My Water Filter ULTRAPURE Aragon Installation Instruction

10" twin under sink water filter system with fluoride removal
Hide thumbs Also See for ULTRAPURE Aragon:

Advertisement

Quick Links

Download this manual
Installation Instruction
ULTRAPURE Aragon 10" Twin Under Sink Water Filter
System with Fluoride Removal
Thank You for trusting us with your Water Filtration needs.
Please read and follow the steps below on setting up your Product.
If you need any help, please call us at 1800-769-300 or contact us through our website
at ​
w ww.mywaterfilter.com.au/contacts/​
or email us at
customerservice@mywaterfilter.com.au

Advertisement

loading
Need help?

Need help?

Do you have a question about the ULTRAPURE Aragon and is the answer not in the manual?

Questions and answers

Related Manuals for My Water Filter ULTRAPURE Aragon

Summary of Contents for My Water Filter ULTRAPURE Aragon

  • Page 1 Installation Instruction ULTRAPURE Aragon 10" Twin Under Sink Water Filter System with Fluoride Removal Thank You for trusting us with your Water Filtration needs. Please read and follow the steps below on setting up your Product. If you need any help, please call us at 1800-769-300 or contact us through our website at ​...
  • Page 2 Parts...
  • Page 3 Faucet Parts...

  • Page 4: Before You Start

    Before you start Things You Will Need: Plumber Thread Tape Sharp knife Electric Drill Spanners Screwdriver 3 Easy Steps to Install: 1. Install system 2. Install faucet 3. Flush system & cartridges - Now Ready to use. NOTE: DO NOT FLOW ANY WATER THROUGH THE SYSTEM OR THE CARTRIDGES UNTIL THE CORRECT STEP 3.

  • Page 5: Installation Diagram

    Installation Diagram...
  • Page 6 1. Easy Installation Guide Click Here to Watch the Video 1. Get a towel and put it inside the cupboard. This will help to absorb water in case there's spillage or leaks while working. 2. Turn off the cold water supply via the angle stop valve under the sink or at the water metre out the front of the property.
  • Page 7 connector of the hose. (See diagram below) 6. Place the water filter into position (Ensure you have a minimum of 30mm of space under the water filter housing so you are able to remove the housings to replace the cartridges when required) Drill 2 x holes in accordance with the mounting holes of the under sink bracket.
  • Page 8 2. How to Install the Under Sink Faucet: 1. Before you start, take some time to ensure there are no hazards or electricity that can harm you. 2. Ensure you are a competent installer, otherwise, ask for assistance from a plumber. 3.
  • Page 9 8. Insert the escutcheon plate of the faucet onto the faucet shaft, then the escutcheon rubber washer. 9. Insert the faucet shaft through the newly drilled hole. Once the faucet is in the hole, insert the rubber washer onto the faucet shaft from under the sink, then the lock washer, then screw on the lock nut provided.
  • Page 10 Your water filter is now installed. Please read the ​ H ow to Flush your ULTRAPURE Aragon 10" Twin Under Sink Water Filter System with Fluoride Removal ​ b efore you flow any water into your system and inspect for leaks at that time.
  • Page 11 3. How to Flush your Under Sink Water Filter: 1. Connect your water filter as required. ​ D O NOT TURN ON THE WATER YET CARTRIDGE POSITIONS​ : Fluoride Removal Cartridge - position 1 Aragon Cartridge - position 2 2. Get the housing opening tool and open the two housings, remove any cartridge packaging if not already removed before installing each cartridge as below.
  • Page 12 How to Change Cartridges: Click Here to Watch the Video 1. Turn off the t-piece cold water supply valve under the sink. 2. Turn on the faucet. This will drain the remaining water & release any pressure built up inside the under sink water filter system. 3.
  • Page 13 5. Turn the housing opening tool to the left until the seal breaks open. Now turn by hand until the housing is removed. NOTE​ : There might be water left inside the housing, Please avoid spilling it onto the floor. Drain the water into the kitchen sink. 6.
  • Page 14 CARTRIDGE POSITIONS​ : Fluoride Removal Cartridge - position 1 Aragon Cartridge - position 2 7. Ensure the Fluoride Removal Cartridge is installed into position 1 and remove the cartridge from position 2. 8. Screw back on the two housings and tighten. ENSURE NO CARTRIDGE​...
  • Page 15 11. Turn on the water and flush both the cartridges for 5 minutes straight. 12.​ ​ Y ou can get a bucket to save the water being flushed for the plants if preferred. The unit is now ready for use. NOTE​...
  • Page 16 For Customer Service. Call us at 1800-769-300 My Water Filter Pty Ltd...
