Key Automation CT-400 Manual For The Installer page 14

EN
• Single-phase or three phase control unit for 1 motor 400/230V up to 2Hp with electrical
obstacle detection
• For sliding gates or foll-up doors.
• Electrical obstacle detection, interior/exterior brake , 4 functions, radio decode supplied.
Selection of the 400 Vac power supply
Selection of the 230 Vac power supply
Selection of the power supply
Signal light or interior brake
Signal light or interior brake
CLOSE
command
OPEN
command
14
-1-
U
-2-
V
-3-
W
-4-
T
-5-
T
-6-
SPY
-7-
SPY
-8-
-9-
-10-
Line 230/400 Vac -11-
Line 230/400 Vac -12-
-13-
Line 230/400 Vac
-14-
-15-
-16-
24 Vac -29-
24 Vac -30-
COM
Common
COM
Common
Opening Limit Switch -17-
Closing Limit Switch -18-
-19-
Stop
Photo -20-
Open -21-
-22-
Close
-23-
START
-24-
PEDESTRIAN
-25-
Mechanical edge NC
-26-
-27-
FTS
Photo-test
-28-
FTS
Photo-test
.
Control board dispose of
2 buttons for opening and
closing of the door.
See page no.4
CT-400
Three-phase motor (400V) or
M
Output for isolated contact of the 2nd channel
Output for isolated contact of the 2nd channel
Up 80W
N.C. N.O.
**
*
**
Manuals for the installer
single-phase motor ( 230V)
12VAC
12 vac Output (up 1A)
12VAC
12 vac Output (up 1A)
OUT2
OUT2
- Antenna
+ Antenna
*
N.O. N.O. N.O.
Connect this point to the FTS terminal board
for the photo-test otherwise connect it to the
24V terminal board.
Connect to the 24V terminal board for test
GND
ANT
