- Page 1 Installation manual Daikin Altherma 3 H HT W https://daikintechnicaldatahub.eu ETBH16DA6V ETBH16DA9W Installation manual ETBX16DA6V English Daikin Altherma 3 H HT W ETBX16DA9W...
- Page 2 3P586469-1A...
-
Page 3: Table Of Contents
2-points curve ............. 23 Latest revisions of the supplied documentation may be available on 6.3.3 Slope-offset curve ............23 the regional Daikin website or via your dealer. 6.3.4 Using weather-dependent curves ....... 24 Settings menu ................24 The original documentation is written in English. All other languages 6.4.1... -
Page 4: About The Box
▪ A subset of the latest technical data is available on the regional Daikin website (publicly accessible). Unit installation ▪ The full set of latest technical data is available on the Daikin Business Portal (authentication required). Preparing the installation site... -
Page 5: Opening And Closing The Unit
2 Reinstall the switch box cover and close the switch box. 3 Reinstall the front panel. NOTICE When closing the indoor unit cover, make sure that the tightening torque does NOT exceed 4.1 N•m. ETBH/X16DA6V+9W Installation manual Daikin Altherma 3 H HT W 4P586453-1B – 2020.01... -
Page 6: Mounting The Indoor Unit
To check the water volume and flow rate Minimum water volume Check that the total water volume in the installation is minimum 20 litres, the internal water volume of the outdoor unit NOT included. Installation manual ETBH/X16DA6V+9W Daikin Altherma 3 H HT W 4P586453-1B – 2020.01... -
Page 7: Third-Party Tank Requirements
4.2.2 To fill the water circuit To fill the water circuit, use a field supply filling kit. Make sure you comply with the applicable legislation. ETBH/X16DA6V+9W Installation manual Daikin Altherma 3 H HT W 4P586453-1B – 2020.01... -
Page 8: To Protect The Water Circuit Against Freezing
Adding glycol to the water circuit reduces the maximum allowed water volume of the system. For more information, see the installer reference guide (topic "To check the water volume and flow rate"). Installation manual ETBH/X16DA6V+9W Daikin Altherma 3 H HT W 4P586453-1B – 2020.01... -
Page 9: To Fill The Domestic Hot Water Tank
For the additional zone: Only for the backup heater of the indoor unit ▪ [3.A] Thermostat type supply" [ 4 12]. "5.3.2 To connect the backup heater power ▪ [3.9] (read-only) Control ETBH/X16DA6V+9W Installation manual Daikin Altherma 3 H HT W 4P586453-1B – 2020.01... - Page 10 Maximum length: 500 m adapter [2.9] Control ▪ Addendum book optional [1.6] Room sensor offset equipment Wires: 2×(0.75~1.25 mm²). Must be sheathed. Maximum length: 200 m See below ("LAN adapter – System requirements"). Installation manual ETBH/X16DA6V+9W Daikin Altherma 3 H HT W 4P586453-1B – 2020.01...
-
Page 11: To Connect The Main Power Supply
1N~, 50 Hz, 230 V AC, 6.3 A Interconnection cable (=main power supply) Normal kWh rate power supply Preferential power supply contact 1 2 3 Interconnection cable (=main power supply) ETBH/X16DA6V+9W Installation manual Daikin Altherma 3 H HT W 4P586453-1B – 2020.01... -
Page 12: To Connect The Backup Heater Power Supply
CAUTION To guarantee the unit is completely earthed, always connect the backup heater power supply and the earth cable. Installation manual ETBH/X16DA6V+9W Daikin Altherma 3 H HT W 4P586453-1B – 2020.01... -
Page 13: To Connect The Shut-Off Valve
4‑pole; 20 A; curve 400 V; tripping class C. K5M Safety contactor (in the switch box) Q1DI Earth leakage circuit breaker (field supply) SWB Switch box X6M Terminal (field supply) ETBH/X16DA6V+9W Installation manual Daikin Altherma 3 H HT W 4P586453-1B – 2020.01... -
Page 14: To Connect The Electricity Meters
2 Connect the alarm output cable to the appropriate terminals as shown in the illustration below. Wires: (2+GND)×0.75 mm² DHW pump output. Maximum load: 2 A (inrush), 230 V AC, 1 A (continuous) Installation manual ETBH/X16DA6V+9W Daikin Altherma 3 H HT W 4P586453-1B – 2020.01... -
Page 15: To Connect The Space Cooling/Heating On/Off Output
3 Switch box 2 Switch box cover 3 Switch box 2 Connect the changeover to external heat source cable to the appropriate terminals as shown in the illustration below. ETBH/X16DA6V+9W Installation manual Daikin Altherma 3 H HT W 4P586453-1B – 2020.01... -
Page 16: To Connect The Power Consumption Digital Inputs
3 Switch box appropriate terminals as shown in the illustration below. 2 Connect the safety thermostat (normally closed) cable to the appropriate terminals as shown in the illustration below. Installation manual ETBH/X16DA6V+9W Daikin Altherma 3 H HT W 4P586453-1B – 2020.01... -
Page 17: Configuration
4 26] ▪ "6.5 Menu structure: Overview installer 6.1.1 To access the most used commands To change the user permission level You can change the user permission level as follows: ETBH/X16DA6V+9W Installation manual Daikin Altherma 3 H HT W 4P586453-1B – 2020.01... -
Page 18: Configuration Wizard
2 Go to [9.I]: Installer settings > Overview settings > Time/date) once the unit is initialised. field settings. 6.2.3 Configuration wizard: System Indoor unit type The indoor unit type is displayed, but cannot be adjusted. Installation manual ETBH/X16DA6V+9W Daikin Altherma 3 H HT W 4P586453-1B – 2020.01... - Page 19 To manually recover it via the user interface, go to the Malfunctioning main menu screen and confirm whether the backup heater and/or booster heater can take over the heat load or not. ETBH/X16DA6V+9W Installation manual Daikin Altherma 3 H HT W 4P586453-1B – 2020.01...
