Summary of Contents for Yazoo/Kees KKFW48180, KKFW52180, KKFW52210
Page 1
Operators Manual Please read these instructions carefully and make sure you understand them before using the machine. MANUAL NO. 107110 REV. IR (10/10/02) Models: KKFW48180 KKFW52180 KKFW52210...
Page 2
Congratulations on the purchase of your Yazoo/Kees mower. This manual has been prepared for the owners and operators of the Hydro Floating Deck 48" and 52" commercial mowers. Read, understand and follow the saftey and operating instructions. Failure to follow cautious operating practices can result in serious injury to the operator or other persons.
STAY A SAFE DISTANCE FROM THE MACHINE RISK OF SEVERING OF TOES OR FINGERS MOWER BLADES READ OPERATORS MANUAL BEFORE OPERATING MACHINE DO NOT OPEN OR REMOVE SAFETY SHIELDS WHILE ENGINE IS RUNING RISK OF SEVERING OF TOES OR FINGERS MOWER BLADES CHEMICAL BURN HAZARD SAFETY DECALS...
TRAINING: 1. Read this manual carefully and question your dealer if something is not clear. 2. Be thoroughly familiar with the controls and proper use of the equipment. 3. Never allow children, teenagers, or people unfamiliar with these instructions to use the mower.
4. To reduce the risk of fire, keep the mower free of grass, leaves and excessive grease or oil. 5. Have your mower inspected and serviced each year by an authorized Yazoo/Kees dealer. 6. Use only authentic Yazoo/Kees replacement parts to insure the safety and quality of your mower is maintained.
EQUIPMENT SETUP AND ADJUSTMENTS 1. Uncrate mower 2. Cut the plastic wire ties holding the operator presence levers down. 3. Check tire pressure in all four tires. (22 PSI in all tires) 4. Check engine oil with dipstick. Add if needed per engine manufactures specifications.(See engine manual) 5.
1. This adjustment must be made with the drive wheels rotating. Raise rear of the unit and block it up so the wheels are free to rotate. CAUTION: keep hands, feet and clothing away from rotating tires. 2. With the ground speed lever in neutral or stop position, start the engine. 3.
REVERSE SPRING DETENT ADJUSTMENT 1. To check if your reverse spring detent adjustment is set right. Make sure your ground speed lever is pulled back to the neutral position. Release the thumb latchs(both sides) and pull up on the control levers at the same time. Then release the levers, it should return to neutral. If it does not, the following adjustmtents need to be made.
MOWER DECK LEVELING: 1. Position mower on a flat surface and stop engine. 2. Check the tire pressure of all four tires. Inflation should be 22 psi. 3. Place two 2x4’s on edge under the blades from side side and lower the deck down onto the 2x4’s.
1. Before performing adjustments on pump belt, turn the mower off and disconnect spark plug wire or wires. 2. Check tension on the belt. If it feels loose adjustment will need to be made. 3. Loosen the nut on the bottom of the idler pulley. 4.
CONTROLS: Be thoroughly familiar with all controls their function and how to operate them before operating the mower. 1. Control levers: Located on each side of the handle control direction of movement. The left lever controls the flow of oil from the left hydro pump to the left wheel motor. The right lever controls the flow of oil from the right hydro pump to the right wheel motor.
3. Blade engagement switch: Located on the left side of the console. To engage the blades pull up on the switch. Push down on the switch to disengage the blades. 4. Choke and throttle control: Located on the right side of the console. Push the throttle control all the way forward for choke.
1. Engine oil level: Check daily with engine cold and on a flat surface. Remove the dipstick and wipe clean. Reinsert the dipstick all the way,but do not screw down. Remove the dipstick and check oil level. If oil level is low add oil. Use engine manufacturers specs for type of oil. 2.
Then replace with new filter. Use only Yazoo/Kees p/n 102606, filter which has a bypass valve and the correct micron filter. Remove the cap nut from the bottom of the tank and allow the tank to drain, reinstall the cap nut.
CUTTER HOUSING SPINDLE ASSEMBLYS The cutter housing assembly is designed with a slip fit inner race and pulley. The sole purpose of the setscrew in the pulley is to hold the housing assembly together. The setscrew is not ment to secure the pulley. The pulley is secured by pinching the pulley to the inner race of the bearings using the blade bolt and nut.
PROBLEM Engine won’t start Mower will not move or moves slowly or hard Blades won’t engage Uneven cut Cut is ragged Mower moves when in neutral position Mower pulls left or right When a problem occurs, do not overlook the simple causes. TROUBLE SHOOTING POSSIBLE CAUSES 1.
Peerless model 700 transmissions (first ninety days warranted by Peerless, remainder by Yazoo/Kees). In the event that any Yazoo/Kees Product warranted hereunder shall be defective or fail to conform with this limited warranty, Yazoo/Kees shall, subject to the provisions hereof, pay for, or provide labor and materials for, the repair or replacement of such defective Yazoo/Kees Product.
Page 20
LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU. This warranty is not subject to change or modification by anyone, including Yazoo/Kees dealers or distributors, and no Yazoo/Kees dealer or distributor is authorized to make any representa- tions on behalf of Yazoo/Kees Power Equipment.
