Campbell Hausfeld Water Wizard PW7005 Operating Instructions And Parts Manual

See Warranty on page 2 for important information about commercial use of this product.
Operating Instructions and Parts Manual
BUILT TO LAST
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain
the product described. Protect yourself and others by observing all safety information. Failure to comply with
instructions could result in personal injury and/or property damage! Retain instructions for future reference.
Operating Instructions
Quick-Connect
Garden
hose
Figure 1
1. Pole telescopes for longer reach. Loosen nut
(Figure 1), adjust Pole to desired length,
retighten nut.
2. To use Detergent Dispenser (Figure 2),
unscrew Detergent Bottle and pour desired
amount of liquid detergent or wax into it.
Screw Detergent Bottle onto Detergent
Dispenser.
During operation, you can start or stop the
release of the detergent or wax by turning
the Detergent Release Valve On or Off
(Figure 3).
Safety Section
Pole conducts electricity! Watch
DANGER
!
for overhead wires. Avoid
power lines.
• Never place eyes or face close to water spray
or attachments.
• Keep away from children.
• This product is not intended for recreational
use by children.
• Do not drink from this device.
• To prevent water supply contamination, only
use this product when back flow prevention
device is present.
• To protect fine surfaces, only use a clean soft
bristle brush.
REMINDER: Keep your dated proof of purchase for warranty purposes! Attach it to this manual or file it for safekeeping.
© 2003 Campbell Hausfeld
Water Wizard
Cleaning Brush Kit
Figure 2
Figure 3
For parts, product & service information
visit www.chpower.com
Pole
Detergent
Dispenser
Detergent
Bottle
On/Off
Valve
Detergent Release Valve
PW7005
Brush
Nut
Screw
Detergent
Bottle onto
Detergent
Dispenser
Off
On
IN462900AV 6/03
