- Page 1 SUNSTAR传感与控制 http://www.sensor-ic.com/ TEL:0755-83376549 FAX:0755-83376182 E-MAIL:szss20@163.com Electrical measurement of mechanical quantities Mounting instructions Absolute pressure transducer SUNSTAR自动化 http://www.sensor-ic.com/ TEL: 0755-83376489 FAX:0755-83376182 E-MAIL:szss20@163.com...
- Page 2 SUNSTAR传感与控制 http://www.sensor-ic.com/ TEL:0755-83376549 FAX:0755-83376182 E-MAIL:szss20@163.com SUNSTAR自动化 http://www.sensor-ic.com/ TEL: 0755-83376489 FAX:0755-83376182 E-MAIL:szss20@163.com...
-
Page 3: Table Of Contents
SUNSTAR传感与控制 http://www.sensor-ic.com/ TEL:0755-83376549 FAX:0755-83376182 E-MAIL:szss20@163.com Contents Page Safety instructions ..........List of components supplied . -
Page 4: Safety Instructions
SUNSTAR传感与控制 http://www.sensor-ic.com/ TEL:0755-83376549 FAX:0755-83376182 E-MAIL:szss20@163.com Safety instructions Use in accordance with the regulations The P6A pressure transducer is to be used exclusively for pressure measurement and directly related control tasks. Any other use is deemed to be not as prescribed. - Page 5 All existing regulations must be complied with. There must be reference to the residual dangers connected with pressure measurement technology. Where residual dangers arise when working with the P6A, these are highlighted in this Manual with the following symbols: DANGER...
- Page 6 SUNSTAR传感与控制 http://www.sensor-ic.com/ TEL:0755-83376549 FAX:0755-83376182 E-MAIL:szss20@163.com Note Symbol: Signifies that important information is being given about the product or the use of the product. Symbol: Meaning: CE mark The CE mark enables the manufacturer to guarantee that the product complies with the requirements of the relevant EC guidelines (see Certificate of Conformance at the end of this User Manual).
- Page 7 SUNSTAR传感与控制 http://www.sensor-ic.com/ TEL:0755-83376549 FAX:0755-83376182 E-MAIL:szss20@163.com Conversions and modifications The pressure transducer must not be modified from the design or safety-engineering point of view without our express agreement. Any modification precludes liability on our part for any damage resulting therefrom. Qualified personnel The pressure transducer must only be installed and operated by qualified personnel strictly in accordance with the technical data relating to the safety requirements and safety rules and regulations below.
-
Page 8: List Of Components Supplied
SUNSTAR传感与控制 http://www.sensor-ic.com/ TEL:0755-83376549 FAX:0755-83376182 E-MAIL:szss20@163.com List of components supplied P6A Absolute Pressure Transducer, User Manual P6A 10 to 500bar: 1 USIT gasket U 12.7 x 20 x 1.5 Also available: -- Cable socket HK6S (for variants with HS6P connector Order no. 3-3312.0095... -
Page 9: Construction And Operating Mode
SUNSTAR传感与控制 http://www.sensor-ic.com/ TEL:0755-83376549 FAX:0755-83376182 E-MAIL:szss20@163.com Parts in contact with the medium are made of 1.4301 and 1.4542 stainless steel. Any fluid or gas (vapour) that does not attack these steels is a suitable measurement medium. The pressure transducer is attached by means of its threaded connector for the pressure connector and can be installed in any position. - Page 10 Caution: Before the P6A pressure transducer is installed or removed, care must be taken to ensure that there is no pressure in the circuit.
