Bticino Living Now with Netatmo Installation Manual

Bticino Living Now with Netatmo Installation Manual

Hide thumbs

Advertisement

Table of Contents

Living Now with Netatmo
Installation Manual
www.bticino.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Living Now with Netatmo and is the answer not in the manual?

Questions and answers

Related Manuals for Bticino Living Now with Netatmo

Summary of Contents for Bticino Living Now with Netatmo

  • Page 1 Living Now with Netatmo Installation Manual www.bticino.com...
  • Page 2 Living Now with Netatmo Installation Manual...

  • Page 3: Table Of Contents

    Living Now with Netatmo Installation Manual Contents General features Install Living Now with Netatmo Associate the connected devices Add a connected device Add a wireless scenario control Associate a wireless light/rolling shutter control to one or more modular connected devices...

  • Page 4: General Features

    Living Now with Netatmo Installation Manual General features The Gateway allows you to create your Smart electric system by associating together all the connected devices of the Living Light with Netamo range and light relays. Supplied as standard is also the wireless master IN&OUT scenario control, item L/N/NT4570CW, required for the association of all the connected devices and for the activation of the “IN”...

  • Page 5: Install Living Now With Netatmo

    Living Now with Netatmo Installation Manual Install Living Now with Netatmo 1. Disconnect the voltage from the general switch. Check that the system is not powered. It is now possible to connect all your system devices as per the following diagrams.
  • Page 6 Living Now with Netatmo Installation Manual * provided with Connected K4411CM2 dimmer Compensator * K4411CM2 Connected Traditional Traditional Connected two-way switch intermediate two-way two-way switch K4003C switch switch K4003C Measurement toroid Wireless In&Out master scenario control K4570CW AS AN ALTERNATIVE Wireless In&Out...
  • Page 7 Living Now with Netatmo Installation Manual 2. Reconnect the power using the general switch. Check that the LEDs of all the devices turn on red steady (with the exception of the wireless LEDs, which will be off ).
  • Page 8 Living Now with Netatmo Installation Manual After installing the Smart electric system, it will be possible to locally control lights and rolling shutters without further set up needed. Note: connected sockets will be powered by default. It is now possible to associate all the devices and take advantage of the connected functions of...

  • Page 9: Associate The Connected Devices

    Living Now with Netatmo Installation Manual Associate the connected devices Wait 1 minute for correct system start-up, after which complete the following association procedure within 15 minutes from powering. If this time is exceeded, disconnect and then reconnect the power.
  • Page 10 Living Now with Netatmo Installation Manual K4570CW Master, wireless In&Out scenario control 1. Remove the tab from the wireless control (K4570CW Master) in K4500C – KG/KW/KM4501C – KG/KW/KM4502C. Note: after re-powering the system always wait at least one minute. 2. Fit the cover and the plate on the wireless control.
  • Page 11 Living Now with Netatmo Installation Manual K4500C Gateway KG/KW/KM4501C Gateway KG/KW/KM4502C Gateway The Gateway LED goes from red to off. K4570CW Master, wireless In&Out scenario control 4. Start the association: press and hold down the two control keys at the same time, the LED will turn green, the LED...
  • Page 12 Living Now with Netatmo Installation Manual Check that the LEDs of all the devices turn green steady (with the exception of the wireless LEDs, which will be off ). Note: the LEDs may take up to 15 minutes to turn from red to green.
  • Page 13 Living Now with Netatmo Installation Manual Check that the LEDs of all the devices immediately turn off: the connected devices are now associated with each other. Note: if the LEDs of any devices stay red, disconnect the power from the system, reconnect it, wait a...
  • Page 14 Living Now with Netatmo Installation Manual After associating the K4570CW Master wireless scenario control, it is possible to activate the IN/ OUT scenarios that can be controlled by the same. K4570CW upper key for scenario. Shutters SU No effect on sockets...

  • Page 15: Add A Connected Device

    Living Now with Netatmo Installation Manual Add a connected device Nota: if the association with the Home + Control App has already been completed, follow the instructions of the “Add a product to this home” menu in the App, or 1.
  • Page 16 Living Now with Netatmo Installation Manual Check that the LEDs of all the devices are off, with the exception of the device to add, which must have a steady red LED. 4. Complete the association of the new device as shown in “Associate connected devices”(point 3).

