Turning on and programming the unit
Learning "START" OPENING COMMAND Times
5.1
WARNING!! The gate must be closet.
1
7
4
5
6
Put the DIP5 in ON
2
Press the control START
3
When the gate reach the opening limit switch ( FCO) the engine stops.
4
Let the time goes for the time that the gate should be open.
5
Press the control START to close the gate.
6
Wait until the gate stops.
7
7
4
5
6
Times learning with the "PEDESTRIAN" COMMAND
5.2
The PEDONALE (partial opening control ) can be used to permit the passage for people or small vehicles .
1
7
4
5
6
2
4
5
6
7
7
4
5
6
24
WARNING!! The gate must be closed.
Put the DIP5 in ON
Press the PARTIAL OPENING control.
Press the control PARTIAL OPENING to stop the automation in the point.
Let the time goes for the time that the gate should be open.
Press the PEDESTRIAN partial opening) control to start closing.
Attendere che l'automazione si arresti automaticamente.
Now the working time program is over.
Put the DIP5 in OFF and get back to the standard function
The gate is CLOSED
The gate STARTS OPENING
The gate STOPS
PAUSE TIME
The gate CLOSES.
The gate is CLOSED
The gate is CLOSED
The gate start OPENING.
PAUSE TIME
The gate starts CLOSING.
The gate is CLOSED
