LIGHT MY BRICKS Downtown Diner Lighting Kit Installation Instructions Manual

Led light kit for lego 10260
Hide thumbs

Advertisement

Quick Links

Download this manual
Light My Bricks
Installation Instructions for Light My Bricks LED Lighting Kits
Mar 1
28 min read
·
·
Light My Bricks: Downtown Diner
Lighting Kit
The following page is instructions for the Light My Bricks LEGO
Downtown Diner (10260) LED light kit. You purchase this kit on our
o cial website.
To ensure a trouble-free installation of your light kit, please read and
follow each step carefully.
If you run into any issues, please refer to the online troubleshooting
guide.
This user guide is also available to download in PDF format here.