-
Page 11: Electrical Connection
(wh) Measuring signal pressure (--) (rd) Sensor circuit green (gn) Sensor circuit (--) grey (gy) Housing / Ground Cable shielding Tab. 5.1: Pin assignment for P6A pressure transducer with connector cable and HS6P connector SUNSTAR自动化 http://www.sensor-ic.com/ TEL: 0755-83376489 FAX:0755-83376182 E-MAIL:szss20@163.com... -
Page 12: Cable Extension
Not assigned Not assigned Cable shielding Fig. 5.2: Pin assignment for connector cable 1-KAB405.30A-3 for the P6A pressure transducer with HS6P device connector If the measuring system has no other connection to ground, earth or mains supply, its zero potential can be connected to the transducer ground by soldering an insulated flexible stranded wire into the HK6S cable socket from the cable shielding to jack Y. -
Page 13: Differential Pressure Measurement Circuit
SUNSTAR传感与控制 http://www.sensor-ic.com/ TEL:0755-83376549 FAX:0755-83376182 E-MAIL:szss20@163.com Measuring cables should not be laid parallel to high-tension and control circuits (e.g. in common cable shafts). If this cannot be arranged, protect the measuring cable with steel conduit and keep it at least 50cm away from other cables. -
Page 14: Measuring Dynamic Pressures
SUNSTAR传感与控制 http://www.sensor-ic.com/ TEL:0755-83376549 FAX:0755-83376182 E-MAIL:szss20@163.com Measuring To get perfect results whenever you are measuring pressure, the correlation between absolute pressure, gauge pressure and atmospheric pressure must be taken into account without fail when setting up the measuring system. The transducers are pressure transducers which, due to their mechanical construction with the hermetically sealed reference chamber, measure absolute pressure only. -
Page 15: Technical Data (In Accordance With Din 16 086)
SUNSTAR传感与控制 http://www.sensor-ic.com/ TEL:0755-83376549 FAX:0755-83376182 E-MAIL:szss20@163.com Technical Data (in accordance with DIN 16 086) Type Accuracy class Measuring range, 0 bar - Natural frequency of the membrane, >100 approx. Mechanical values in accordance with VDI/VDE 2600, by reference to final scale value Operating range at +23˜C 0...200 0...150... -
Page 16: Dimensions (In Mm)
SUNSTAR传感与控制 http://www.sensor-ic.com/ TEL:0755-83376549 FAX:0755-83376182 E-MAIL:szss20@163.com Dimensions (in mm) Version with cable connection Assignment of the cable Cable, 3m, unterminated Size 2 -- BK (black) excitation voltage U 3 + BL (blue) 2’ -- GR (grey) sensor circuits 3’ -- GN (green) ®... - Page 17 SUNSTAR传感与控制 http://www.sensor-ic.com/ TEL:0755-83376549 FAX:0755-83376182 E-MAIL:szss20@163.com M12/M20 adapter Size 32 Material: 1.4305 high-grade steel ® D ® N ® O ® P Type P3M/500/M20 M12x1.5 M20x1.5 20.2 P3M/500/R1/2 M12x1.5 G1/2 20.2 SUNSTAR自动化 http://www.sensor-ic.com/ TEL: 0755-83376489 FAX:0755-83376182 E-MAIL:szss20@163.com...
-
Page 18: Options
HS6P connector Please state length of cable required Corresponds to PT06E-10-6S, supplied by Bendix UPT06J-10-6S, supplied by Cannon Order no.: P6A Typical order P6A-- 0 1 0 B Typical order for 10 bar with D15 connector Order numbers: HK6S cable socket, order no. 3-3312.0095 MS3106A16S-1P connecting plug, order no. - Page 19 SUNSTAR传感与控制 http://www.sensor-ic.com/ TEL:0755-83376549 FAX:0755-83376182 E-MAIL:szss20@163.com Copy of Declaration of Conformity SUNSTAR自动化 http://www.sensor-ic.com/ TEL: 0755-83376489 FAX:0755-83376182 E-MAIL:szss20@163.com...
- Page 20 SUNSTAR传感与控制 http://www.sensor-ic.com/ TEL:0755-83376549 FAX:0755-83376182 E-MAIL:szss20@163.com SUNSTAR自动化 http://www.sensor-ic.com/ TEL: 0755-83376489 FAX:0755-83376182 E-MAIL:szss20@163.com...
- Page 21 SUNSTAR传感与控制 http://www.sensor-ic.com/ TEL:0755-83376549 FAX:0755-83376182 E-MAIL:szss20@163.com SUNSTAR自动化 http://www.sensor-ic.com/ TEL: 0755-83376489 FAX:0755-83376182 E-MAIL:szss20@163.com...
- Page 22 SUNSTAR传感与控制 http://www.sensor-ic.com/ TEL:0755-83376549 FAX:0755-83376182 E-MAIL:szss20@163.com SUNSTAR自动化 http://www.sensor-ic.com/ TEL: 0755-83376489 FAX:0755-83376182 E-MAIL:szss20@163.com...
- Page 23 SUNSTAR传感与控制 http://www.sensor-ic.com/ TEL:0755-83376549 FAX:0755-83376182 E-MAIL:szss20@163.com SUNSTAR自动化 http://www.sensor-ic.com/ TEL: 0755-83376489 FAX:0755-83376182 E-MAIL:szss20@163.com...
- Page 24 Im Tiefen See 45, D-64293 Darmstadt express warranty and do not constitute any Tel.: +49 / 61 51 / 8 03-0; Fax: +49 / 61 51 / 89 48 96 liability whatsoever. http://www.hbm.de im- -d6.97- -0pod- -e SUNSTAR自动化 http://www.sensor-ic.com/ TEL: 0755-83376489 FAX:0755-83376182 E-MAIL:szss20@163.com...
