Each rotary mower is equipped with a serial plate; see Figure 1.3 that includes the following data in this order:
- EC Marking.
- Manufacturer marking.
- Name and address of the manufacturer.
- Machine Whole Goods Code (WGC).
- Machine Product Group Code.
- Serial number of the machine.
- Year of construction.
- Mass in kg.
- Model year.
Machine
Whole Goods
Code (WGC)
Machine Serial
Number
Weight (kg)
Data on the manufacturer's plate should always be referred to when requesting assistance and/or supply of spare
parts.
This data can identify the rotary mower and its characteristics, certifying that it responds to current regulations. For this
reason the plate should never therefore be removed nor be used for other purposes; if the rotary mower is dismantled,
it should be destroyed to prevent any form of abuse.
1.4

Machine general specification

Agricut Series (1)
A Overall Length
B Overall Width
C Overall Height (max)
D Deck Width
Weight
Number of Rotors
Number of Blades
Cutting Width
Linkage Mounting
P.T.O Speed
Power Requirements
Cutting Height
Notes:
(1) Spearhead constantly reviews and improves product designs and reserve the right to change this
information. Actual machines may vary from the above specification. Contact your Spearhead Sales
representative if you have any queries.
Supplier Information
Product Group Code
Production Year
Model Year
Agricut 240 Offset
4366mm
1856mm
1060mm
2679mm
22kW (30hp) at P.T.O.
Figure 1.4
Page 1.9 of 1.9 pages
8999070: v3 03/09/2018
Figure 1.3
See Figure 1.4
540kg
2
4
2400mm
Cat II
540rpm
30-150mm
