1. About This Manual

This manual covers interface options for Raveon's Tech Series products. Various radio
models may be incorporated into the Tech Series products, so refer to the particular radio
module Technical Manual for specific information about how to configure and use the radio
features.
This manual covers Tech Series I/O features. The manuals for the radios used in Tech
Series products are:
RV-M8
RV-M6
RV-M50
RV-Z50
RV-Z55
There are two different Tech Series Enclosures:
RV-M21
RV-M22

2. Tech Series Overview

2.1. M21 and M22

M22 Enclosure
The M21 is larger to utilize the 5 watt M8 radio modems. Both enclosures have GPS
options and can utilize the myriad of IO options.
VHF/UHF 5W radio modem module
VHF/UHF 2W radio modem module
915MHz ISM Daisy radio, License Free
3G cellular radio modem
LTE cellular radio modem
For M8 radio modules, up to 5 watts TX power.
For M6, M50m, Z50 radio models. Low power, miniature enclosure.
M21 Enclosure
