Summary of Contents for Symbol LS-2100U

  • Page 2: Installation

    Installation Installing the Keyboard Wedge Reader To install a keyboard wedge reader, follow the steps below: Turn off the power of the PC or Terminal. Unplug keyboard from the PC or Terminal. Make sure you have the Y cable with appropriate connector type for your PC or Terminal.

  • Page 3: Method Of Programming

    Method of Programming Loop of programming The philosophy of programming parameters has been show on the flow chart. Basically user should Scan Start of Configuration. Scan all necessary labels for parameters that meet applications. Scan End of Configuration to end the programming. To go bark to the Default Settings, just scan label for Set All Defaults.

  • Page 4: Setup Commands

    Setup Commands Set All Defaults Set all the parameters to the factory default setting. Start Configuration. End Configuration. Abort Configuration Terminate current programming status. Version Information Display the decoder version information and date code...

  • Page 5: Interface Selection

    Interface Selection <Keybard Mode> RS232 Mode USB Mode Start Configuration Abort Configuration...

  • Page 6: Reading Mode

    Reading Mode <Good Read Off> Flash-On Trigger On/Off Continuous/Trigger Off Testing Continuous/No Trigger Trigger ON/Good Read Off/Delay=?? *This mode is almost the same as <Good Read OFF> but you can delay time for turning off LED<Default is 3 seconds> you can use the provided Trigger On/Good Read Decimal and Hex-Label Tables for your own setup.
  • Page 7 RS-232 Communication Parameters Set Up BAUD Rate <9600> 19200 1200 38400 2400 4800 Start Configuration Abort Configuration...
  • Page 8 RS-232 Communication Parameters Set Up Data Bits: 7 Data Bits <8 Data Bits> Set up Parity: <None> Even End Configuration...

  • Page 9: Rs-232 Communication Parameters

    RS-232 Communication Parameters Handshaking <None> RTS/CTS Enable ACK/NAK Enable XON/XOFF Enable Start Configuration Abort Configuration...
  • Page 10 RS-232 Communication Parameters (ACK/NAK Response Time CTS Observation Time:) ACK/NAK Time Out=?? Scan Start Configuration Label Scan ACK/NAK Time-out Label Scan Two Digit Labels in Table–Hex Scan Confirm Label in Table-Hex Scan End Configuration Label RTS/CTS Time Out=?? Scan Enter Start Configuration Label Scan RTS/CTS Time-Out Label Scan Two Digit Labels in Table–Hex Scan Confirm Label in Table-Hex...

  • Page 11: Keyboard Wedge Parameters

    Keyboard Wedge Parameters Terminal Type <IBM PC/AT, PS/2> UPPER/LOWER Case ATUTO <Lower Case> Upper Case Send character by ALT Method ALT MODE Enable (ALT+HOT KEY) ALT MODE Select Numerical Pad (ALL DATA FOR ALT) <Off> Bar-space invert to Read <No> Start Configuration Abort Configuration...

  • Page 12: Language Selection

    Language Selection <US English> Poland UK English Japanese Italian Belgium Spanish Portuguese French Demark Germany Netherlands Swedish/Finnish Norway Swiss Latin America End Configuration...
  • Page 13 Output Characters Parameters Select Terminator Keyboard NONE <CR> SPACE Start Configuration Abort Configuration...

  • Page 14: Output Characters Parameters

    Output Characters Parameters Select Terminator RS232 NONE <CR> CTR-C CR/LF STX..XOFF XON..XOFF SPACE End Configuration...
  • Page 15 Code ID Code ID Selection CODE ID=ON <CODE ID=OFF> Code Length Select Code ID Set Set<user defined> Set1 Set2 Set3 Set4 Set5 Set6 Set7 Note1: UP to two characters of code ID can be configured for each symbology when you select user defined.
  • Page 16 Code ID Set1-Set5 Table Set1 Set2 Set3 Set4 Set5 Code 39 Italy Pharmacode French Pharmacode Industrial 25 Interleave 25 Matrix 25 Codabar Code 93 Code 128 UPCE EAN8 EAN13 Plessey UPCA End Configuration...
  • Page 17 Code ID Bar Code ID <USER DEFINED> CODE 39 MSI/PLESSEY INDUSTRIAL 2 OF 5 ENA-13 CHINA POSTAGE UPC-E CODE 93 INTERLEVED 2 OF 5 MATRIX 2 OF 5 CODABAR/NW7 CODE 128 EAN-8 UPC-A Note: Refer to ASCII Table; scan two hexadecimal labels in Table-hex to represent one character.

  • Page 18: Misc. Parameters

    Misc. Parameters Buzzer Beep Tone Buzzer Pitch=?? (0-22) Buzzer Duration=?? (0-127) Power up Tone <On> LED Indicator <Normal On Good Read Off> Normal Off Good Read On Keyboard Speed of PC/AT <Normal> Turbo Single Scan <Double Scan> End Configuration...

