Thank you for purchasing this quality product. Be sure to check all packing material carefully for small
hardware which may have come loose inside the carton during shipment. Identify and count all hardware
and compare with the hardware list below.
When placing furniture on non-carpeted flooring, HMI recommends the use of floor protection such as
an area rug or furniture pads. Area rugs and padding not included with purchase.
No.
1
2
3
No.
A
B
C
D
E
F
STEP 1
-Attach Front leg(2) to Seat Cushion(3),
Do not fully tighten at this moment.
Made In Malaysia
L I V I N G S P A C E S
ASSEMBLY INSTRUCTIONS
ITEM 305-P193262
Wood Back Dining Side Chair
PARTS LIST
Description
Wooden Chair Back
Front Leg
Seat Cushion
HARDWARE LIST
Description
JCBC Screw M6 x 40mm
JCBC Screw M6 x 60mm
JCBC Screw M6 x 80mm
Spring Washer M6 x 12mm Ø
Flat Washer M6 x 19mm Ø
Allen Key M4 x 65mm
F
D
E
B
4x
Sketch
Sketch
3
Quantity
1pc
2pcs
1pc
Quantity
2pcs
4pcs
4pcs
10pcs
10pcs
1pc
2
Page 1 of 2
