHINE Features and Controls Bench Extension Saw Blade Guard Rip Fence Riving Knife Miter Guage Rip Fence Locker Guide Rail Motor Switch Self-tapping Push Stick Transport Handle Suction Piece Height Adjusting Handlebar Transporting Wheels Saw Blade Key Push Stick 1 ON/OFF Switch Height Adjusting Handlebar The saw can be switched on by pressing the... -
Page 14: Set Up
Working with the Rip Fence Set Up Set the Guide Height Change Blade Depth The rip fence has two guide surfaces with Turn the height adjusting handlebar to set the different heights. blade to the required cutting depth. For thick material you must use the rip fence Counterclockwise: smaller cutting depth as shown in below illustration 1 &... - Page 15 Tension Lever Set the Cutting Width The rip hence has to be used when making longitudinal cuts in wooden workpieces. The rip fence should be mounted on the right- Unlock Lock hand side of the saw blade. Before move the rip fence, release the rip fence locker.
-
Page 16: Operation
Cutting Narrow Workpieces Be sure to use a push stick when making longitudinal cuts in workpieces smaller than 120 mm in width. A push stick is supplied with the saw. Replace a damaged or worn push stick immediately. Unlock Lock 1. -
Page 17: Transport
Making Angular Cuts MAINTENANCE Angular cuts must always be made using the rip fence. Warning! Prior to any adjustment, 1. Set the blade to the desired angle. m a i n t e n a n c e o r s e r v i c e w o r k 2. - Page 18 Always check the bench insert in the process: Immediately replace the bench insert if it is damaged or is no longer flush with the saw table. 6. Make sure that the angle of the saw blade is set to 0°. 7.
-
Page 19: Storage
20. Mount the riving knife, the table insert and STORAGE the saw blade guard. Store the equipment and accessories in a dark and dry place at above freezing temperature. The ideal storage temperature is between 5 and 30°C. Store the electric tool in its original packaging. -
Page 20: Trouble Shooting
TROUBLE SHOOTING Problem Cause Remedy 1. Fastening nut tightened insufficiently 1. Check the mains fuse Motor does not 2. Check the extension cable 2. Extension cable defect start 3. Have it checked by an electrician 3. Connections on the motor or switch defect 1. -
Page 21: Parts Schedule
PARTS SCHEDULE TABLE SAW 65063UK00M100.indd 21 2020/5/27 9:38:56... -
Page 22: Parts List
65062 / 65063 / 65066 / 65067 Parts List Description Q'ty Description Q'ty Rubber Foot Tension Lever Locking Rod Bolt 8.8 M6×12 Bench Insert Washer 6 Screw ST2.9×25 Transport Handle Lever Blade Guard-Left Transport Handle Lever Cover Wing Nut M6 Bolt 8.8 M8×45... - Page 23 Description Q'ty Description Q'ty Height Indicator Guide Rail Nut M6 Side Rail- Front cap Nut M8 Side Rail Bolt 8.8 (cvc) M8x16 Bolt M6×20 Guiding Connecting Plate Sliding Plate Connecting Plate Screw ST4.8×16 Height Adjusting Handlebar Rod Side Rail- Rear cap Thin Nut M10 Bracket Height Adjusting Handlebar...
- Page 24 65063UK00M100.indd 24 2020/5/27 9:38:57...