  • Page 17: Add A Wireless Scenario Control

    Living Now with Netatmo Installation Manual Add a wireless scenario control K4570CW Master, wireless In&Out scenario control 1. Start the association: press and hold down the two control keys at the same time, the LED will turn green. Release the keys and wait until it turns off.
  • Page 18 Living Now with Netatmo Installation Manual K4570CW Master, wireless In&Out scenario control 2. Remove the tab from the new control. 3. Fit the cover and the plate on the wireless control. Warning: if cover and plate are not fitted, do not press the wireless control keys.
  • Page 19 Living Now with Netatmo Installation Manual Check that the LEDs of all the devices immediately turn off. The control is now associated to your Smart electric system and you will be able to control the IN/OUT and/or Day/Night scenarios. You can also add light control K4003CW – K4003DCW – 3577C or rolling shutter control K4027CW...

  • Page 20: Associate A Wireless Light/Rolling Shutter Control To One Or More Modular Connected Devices

    Living Now with Netatmo Installation Manual Associate a wireless light/rolling shutter control to one or more modular connected devices K4003CW – K4003DCW – 3577C wireless light control K4027CW wireless shutter control 1. Start the association:: press and hold down the two control keys at the same time, the LED will turn green. Release the keys and wait until it turns off.
  • Page 21 Living Now with Netatmo Installation Manual K4003CW – K4003DCW – 3577C wireless light control K4027CW wireless shutter control 2. Remove the tab from the new control. 3. Fit the cover and the plate on the wireless control. Warning: if cover and plate are not fitted, do not press the wireless control keys.
  • Page 22 Living Now with Netatmo Installation Manual Connected device K4003C connected two-way switch 5. Press and hold down one of the two keys of the wireless control to associate, with the control, touch three times (gently and in quick sequence) the connected device to associate.
  • Page 23 Living Now with Netatmo Installation Manual Table A Association of the connected devices/wireless controls Wireless controls Connected devices that can be controlled K4003DCW K4003C K4003CW Lights K4411CM2 3577C 3584C K4027C K4027CW Shutters K4027CM2 K4531C K4003CW Sockets * KG/KW/KM4441AC KG/KW/KM4441AC * Note: even when associated to a wireless light control, the controlled sockets are not controlled by wireless scenario controls controlling lights.
  • Page 24 Living Now with Netatmo Installation Manual K4003CW – K4003DCW – 3577C wireless light control K4027CW wireless shutter control The LEDs flash three times blue. Release the wireless control. The control LED goes from blue flashing to off, turns on again blue for a second and then turns off.
  • Page 25 Living Now with Netatmo Installation Manual Check that the LEDs of all the devices immediately turn off: the association has been completed correctly. Repeat the procedure shown for each wireless control point from which you wish to control the connected devices.

  • Page 26: Dissociate A Wireless Control From The Connected Devices

    Living Now with Netatmo Installation Manual Dissociate a wireless control from the connected devices K4003CW – K4003DCW – 3577C wireless light control K4027CW wireless shutter control 1. Press at the same time the two pushbuttons of the control to dissociate until the LED turns orange.
  • Page 27 Living Now with Netatmo Installation Manual K4003CW – K4003DCW – 3577C wireless light control K4027CW wireless shutter control 2. Press and hold down the reset pushbutton The LED flashes green, then it goes off, then turns red. Now release the pushbutton.

  • Page 28: Use The App

    Living Now with Netatmo Installation Manual Use the App After completing the association of all the devices connected to the gateway and adding any wireless controls associated to connected devices, it will immediately be possible to: – activate the “IN” scenario: all rolling shutters go up –...
  • Page 29 Living Now with Netatmo Installation Manual...
  • Page 30 BTicino SpA Viale Borri, 231 21100 Varese www.bticino.com BTicino Spa reserves at any time the right to modify the contents of this booklet and to communicate, in any form and modality, the changes brought to the same.
