INSTALLATION INSTRUCTION
ULTRAPURE ARAGON 10" TWIN UNDER SINK WATER
FILTER SYSTEM WITH ALKALINE
Thank You for trusting us with your Water Filtration needs.
Please read and follow the steps below on setting up your Product.
Ensure you check you have received ALL the correct components before you
call & arrange the plumber or any installation just in the unexpected case that
you have a missing part.
If you need any help, please call us at 1800-769-300 or contact us through our
website at www.mywaterfilter.com.au/contacts/ or email us at customerservice@
mywaterfilter.com.au

Advertisement

loading
Need help?

Need help?

Do you have a question about the ULTRAPURE ARAGON and is the answer not in the manual?

Questions and answers

Related Manuals for My Water Filter ULTRAPURE ARAGON

Summary of Contents for My Water Filter ULTRAPURE ARAGON

  • Page 1 INSTALLATION INSTRUCTION ULTRAPURE ARAGON 10” TWIN UNDER SINK WATER FILTER SYSTEM WITH ALKALINE Thank You for trusting us with your Water Filtration needs. Please read and follow the steps below on setting up your Product. Ensure you check you have received ALL the correct components before you call &...
  • Page 2 PARTS...
  • Page 3 FAUCET PARTS...

  • Page 4: Before You Start

    BEFORE YOU START Things you will need: ü ü ü Plumber Thread Tape Sharp Knife ü Electric Drill ü Spanners ü Screwdriver 3 Easy Steps to Install: 1. Install system 2. Install faucet 3. Flush system & cartridges - Now Ready to use. NOTE: DO NOT FLOW ANY WATER THROUGH THE SYSTEM OR THE CARTRIDGES UNTIL THE CORRECT STEP 3.

  • Page 5: Installation Diagram

    INSTALLATION DIAGRAM SAME FOR SINGLE, TWIN OR TRIPLE WATER FILTERS...
  • Page 6 1. EASY INSTALLATION GUIDE CLICK HERE TO WATCH THE VIDEO Get a towel and put it inside the cupboard. This will help to absorb water in case there’s spillage or leaks while working. Turn off the cold water supply via the angle stop valve under the sink or at the water metre out the front of the property.
  • Page 7 Wrap some thread tape around the male thread of the connector, then screw on the provided t-piece connector by turning clockwise via the swivel female end. Use a spanner to tighten. Make sure that the push- in hose end of the t-piece is facing the location where the under sink water filter unit will be mounted.
  • Page 8 2. HOW TO INSTALL THE UNDER SINK FAUCET Before you start, take some time to ensure there are no hazards or electricity that can harm you. Ensure you are competent, otherwise, ask for assistance from a qualified person. Select the best position where you would like to install your drinking water faucet on your sink or benchtop.
  • Page 9 Your water filter is now installed. Please read the How to Flush your ULTRAPURE Aragon 10” Twin Under Sink Water Filter System with Alkaline before you flow any water into your system and inspect for leaks at that time.
  • Page 10 3. HOW TO FLUSH YOUR UNDER SINK WATER FILTER: Connect your water filter as required. DO NOT TURN ON THE WATER YET CARTRIDGE POSITIONS: Aragon Cartridge - position 1 Alkaline cartridge - position 2 Use the housing opening tool and open the two housings, remove any cartridge packaging from each cartridge if not already removed.
  • Page 11 HOW TO CHANGE CARTRIDGES Turn off the t-piece cold water supply valve under the sink. Turn on the faucet. This will drain the remaining water & release any pressure built up inside the under sink water filter system. Get a towel and put it inside the under-sink cupboard floor. This will help to absorb water in case there’s spillage or leaks while working.
  • Page 12 Remove the old cartridges and discard into the rubbish bin. Get the new cartridges and remove the packaging for both cartridges if not already removed. Unscrew the end plug from the Aragon cartridge. Ensure there is a washer on each end of the Aragon cartridge then insert the cartridge into the housing.
  • Page 13 For Customer Service. Call us at 1800-769-300 My Water Filter Pty Ltd...
