Quick reference
31.4001.02 Starter set with temperature sensor
Download App
Download the WeatherHub app from the „Apple App Store" or „Google Play Store".
Connect the Gateway
Connect the gateway to the power supply using the enclosed AC power adaptor. Connect the included LAN cable to the gateway and your
router. After about 10 seconds, the gateway is in operation. The LED will turn static green. If no DHCP server is available in your network,
you can configure the gateway in the app under „Settings" manually. If the gateway's green LED is not permanently lit, please check
whether the gateway is properly connected to the AC power adaptor and the router, or if it is turned on and connected to the Internet.
(More information can be found on the app under „Info").
Important: The gateway should always be put into operation before starting the sensors!
Set up transmitter
Set up the temperature transmitter as described in the specific device's manual and look for a suitable location.
Add sensor
Open the app, the dashboard is displayed. The sample sensors are for testing purposes only and may be deleted later on. Tap „Add" new
sensor and scan the sensor's QR code. Then set a name for the sensor. To set a name, select the transmitter and then tap the area left of
the pencil icon on the top right corner of the screen.
Read measurements
Now you can read the measured values on your mobile phone.
Troubleshooting
If no sensor readings are displayed on the app, check first whether the gateway's green LED is permanently lit.
(See „Connect the gateway").
If the gateway works properly, but the problem persists, we recommend the following steps:
•
Check if the sensor batteries are inserted with the correct polarity.
•
Restart the sensor by removing the batteries for a minute and reinserting them.
•
Check if your phone is connected to the internet.
•
Decrease the distance between sensor and gateway. The signal may be weakened by thick
walls and ceilings.
•
More information can be found on the app under „Info".
Specifications
Power supply:
Power adapter (included)
Input power adapter:
100-240 V~, 50/60 Hz, 0,3A Max
Output power adapter:
4 V⎓, 0,3A, 1,2W
Average active efficiency:
68,13%
No-load power consumption:
< 0,1W
Network connection:
LAN (RJ45)
Transmission frequency:
868 MHz
Maximum radio-frequency power:
< 25mW
Further specification can be found in the temperature transmitter manual (30.3300.02).
Waste disposal
This product has been manufactured using high-grade materials and components which can be recycled
and reused.
Do not dispose of batteries or rechargeable batteries in the household waste!
As a consumer, you are legally required to take them to your retail store or to appropriate
collection sites according to national or local regulations in order to protect the environment.
The symbols for the heavy metals contained are: Cd=cadmium, Hg=mercury, Pb=lead
This instrument is labelled in accordance with the EU Waste Electrical and Electronic Equipment Directive (WEEE). Please
do not dispose of this product with other household waste. The user is obligated to take end-of-life devices to a designat-
ed collection point for the disposal of
electrical and electronic equipment, in order to ensure environmentally-compatible disposal.
EU Declaration of conformity
Hereby, TFA Dostmann declares that the radio equipment type 31.4001.02 is in compliance with Directive 2014/53/EU. The full text of
the EU declaration of conformity is available at the following internet address:
www.tfa-dostmann.de/service/downloads/ce
TFA Dostmann GmbH & Co.KG, Zum Ottersberg 12, D-97877 Wertheim, Germany
Commercial registration number: Reg. Gericht Mannheim HRA 570186
No part of this manual may be reproduced without written consent of TFA Dostmann.
The technical data are correct at the time of going to print and may change without prior notice.
The latest technical data and information about your product can be found by entering
your product number on our homepage.
More information and detailed instructions can be found in the app at "Info" or on
www.tfa-dostmann.de/weatherhub.
03/2020
