INSTALLATION AND SERVICE MANUAL
SUBMERSIBLE
SX SERIES PUMPS
MYERS
NOTE! To the installer: Please make sure you provide this manual to the owner of the equip ment or to the responsible
party who maintains the system.
Item # M1057 | © 2018 Pentair plc | 09/27/18
ENGLISH: PAGES 2-16
Installation and Service Manual
NOTE! To the installer: Please make sure you provide
this manual to the owner of the equip ment or to the
responsible party who maintains the system.
The submersible SX Series pumps are CSA approved for
use in Class I, Division 1, Group D hazardous locations in
wastewater and storm water applications. The SX Series
pumps are not intended for applications requiring
the pumping of flammable liquids. A triplex system is
recommended to reduce the possibility of concentrations of
flammable/hazardous liquids entering the main lift station.
Models
SX
Series
(Class I, Division 1, Group D)
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Pentair MYERS SX Series
Summary of Contents for Pentair MYERS SX Series
- Page 1 MYERS NOTE! To the installer: Please make sure you provide this manual to the owner of the equip ment or to the responsible party who maintains the system. Item # M1057 | © 2018 Pentair plc | 09/27/18...
-
Page 2: California Proposition 65 Warning
WARNING! IMPORTANT SAFETY INSTRUCTIONS! READ CAREFULLY BEFORE INSTALLATION. This manual contains important information for the safe use of this product. Read this manual completely before using this product and refer to it often for continued safe product use. DO NOT THROW AWAY OR LOSE THIS MANUAL. - Page 3 These pumps are to be used for handling septic tank effluent, pump torques upon initial starting. A properly rotating pump will sewage, and storm water only. Do not use in other hazardous torque counterclockwise upon start. locations. These motors must be repaired and serviced only at a Myers authorized service center or at the Myers factory.
-
Page 4: Troubleshooting
TROUBLESHOOTING PROBABLE CAUSE CONDITION This indicates some water has leaked past the lower seal and has entered Red light comes on at control box. the seal chamber and made contact with the electrode probe. Pump must be removed for replacement of lower seal. This preventive repair will save an expensive motor. - Page 5 SX Series Standard Configurations SOLIDS Cord DISCHARGE Weight MODEL UPC # ENG. NO. HP VOLTS PHASE Amps HANDLING IN. SWITCH Length Ft. IN. (mm) Lbs. (kg) (mm) SX50-21 054128305264 26857E611 2" (50.8) 2" (50.8) 20' (6.1) 83 (37.6) SX50H-21 054128305271 26858E611 1-1/2"...
- Page 6 SX50 DIMENSIONS [Dimensions in mm] SX50H, SX150H and SX200H DIMENSIONS [Dimensions in mm]...
- Page 7 SX50 PUMP PARTS...
- Page 8 SX50H PUMP PARTS...
- Page 9 SX150H and SX200H PUMP PARTS...
- Page 10 SX SERIES PARTS LIST Ref. Description Qty. SX50 SX50H SX150H/SX200H CAP, CORD 22407C602 22407C602 22407C602 CONNECTOR 12762A001 12762A001 12762A001 TUBE, PLASTIC x 1-1/4" LG. 10649A102 10649A102 10649A102 SCREW, CAP 5/16 x 1-1/4" LG. 19100A012 19100A012 19100A012 O-RING, 4-1/2" x 4-1/4" x 1/8" 05876A122 05876A122 05876A122...
-
Page 11: Wiring Diagrams
WIRING DIAGRAMS " CORD CONNECTORS " " NOTE: All components shown must be approved for hazardous locations. - Page 12 WIRING SCHEMATIC FOR 208/230V, 1Ø SIMPLEX SYSTEM SX50/SX50H ONLY...
-
Page 13: Wiring Diagram
WIRING DIAGRAM 200 OR 200 OR 575 VOLT - THREE PHASE WIRING SCHEMATIC FOR 208/230, 1, Simplex 7263 0118... - Page 14 WIRING SCHEMATIC FOR 3Ø SIMPLEX SYSTEM...
- Page 15 Limited Warranty Myers warrants to the original consumer purchaser (“Purchaser” or “You”) of the products listed below, that they will be free from ® defects in material and workmanship for the Warranty Period shown below. Warranty Period Product whichever occurs first: Jet pumps, small centrifugal pumps, submersible pumps and 12 months from date of original installation, related accessories...
