FAS8200 Systems

Installation and Setup Instructions

Prepare for installation | 1

1. Go to

Pre-setup

2. Unpack all boxes and inventory contents.

2. Go to to

- Download and complete the

- Watch the videos listed under

Controller-to-controller cables

In the box

Cluster interconnect cable

Part number 112-00297 or 112-00299

You provide

3U per chassis

mysupport.netapp.com

and

create an

AFF and FAS System Documentation Center

Cluster Conﬁguration

Setup

10 GbE network cable

Part number 112-00299 or

112-00300 or 112-00301

Optical network cable

Part number 112-00188 or

112-00189 or 112-00090

Rack space

Screwdriver

Prepare for installation

account,

system, and

and click FAS8200 systems, and then click Installation and Setup:

Worksheet.

videos.

Host cables

Storage cables

SAS cables

Part number 112-00436 or

112-00437 or 112-00438

Additional network cables

For connecting your storage to your network

switch and Microsoft ® Windows ® client

Install Hardware

Cable Storage

get your license

keys.

Power cables

Windows client

Runs the software to conﬁgure

your storage system

Complete system setup

and conﬁguration

Ethernet cables

215-15015_A0

Summary of Contents for NetApp FAS8200 Series

Page 1 Install hardware Cable storage Complete system setup and conﬁguration FAS8200 Systems Installation and Setup Instructions Prepare for installation | 1 1. Go to mysupport.netapp.com create an account, register your system, and get your license keys. Pre-setup 2. Unpack all boxes and inventory contents.
Page 2 Install hardware | Stage 2 Unpack and install system Optional 2-post mid-mount brackets • Unpack all boxes and inventory contents. • Install rail kits, as needed, using the enclosed installation instructions. • Install system components on rails or in a system cabinet per installation instructions.
Page 3 Cable storage | Stage 3 Multi-path HA cabling a FAS8200 WITH external storage (DS212C or DS224C disk shelves Storage cables 112-00436, 112-00437, or 112-00438 Connect the shelf-to-shelf ports Connect the controllers to the ﬁrst stack of disk shelves Primary path from controller to stack Connect the controllers to the second stack of disk shelves Secondary path from controller to stack IOMA...
Page 4 Use System Manager Guided Setup to conﬁgure your cluster Completing setup 1. Verify the health of your system by running Conﬁg Advisor. 2. After you have completed the initial conﬁguration, go to the NetApp ONTAP Resources page for information about conﬁguring additional features in ONTAP.