-
Page 20: Configuration Wizard: Backup Heater
50°C, metering and/or power consumption control feature to work properly. Daikin recommends NOT to disable the backup heater When measuring the resistance value of the booster heater, you can second step because it will have a big impact on the... -
Page 21: Configuration Wizard: Main Zone
Define how the operation of the unit is controlled. Emitter type For more info about this functionality, see "6.2.5 Configuration zone" [ 4 21]. wizard: Main ETBH/X16DA6V+9W Installation manual Daikin Altherma 3 H HT W 4P586453-1B – 2020.01... -
Page 22: Configuration Wizard: Tank
Because it reacts more quickly, it prevents high rises and drops of the indoor temperature and water temperature at tap points. Advantage Weather-dependent operation reduces energy consumption. Installation manual ETBH/X16DA6V+9W Daikin Altherma 3 H HT W 4P586453-1B – 2020.01... -
Page 23: 2-Points Curve
The icon corresponds to the heat emitter temperature at X2. for that zone: Slope ▪ : Underfloor heating Offset ▪ : Fan coil unit ▪ : Radiator ▪ : Domestic hot water tank ETBH/X16DA6V+9W Installation manual Daikin Altherma 3 H HT W 4P586453-1B – 2020.01... -
Page 24: Using Weather-Dependent Curves
Main zone – Cooling [2.6] Main zone > Cooling WD thermostat will control the room frost protection. However, curve the room frost protection is only possible if [C.2] Space heating/cooling=On. Installation manual ETBH/X16DA6V+9W Daikin Altherma 3 H HT W 4P586453-1B – 2020.01... -
Page 25: Additional Zone
▪ 2: 2 contacts 6.4.3 Information Dealer information The installer can fill in his contact number here. Code Description [8.3] Number that users can call in case of problems. ETBH/X16DA6V+9W Installation manual Daikin Altherma 3 H HT W 4P586453-1B – 2020.01... -
Page 26: Menu Structure: Overview Installer Settings
Solar kit settings are shown but are NOT applicable for this unit. Settings shall NOT be used or changed. INFORMATION Depending on the selected installer settings and unit type, settings will be visible/invisible. Installation manual ETBH/X16DA6V+9W Daikin Altherma 3 H HT W 4P586453-1B – 2020.01... -
Page 27: Commissioning
Next commissioning instructions in this chapter, a general ▪ Between the local supply panel and the indoor unit commissioning checklist is also available on the Daikin ▪ Between the indoor unit and the valves (if applicable) Business Portal (authentication required). -
Page 28: To Check The Minimum Flow Rate
1 Go to Stop UFH screed dryout. To monitor the temperatures: 2 Select OK to confirm. 1 In the menu, go to Sensors. 2 Select the temperature information. Installation manual ETBH/X16DA6V+9W Daikin Altherma 3 H HT W 4P586453-1B – 2020.01... -
Page 29: Hand-Over To The User
▪ Show the user what to do for the maintenance of the unit. ▪ Explain the user about energy saving tips as described in the operation manual. ETBH/X16DA6V+9W Installation manual Daikin Altherma 3 H HT W 4P586453-1B – 2020.01... -
Page 30: Technical Data
9 Technical data Technical data A subset of the latest technical data is available on the regional Daikin website (publicly accessible). The full set of latest technical data is available on the Daikin Business Portal (authentication required). Piping diagram: Indoor unit... -
Page 31: Wiring Diagram: Indoor Unit
Ext. thermistor External thermistor Terminal strip Heat pump convector Heat pump convector Optional Field supply Position in switch box English Translation Position in switch box Position in switch box ETBH/X16DA6V+9W Installation manual Daikin Altherma 3 H HT W 4P586453-1B – 2020.01... - Page 32 Shut-off valve Switch box (7) Option PCBs (7) Option PCBs Alarm output Alarm output Changeover to ext. heat source Changeover to external heat source Max. load Maximum load Installation manual ETBH/X16DA6V+9W Daikin Altherma 3 H HT W 4P586453-1B – 2020.01...
- Page 33 A11P: X5: 4-5 5 core 2×0.75 A20P: J2 X5M: 11-12 A14P: P1-P2 user interface communication communication A11P: X9: 1-2-3 2 core 2×0.75 A13P: P1-P2 LAN adapter communication 4D124706A ETBH/X16DA6V+9W Installation manual Daikin Altherma 3 H HT W 4P586453-1B – 2020.01...
- Page 36 4P586453-1 B 00000002 4P586453-1B 2020.01 Verantwortung für Energie und Umwelt...
