- Page 1 BAIT & LIVEWELL PUMP MODELS 1500 AND 2000 INSTALLATION AND OPERATION MANUAL pentair.com...
- Page 2 TABLE OF CONTENTS Safety Instruction ....................................3 Installation .......................................4 Operations .......................................5 Troubleshooting ......................................6 911-1000 (10-01-20)
- Page 3 SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS: This manual contains SAFETY INSTRUCTIONS important instructions that should be followed during Always use fuse with amps rating specified on installation, operation, and maintenance of the product. pump label. Failure to do so may result in serious personal Carefully read and follow all safety instructions in this injury, fire hazards and will void the warranty.
- Page 4 INSTALLATION MOUNTING Avoid airlock & maximize performance: Avoid any sagging or loops in the tubing. Tubing must go up from pump to tank. (Suggested installation & operation only. Your installation Use full -flow style valves only. Valve is used to regulate may vary) flow to tank while at rest and while under way (2 different Mount scoop-type thru-hull [high speed pick-up] to hull.
- Page 5 OPERATION Never operate equipment if gasoline fumes are present. Refer to tank size chart for optimal pump size. Note position for later reference. Always test pump before leaving dock. Always remember to adjust valve when at rest or under ...
- Page 6 TROUBLESHOOTING TROUBLESHOOTING Pump will not start or no water: Check electrical connections including fuse, switch and ground connection. Check if voltage is present at the pump. Check for improper fuse rating or wire size. Sea-Cock / thru-hull or valve closed? ...
- Page 7 PAGE INTENTIONALLY LEFT BLANK 911-1000 (10-01-20)
- Page 8 1101 Myers Parkway | Ashland, Ohio, USA 44805 | Ph: 800 854-3218 | pentair.com All indicated Pentair trademarks and logos are property of Pentair. Third party registered and unregistered trademarks and logos are the property of their respective owners. Because we are continuously improving our products and services, Pentair reserves the right to change specifications without prior notice. Pentair is an equal opportunity employer.
