You can copy the GPF file to as many flash memory cards as you need one after the other. Simply
replace the flash memory card in the slot of the CompactFlash
#20 (Save Project File to CF Card) again. Please make sure that you still have selected the
®
CompactFlash read/write drive as your target drive.
With the help of this program, a GPF file that has been saved to your computer's hard drive, can be
copied to your flash memory cards any time you like – again and again.
A mouse-click on button #21 (Info) will show you the contact information and the software version.
To close the Project Maker please click on button #22 (Close).
Attention: Only use the Project Maker to write GPF files to your flash memory card. If you try to copy
the GPF files to your flash memory card using other programs (e.g. Microsoft
some very important requests are not being made. Be aware that using other programs than the
Project Maker might possibly cause problems and flawless playback of the file is in question.
Note: If you want to copy a GPF file to your flash memory card without the converting process from a
wave file into a GPF file (i.e. in case that you have already converted the wave file into a GPF file
earlier and the GPF file is stored on your PC) simply start the Project Maker and select the file that you
want to copy by clicking on button #12 (Project File). That followed please follow the familiar steps to
copy the file to flash memory card.

8. Switching on the PFE Profi Audio, Operating time

Turn the key switch to switch on the PFE Profi Audio.
The following will be displayed in succession:
Only if there is a flash memory card with a valid GPF file inside the slot of the PFE Profi Audio, the
name of the project will now be shown on the display for a few seconds:
After that the device will automatically enter the receiving mode and the standard display will appear.
The maximum operation time is depending on the hardware version. The following values can be
expected with the old hardware version: In receiving mode the operating time of the PFE Profi Audio is
limited to approx. 6 hours. When the audio track is played back the power consumption increases. If
the device is playing back permanently the operating time is reduced to approx. 3 hours. If
loudspeakers are used in addition the operating time is reduced even more – depending on the power
delivered to the loudspeakers. If the maximum output power of the PFE Profi Audio is being used the
operating time is reduced to a little less than one hour. With the new hardware version (older devices
can be upgraded anytime) the operation time is doubled: Approx. 12h in receiving mode, approx. 6h
when playing back and approx 2h with maximum speaker output power.
If the battery becomes discharged below 30% or less the LED "Akku leer / Laden" is illuminated in red
color. This is how all of our products indicate a low battery status. If the device is operating in the play
mode or in the menu mode, no battery warning is being showed. Deep discharges (i.e. total
discharges) that might possibly occur are being counted and the number of deep discharges is being
displayed the time you switch on the device.
Start screen.
Product name and software version.
The name that you have chosen for your project will be shown in the bottom
line of the display (first twelve characters only).
®
read/write drive and click on button
- 12 -
® ® ®
Windows Explorer )