  • Page 19: Code Option

    Code Option UPC-A/EAN-13 <On> UPC-E <On> EAN-8/JAN-8 <On> CODE 39 <On> CODE 128 <On> CODABAR/NW7 <On> Start Configuration Abort Configuration...
  • Page 20 Code Option Interleave25 <On> Industrial 25 < Off > UCC EAN/128 < Off > Matrix 25 < Off > CODE 93 <On> End Configuration...
  • Page 21 Code Option China postage <Off> MSI/PLESSEY <On> IATA Code <Off> ISBN <Off> UPC-EAN Add-ON 2/5 <Off> Start Configuration Abort Configuration...
  • Page 22 Code Option EAN 8 Convert to EAN-13 <Off> When this option is selected the scanner will convert EAN-8 to EAN-13 by transmitting five zeroes after three characters. When this option is selected the canner will convert EAN-8 to EAN-13 by transmitting five zeroes before the barcode UPC-E Convert to UPC-A <Off>...
  • Page 23 EAN-13/JAN-13 Transmit Check Character <On> Truncate Leading Digit <Off> Truncate Leading Zero <Off> Start Configuration Abort Configuration...
  • Page 24 UPC-A Transmit Check Character <On> Truncate Leading Zero <Off> Truncate Leading Digit <Off> EAN-8 /JAN-8 Transmit Check Char <On> Truncate Leading <Off> End Configuration...
  • Page 25 UPC-E/UCC EAN/128 Transmit Check Char <On> Truncate Leading Digit <Off> UCC EAN/128 <Off> CODE 39 Concatenation <Off> Start Configuration Abort Configuration...
  • Page 26 CODE 39 / (CODE 32) <Standard> Full ASCII Transmit Start/End Character <Off> Transmit Check Character <On> Verify Checksum <OFF> Code 32 On End Configuration...
  • Page 27 Interleaved 2 of 5 Transmit Check Character <On> Verify Checksum <Off> Length Define Min: 02 Max: 48 Barcode Length Setting Scan Start Configuration Scan Length Define Label Scan Four Digit Labels in Table-Hex Scan Confirm Label in Table-Hex Scan End Configuration User Define 3 Sets Available User Define Length Setting:...
  • Page 28 Industrial 2 of 5 / IATA Transmit Check Character <On> Verify Checksum <Off> Length Define Min: 2 Max: 24 Barcode Length Setting Scan Start Configuration Scan Length Define Label Scan Four Digit Labels in Table-Hex Scan Confirm Label in Table-Hex Scan End Configuration User Define 3 Sets Available...
  • Page 29 MATRIX 2 OF 5 Transmit Check Character <On> Verify Checksum <Off> Length Define Min: 2 Max: 40 Barcode Length Setting Scan Start Configuration Scan Length Define Label Scan Four Digit Labels in Table-Hex Scan Confirm Label in Table-Hex Scan End Configuration User Define 3 Sets Available User Define Length Setting:...

  • Page 30: China Postage

    CHINA POSTAGE Transmit Check Character <On> Verify Checksum <Off> Length Define Min: 2 Max: 40 Barcode Length Setting Scan Start Configuration Scan Length Define Label Scan Four Digit Labels in Table-Hex Scan Confirm Label in Table-Hex Scan End Configuration User Define 3 Sets Available User Define Length Setting: Scan Start Configuration...

  • Page 31: Barcode Setting

    Barcode Setting Transmit Check Character <Off> Start / End Transmit Type ABCD/ABCD ABCD/TN*E <abcd/abcd> Abcd/tn*e CODABAR / NW7 Start /END Transmit NW7 CS=On NW7 CS=Off NW7 TX=No NW7 TX=Yes Start Configuration Abort Configuration...

  • Page 32: Preamble And Postamble

    Preamble and Postamble Preamble Postamble Preamble & Postamble Setting: Scan Start Configuration Scan Preamble or Postamble Label Refer to ASCII Table; scan two digits in Table-Hex for pepresenting one character, maximum 10 characters can be accepted Scan Confirm Label in Table-Hex Scan End configuration Clear Clear Preamble &...

  • Page 33: Function Key Emulation

    Function Key Emulation <Off> Enable Function Key Emulation: Scan start configuration Scan ON Label Scan End configuration 1:To concatenate a function key with input data; please refer to Function Key Table for its hexadecimal representation. For Example. Preamble data with F1: Scan start configuration Label Scan Preamble Label Scan Label 0 and 1 in Table-Hex...

  • Page 34: Function Code For Pc Xt/At

    Function code for PC XT/AT F1 ($A) F7 ($G) F2 ($B) F8 ($H) F3 ($C) F9 ($I) F4 ($D) F10 ($J) F5 ($E) F11 ($K) F6 ($F) F12 ($L) End Configuration...
  • Page 35 Function code for PC XT/AT Enter ($M) End ($U) Tab ($N) PgUp ($V) BS ($O) PgDn($W) Up ($P) Ins ($X) Down ($Q) Del ($Y) Left ($R) Esc (%A) Right ($S) Home ($T) Start Configuration Abort Configuration...
  • Page 36 Table-Hex HEXADECIMAL End Configuration...
  • Page 37 Table-Hex HEXADECIMAL Confirm Start Configuration Abort Configuration...

  • Page 38: Pin Assignments

    Pin Assignments...
  • Page 39 Pin Assignments...
  • Page 40 ASCII TABLE “ & ‘ < > DEL.
  • Page 41 Hexadecimal-Decimal Conversion Table For example: Hexadecimal Decimal H: 5 L: 3 83 D5 H: D L: 5 213...
