Instruction Manual
XPCDH10 / 12 / 14
Models:
For domestic household use only.
These products fully comply with all current European Safety Standard requirements
for Dehumidifiers and are fully compliant with the Low Voltage Directive 2014/35/EU,
the EMC Directive 2014/30/EU and the RoHS Directive 2015/863/EU.
XPCDH10UKIM ISSUE: 1 Series: A
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Xpelair XPCDH10
Summary of Contents for Xpelair XPCDH10
- Page 1 Instruction Manual XPCDH10 / 12 / 14 Models: For domestic household use only. These products fully comply with all current European Safety Standard requirements for Dehumidifiers and are fully compliant with the Low Voltage Directive 2014/35/EU, XPCDH10UKIM ISSUE: 1 Series: A...
- Page 2 NB These symbols on your device mean: • This appliance is filled with Propane gas R290. Follow strictly the manufacturer’s instruction concerning use and repairs! • Before using this appliance, you must carefully read the entire instruction manual. • Do not install, operate or store the device in a room with a floor area smaller than 4m for 10L/12L models, and 7m for 14L models.
- Page 3 IMPORTANT THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE. Note also the information presented on the appliance CAUTION: FAILURE TO FOLLOW THESE INSTRUCTIONS MAY CAUSE INJURY AND / OR DAMAGE AND MAY INVALIDATE YOUR GUARANTEE Please read the operating instructions carefully before using your dehumidifier for the first time and keep them in a safe place.
- Page 4 Children aged from 3 years and less than 8 years shall only switch on/off the appliance provided that it • has been placed or installed in its intended normal operating position and they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children aged from 3 years and less than 8 years shall not plug in, regulate and clean the appliance or perform user maintenance.
- Page 5 IMPORTANT: Do not use this unit where the ambient temperature is lower than 5 C, otherwise the • evaporating coil will ice up heavily and this will affect the performance of the product and potentially cause a malfunction. NEVER drop or insert any object into any openings. •...
- Page 6 Exposed to the Near water If the power cable weather outdoors wires are frayed or cut Where small children If an extension Where the power may be left unattended lead may become cable may be damaged overload On a slope or Where there is risk Where it may be uneven surface...
-
Page 7: Specification
Specification Model no. XPCDH10 XPCDH12 XPCDH14 Max Dehumidification capacity at 30°C, 80% 10L/day 12L/day 14L/day Max Dehumidification capacity at 21°C, 59% 3.3L/day 4.4L/day 4.7L/day Max Dehumidification capacity at 10°C, 59% 1.5L/day 1.7L/day 1.5L/day Working range 5 ~ 32°C Water tank 2.5 L... -
Page 8: How It Works
Quick start/ First time operation 1. Before switching on for first time please ensure unit has settled for 12 hours. 2. Please ensure anti-dust filter is fitted securely. 3. Plug product in. 4. Press on/off button. How It Works Air Outlet Air Inlet Condenser Motor... -
Page 9: Where To Position
Where To Position Excess moisture will travel throughout your home, in the same way that cooking smells waft to every room in the house. For this reason, the dehumidifier should be positioned, so that it can draw this moist air towards it from all over the home. -
Page 10: Control Panel
Control Panel ON/OFF (power) button FULL ON/OFF Water tank "Full" Operation indicator indicator 1. Plug the unit into a correct mains socket. (Please refer to the rating label at the rear of the unit for correct voltage/frequency.) 2. Press ON/OFF button to turn on the unit. The compressor will start to work in continuous mode. 3. -
Page 11: Continuous Drainage
Drainage While the water tank is full, the compressor will stop for self-protection and the water tank full indicator light will turn red. To move the water tank, pull it out squarely from the unit. After emptying the water tank, place the water tank carefully back into its location into space. The tank must be properly located in order for the ‘water full’... -
Page 12: Maintenance
Maintenance Always unplug the unit from the mains before carrying out any maintenance or cleaning of the unit. CLEANING THE BODY Use a soft damp cloth to wipe the unit clean. Don’t ever use volatile chemicals, gasoline, detergents, chemically treated clothes, or other cleansing solutions. -
Page 13: Troubleshooting
Troubleshooting THE UNIT DOES NOT OPERATE: • Is the unit plugged in? • Is the house electricity on? • Is the room temperature below 5°C or above 32°C? If so, then it is out of the working range of the unit. •... - Page 14 If you are a consumer and you experience a problem with your Xpelair product, which is found to be defective due to faulty materials or workmanship within the guarantee period, this Xpelair guarantee will cover repair or - at the discretion of Xpelair –...
-
Page 15: Terms And Conditions
You must provide to Xpelair or its authorised agents on request the original receipt as proof of purchase and - if required by Xpelair - proof of delivery. If you are unable to provide this documentation, you will be required to pay for any repair work required. - Page 16 Customer Helpline: 0344 879 3588 www.xpelair.co.uk Glen Dimplex Heating and Ventilation Millbrook House, Grange Drive, Hedge End, Southampton, SO30 2DF © Glen Dimplex. All rights reserved. Material contained in this publication may not be reproduced in whole or in part, without prior permission in writing of Glen Dimplex...
