Thank you for choosing this wireless weather station from TFA.

BEFORE YOU USE IT

Please be sure to read the instruction manual carefully.
This information will help you to familiarise yourself with your new device, learn all of its
functions and parts, find out important details about its first use and how to operate it, and
get advice in the event of faults.
Following the instruction manual for use will prevent damage to the device and loss of your
statutory rights arising from defects due to incorrect use.
We shall not be liable for any damage occurring as a result of not following these
instructions.
Please take particular note of the safety advice!
Please look after this manual for future reference.

SCOPE OF SUPPLY:

Weather station (basic unit)
•
Outdoor transmitter
•
Batteries 5 x AA, IEC LR6, 1.5V
•
Instruction manual
•
FIELD OF OPERATION AND ALL OF THE BENEFITS OF YOUR NEW
WEATHER STATION AT A GLANCE:
DCF Radio controlled time with manual setting option
•
Time reception ON/OFF (user selectable)
•
12/24 hour time display
•
Time zone option ±12 hours
•
Weekday and day calendar display (year and month only in setting mode)
•
Alarm setting with snooze function
•
Display 12 Moon phases throughout the year
•
Weather forecasting with weather tendency indicator
•
Indoor comfort indicator
•
Temperature display in ºC/ºF
•
Indoor and outdoor temperature display with MIN/MAX records and time of reception
•
Humidity data display as RH%
•
Indoor and outdoor humidity display with MIN/MAX records
•
Relative air pressure hPa/ inHg with adjustable reference value
•
Weather icon sensitivity setting
•
Relative air pressure history for the past 24 hours (electronic barometer with
•
barometric pressure trend)
LCD contrast selectable
•
Wireless transmission at 868 MHz
•
Signal reception intervals at 4 seconds
•
Can receive up to 3 outdoor transmitters
•
LED back light
•
Low battery indicator
•
Table standing or wall mounting
•
WEATHER STATION
Instruction Manual
Cat. No. 35.1045.IT
19

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Weather Station and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TFA Weather Station

Summary of Contents for TFA Weather Station

  • Page 1: Weather Station

    WEATHER STATION Instruction Manual Cat. No. 35.1045.IT Thank you for choosing this wireless weather station from TFA. BEFORE YOU USE IT Please be sure to read the instruction manual carefully. This information will help you to familiarise yourself with your new device, learn all of its functions and parts, find out important details about its first use and how to operate it, and get advice in the event of faults.
  • Page 2 Do not expose the instrument to extreme temperatures, vibration or shock. • The outdoor transmitter is protected against splash water, but is not watertight. Choose • a shady and dry position for the transmitter. ELEMENTS Weather Station Hanging hole Battery LCD Display compartment Stand...
  • Page 3 This is due to a random security code assigned by the transmitter at start-up. This code must be received and stored by the weather station in the first 3 minutes of power being supplied to the transmitter.
  • Page 4 The outdoor temperature and humidity from the second transmitter and the "channel 2" icon should then be displayed on the weather station. If this does not happen after 2 minutes, the batteries will need to be removed from all the units and reset from step 1.
  • Page 5 A single daily reception is adequate to keep the accuracy deviation below 1 second. FUNCTION KEYS: Weather station: The weather station has 5 easy to use function keys: IN key OUT/+ key ALM/DATE key SET key...
  • Page 6 ºC/ ºF Outdoor relative humidity in RH% * When the signal is successfully received by the weather station, the outdoor transmission icon will be switched on. (If not successful, the icon will not be shown on LCD). The user can...
  • Page 7 TIME ZONE SETTING: Flashing The time zone default of the Weather Station is “0”. To set a different time zone: The current time zone value starts flashing. Use the OUT/+ key to set the time zone. The range runs from 0 to -12 and then runs from +12 back to 0 in consecutive 1-hour intervals.
  • Page 8 Date and month (24hr time format) Month and date (12hr time format) The date default of the weather station is 1. 1. 2011. Once the radio-controlled time signals are received, the date is automatically updated. However, if the signals are not received, the date can also be set manually.
  • Page 9 Press the SET key again to confirm and to enter the month setting. The month starts flashing. Use the OUT/+ key to set the month. Press the SET key again to confirm and to enter the date setting mode. The date starts flashing.
  • Page 10 SNOOZE/CH key. To stop the alarm, press any key during alarm ringing, except the SNOOZE/CH key. MOON PHASES SYMBOL The Moon icon of the weather station will also display all 12 Moon phases throughout the year according to the set calendar.
  • Page 11 Large Waxing Small Waxing Small Waxing Large Waxing New Moon First Quarter Crescent Crescent Gibbous Gibbous Small Waning Large Waning Small Waning Large Waning Full Moon Last Quarter Crescent Crescent Gibbous Gibbous INDOOR RELATIVE HUMIDITY AND INDOOR TEMPERATURE: The indoor temperature and humidity data, the indoor comfort indicator are automatically updated and displayed on the second section of the LCD.
  • Page 12 After setting up, readings for weather forecasts should be disregarded for the next 12-24 hours. This will allow sufficient time for the Weather station to collect air pressure data at a constant altitude and therefore result in a more accurate forecast.
  • Page 13 “0h“. Note: For accurate barometric pressure trends, the Weather Station should operate at the same altitude for example, it should not be moved from the ground to the second floor of the house.
  • Page 14 When the 868MHz signal is received correctly, do not re-open the battery cover of either the transmitter or Weather station, as the batteries may spring free from the contacts and force a false reset. Should this happen accidentally then reset all units (see “Setting up” above) otherwise transmission problems may occur.
  • Page 15 • No transmitter reception Check batteries of external transmitter (do not use • Display "---" rechargeable batteries!) Restart the transmitter and weather station as per the • manual Choose another place for the transmitter and/or the • weather station Reduce the distance between the transmitter and the •...
  • Page 16 TFA Dostmann GmbH & Co. KG, Zum Ottersberg 12, D - 97877 Wertheim No part of this manual may be reproduced without written consent of TFA Dostmann. The technical data are correct at the time of going to print and may change without prior notice.
