Instruction CF-RP Public (Tamperproof ) Room Thermostat
3. Transmission Test
Initiate transmission test on Room Thermostat
- fig. 1
• Press the push button
• LED
Link test is satisfactory
• LED
Link test is unsatisfactory
• LED
No Link connection to Room Thermostat
• Try to relocate Room Thermostat in the room
• Or install Repeater Unit (CF-RU) and locate be-
tween Master Controller and Room Thermostat
Note: Master Controller output LED(s)
the room thermostat, flash(es) during Link test
4. Mounting
Placing the Room Thermostat - fig. 4
! Wherever possible, the room thermostat should be
installed at a place where the effect of sunlight, draught,
other heaters (eg. TV's), etc. is avoided
Mounting with screws - fig. 2
Back plate
Screw hole for wall mounting
Screw and wall plug
VI.UH.P4.1C
6
goes ON
goes OFF
flashes 5 times
Produced by Danfoss Floor Heating Hydronics 03.2007
connected to
.
