List of Parameters
COn Description
SET
Set point
r0 Differential or hysteresis
r1
Minimum value for set point
r2 Maximum value for set point
r6
Fan operation
F0 Fan stoppage temperature
F1
Stop compressor & fan with door open
c0 Minimum compressor stoppage time
c1 Continuous cycle time
c2 ON time of fault cycle
c3 OFF time of fault cycle
c4 Minimum ON time of the compressor
c5 Minimum time between two connections of
the compressor
dEF Description
d0 Cool/Heat mode (ST13)
d0 Type of defrosting (ST23 & 33)
d1 Temperature at which defrosting will stop
d2 Maximum defrosting time
d3 First hour of day for defrosting
d4 Delay of first defrosting
d5 Display on defrosting
d6 Display return limit
d7 Compressor drip time
d8 Interval between defrosting
d9 Fan works on defrosting
d10
Fan drip time
d11 Minimum defrosting time
d12
Fan/defrosting control probe
d14 Units to count the defrosting cycle
Pro Description
P0
Temperature scale
P1 Ambient probe 1 calibration
P2
Defrosting probe 2 calibration
P3 Product probe 3 calibration
P4 Decimal point
P5 Probe to display
P6 Probe 2 present
P7 Probe 3 present
ALA Description
A0 Fan and alarm differential
A1 Maximum alarm temperature
A2 Minimum alarm temperature
A3 Time validation open door or external alarm
A4 Time without alarm after defrosting
A5 Time without alarm after opening the door
A6 Time without alarm after connection
A7 Alarm verification time
A8 Probe for alarm
Ini Description
Hor Hour
Min Minutes
E0 Configure digital input
H0 Factory settings
H1 Master slave
H2 Keypad protection
H3
Delay time on connecting
H5 Keyboard code
H6
Type of probe
H7 Relay 2 setup
H8
Relay 3 setup
H10 HACCP activated
HdE Next defrost time
MdE Next defrost time
Note: For parameter settings described as h-m, the first 2 digits represent hours, and
the third represents tens of minutes. (Example: 4.2 is 4 hours and 20 minutes).
Units Range
Degrees r1 to r2
Degrees 0.1 to 20
Degrees -99.9 to r2
Degrees r1 to 302
Option off/on/con
Degrees -99.9 to 302
Option no/yes/con/fan
Minutes 0 to 240
h - m 0.0 to 18
Minutes 0 to 999
Minutes 0 to 999
Minutes 0 to 240
Minutes 0 to 240
Units Range
Option re/in
Option re/in
Degrees -99.9 to 302
Minutes 0 to 240
h - m 00.0 to 18.0
Minutes 0 to 999
Option off/on/-d-
Minutes 0 to 240
Minutes 0 to 240
h - m 00.0 to 99.0
Option no/yes
Minutes 0 to 240
Minutes 0 to 240
Option sd1/sd2/sd3
Option rt/ct
Units Range
Option °C/°F
Degrees -20.0 to 20.0
Degrees -20.0 to 20.0
Degrees -20.0 to 20.0
Option no/yes
Option sd1/sd2/sd3
Option no/yes
Option no/yes
Units Range
Degrees 0.1 to 20.0
Degrees 0.1 to 99.9
Degrees 0.1 to 99.9
Minutes 0 to 999
h - m 0.0 to 18.0
h - m 0.0 to 18.0
h - m 0.0 to 18.0
h - m 0.0 to 18.0
Option sd1/sd2/sd3
Units Range
Hours 0 to 23
Minutes 0 to 59
Option all/AI/In/def/ndf
Option 0 to 3
Option Mst/Slv
Option no/yes
Seconds 0 to 240
Numeric 0 to 999
Option PTC/NTC
Option lit/FAn/ALA/dEF/FAI
Option lit/FAn/ALA/dEF/FAI
Option no/yes
Hours (only read)
Minutes (only read)
Parameter Descriptions
Compressor (COn)
SET = Working Set Point. Temperature the system trys to maintain. Variable
between r1 and r2.
r0 = Differential. When primary probe temperature >= Set+r0 Compressor ON
When primary probe temperature <= Set Compressor OFF
r6 = Fan operation on regulation.
Off = Fan does not connect on regulation.
On = Fan is always connected on regulation.
Con = Fan linked to compressor start-up.
(Fan ON if allowed by the temperature set in F0)
F0 = Fan temperature limit.
Direct mode. Relay selected as FAN. Fan OFF on regulation when probe temperature
set in d12 is >= F0. Fan ON on regulation, when temperature is =< F0 - A0.
Reverse mode. Relay selected as FAI. Fan OFF on regulation when probe
temperature set in d12 is < F0. Fan ON on regulation, when temperature is >= F0 + A0.
F1 = Stop compressor and Fan if door opened (Circuit closure between input
terminal 5 and common terminal 4).
No = the fan and compressor do not stop on regulation and continuous cycle when
opening the door.
Yes = the fan and compressor stop on regulation and continuous cycle when opening
the door.
Con = the compressor stop but the fan do not stop on regulation and continuous
cycle when opening the door.
Fan = the fan stop but the compressor do not stop on regulation and continuous
cycle when opening the door.
c0 = Minimum compressor stop time. Minimum time since compressor stops until
it is starts again.
c1 = Continuous cycle time. Duration of a continuous cold cycle.
c2 = ON time of fault cycle, when ambient probe is broken
c3 = OFF time of fault cycle, when ambient probe is broken
c4 = Minimum time since compressor starts until it stops.
c5 = Minimum time since compressor starts until it starts again.
Defrost (dEF)
d0 = Cool / Heat mode (ST13). re = cool; In = heat
d0 = Type of defrosting (ST23, ST33)
re = defrosting without connecting the compressor.
in = defrosting by connecting the compressor.
d1 = End of defrosting temperature. When this temperature is reached the defrosting
will end.
d2 = Maximum defrosting time. The defrosting will stop when this time is reached. If
it is zero there will be no defrosting.
d3 = First hour defrosting of the day. From 00:00 hours the first defrosting is at d3
hours. Until this time no defrosting is performed.
d4 = Delay first defrosting.
Time to carry out the first defrosting if d3 = yes.
d5 = Display during the defrosting.
Off = the current temperature will be shown during defrosting.
On = the temperature at defrost beginning is frozen on display until the end of
defrosting and until the current temperature is equal or lower than the initial one, or
until d6 time elapses.
-d- = Label -d- is displayed during defrosting, until the end of defrosting and until the
current temperature is equal or lower than the initial one, or until d6 time elapses.
d6 = Display return limit. Maximum time before viewing the current temperature
again after defrosting.
d7 = Compressor drip time. Time since defrosting ends until the compressor can
be connected.
d8 = Interval between defrosting. Time between the start of a defrosting and the start
of the following one. If it is zero defrosting is not done automatically by time.
d9 = Fan operation during defrosting time. It determines if the fan is connected or
not during defrosting.
d10 = Fan drip time. Time since defrosting ends until fan can be connected.
d11 = Minimum Time duration defrosting. Once defrosting begins it stays at least
during this time
d12 = Fan & defrosting control probe.
sd1 = primary probe
sd2 = defrosting probe
sd3 = product probe
d14 = Units to count the defrosting cycle.
rt = according to the working time of the controller
ct = according to the working time of the compressor
