2.2. I/O Options

The front interface of the M21 is fully field-reconfigurable. The following interface boards
may be attached or changed at any time:
 RS-232
 USB
 RS-485
 RS-422
 GPIO
 Analog
 FIO

2.3. Tech Series Flexibility

The Tech Series radios from Raveon is the most flexible radio platform in the industry.
A myriad of I/O options, and many RF band options, GPS options, wide/narrow
channels, Arduino option, and wide DC input voltage range.
I/O Connector Type
[ S ] 5T835
[ U ] 5T837
[ T ] 5T836-1
[ F ] 5T836-2
[ G ] contact sales
[ A ] 5T838
[ D ] 5T832-1
RS232 serial port, DB9.
USB for computer communication.
RS-485 2-wire interface.
RS-422 4-wire interface.
General Purpose IO.
Analog radio interface.
Flexible IO. Digital INs and OUTs
Connector Code
F,G, T
4
S
U
A,D
