TYM T700 Operator's Manual
  1. Manuals
  2. Brands
  3. TYM Manuals
  4. Tractor
  5. T700
  6. Operator's manual
TYM T700 Operator's Manual

TYM T700 Operator's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

TYM
OPERATOR'S MANUAL
OPERATOR'S MANUAL
FOR
TRACTORS
(T700 MODEL)
2~3 Floor Daeyong B/D #90, Nonhyeon-dong, Kangnam-gu, Seoul, Korea
■TEL:82-2-3014-2800,
■www.tym.co.kr
FAX:82-2-3014-2850

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T700 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TYM T700

Summary of Contents for TYM T700

  • Page 1 OPERATOR’S MANUAL OPERATOR’S MANUAL TRACTORS (T700 MODEL) 2~3 Floor Daeyong B/D #90, Nonhyeon-dong, Kangnam-gu, Seoul, Korea ■TEL:82-2-3014-2800, ■www.tym.co.kr FAX:82-2-3014-2850...
  • Page 3 Emission system Warranty Emission control system Certification Label CAUTION:Statutes providing severe penalties for tempering with emissions penalties for tempering with emissions controls may apply at the user’s location The emissions warranty described below applies only to those engines marketed by John Deere that have been certified by the United States Environmental Protection Agency(EPA) and/or California Air Resources Board(CARB):and used in the United States and Canada in non-road mobile(self propelled or d(CARB)
  • Page 5 FOREWARD Thank you very much for purchasing our tractor, which, we feel sure, will give you many years of trouble Free service. The introduction in this manual set out the correct manner of operating, maintaining and checking the tractor to ensure long-term durability. Please ensure correct operation of the tractor as incorrect operation can cause substantial mechanical f th t b t ti l...

  • Page 6: Table Of Contents

    CONTENTS Sr. No. Description Page No. Tractor Identification About this manual t thi Introduction & description Owner assistance (POPS)Roll over protectiv stuctures 9~11 Safety instructions, Do’s & Don’ts 12~24 Safety signs 25~27 Universal symbols Section A Controls, Instruments & Operations 29~61 Section B Lubrication &...

  • Page 7: Tractor Identification

    TRACTOR IDENTIFICATION The engine number is stamped on the left hand side of the engine block. The chassis number is shown on the left hand side of the tractor as shown in the drawing. Illustration A WARRANTY OF THE PRODUCT. The manufacturer warrants this product and full details of the warranty are provided on a separate warranty schedule.

  • Page 8: About This Manual Ab T Thi L

    ABOUT THIS MANUAL This manual has been prepared to assist you in following/adopting the correct procedure for running-in operation and maintenance of your new Tractor. Your Tractor has been designed and built to give maximum performance, with good fuel economy and ease of operation under a wide variety of operating conditions.

  • Page 9: Introduction & Description 5~7

    Introduction & Description The word, ’Tractor’ has been derived from ‘Traction’ which means pulling. A Tractor is required to pull or haul equipment, implements or trailers which are coupled to the Tractor body through suitable linkage. A Tractor can also be used as a power source as it has a power outlet source which is called...
  • Page 10 ■ Engine The tractors are fitted with fuel-efficient direct turbo charged injection engines with 3 cylinders of T700 designed by AVL. USA. ■ Clutch and Transmission A single composite* plate dry clutch(10.83″ diameter) is used on these tractors. Tractor with IPTO (Independent Power Take Off) are fitted with hydraulic Clutch Assy.
  • Page 11 ■ Steering This consists of Hydrostatic Power steering system, which has a hydraulic cylinder and a tandem type hydraulic pump ■ Electrical System A 12 Volt Lead Acid Propylene Battery is used to activate the Engine through the Starter Motor. The Electrical system comprising Horn, Head Lamps.

  • Page 12: Owner Assistance

    When additional assistance is needed, Your Dealer has direct access to your Distributor’s office. If you cannot obtain satisfaction by doing this, contact the TYM CO.,LTD. Office and provide them with; Your name, address and telephone number ■ Model and Tractor serial number ■...
  • Page 13 (ROPS) Roll Over Protective Structures Roll Over Protective Structures (ROPS) Tractors are equipped with a frame for the protection of operators. In the case of cab tractors the frame is incorporated in the cab structure. The objective of the frame or cab structure is to protect the operator in the event of a roll over and they are designed to support the entire weight of the tractor in that event and they are designed to support the entire weight of the tractor in that event.
  • Page 14 Damage of the ROPS If the tractor has rolled over or the ROPS has damaged (such as striking an overhead object during transport), It must be replaced to provide the original protection. After an accident, check for damages to the 1.ROPS.2.Seat 3.seat belt &...
  • Page 15 CONTROLS, INSTRUMENTS AND OPERATIONS Seat Adjusting Lever Fig.1 NOTE: Do not use solvents to clean the seat. Use warm water with a little detergent added. Before operating a Tractor it is important to adjust the seat to the most comfortable position & check whether it is properly locked in its position.

  • Page 16: Safety Instructions, Do's & Don

    SAFETY INSTRUCTIONS RECOGNIZE SAFETY INFORMATION This symbol means ATTENTION! YOUR SAFETY IS INVOLVED. The message that follows the symbol contains important information about safety. Carefully read the message SIGNAL WORDS. A signal word―DANGER, WARNING OR CAUTION―is used DANGER with safety alert symbol.
  • Page 17 USE OF ROPS AND SEAT BELT The Roll over Protection Structure (ROPS) has been certified to industry and/or government standards. Any damage or alternation to the ROPS, mounting hardware, or seat belt voids the certification and will reduce or eliminate protection for the operator in the event of a roll-over. Th ROPS The ROPS, mounting hardware, and seat belt should be checked t b lt h ld b...
  • Page 18 HANDLE FUEL SAFELY-AVOID FIRES Handle fuel with care; it is highly flammable. Do not refuel the Tractor while smoking or near open flame or sparks. Always stop the engine before refueling Tractors. Always keep your tractor clean of accumulated grease, and debris. Always clean up spilled fuel.
  • Page 19 AVOID HIGH-PRESSURE FLUIDS Escaping fluid under pressure can penetrate the skin causing serious injury. Keep hands and body away from pinholes and nozzles, which eject fluids under high pressure. If ANY fluid is injected into the skin. Consult your doctor immediately. PREVENT BATTERY EXPLOSIONS Keep sparks, lighted matches, and open flame away from the top of battery.
  • Page 20 WORK IN VENTILATED AREA Do not start the Tractor in an enclosed building unless the doors & windows are open for proper ventilation, as tractor fumes can cause sickness or death. If it is necessary to run an engine in an enclosed area remove the exhaust fumes by connecting exhaust pipe extension which...
  • Page 21 SAFE OPERATION OF YOUR TRACTOR The manufacturer of your tractor has made every effort to make it as safe as is humanly possible. Beyond this point it is the responsibility of the operator to avoid accidents and we ask that you read and implement our suggestions for your safety.
  • Page 22 SAFETY TIPS DURING MAINTENANCE 1. At least on a daily basis check all oil levels, Water level in the radiator and electrolyte level in the battery and perform services according to the service schedule. 2. Ensure tire pressures are even and the correct pressure for the job being done is maintained maintained.
  • Page 23 ► MOUNTING AND DEMOUNTING IMPLEMENTS (1)Ensure that all mounting and removal of implements is done on safe flat ground. Ensure no one is between the Tractor and implement and do not get under the implement to avoid accidental injuries. (2) After mounting the implement, ensure that all sway chains are correctly adjusted and, where PTO shafts are used that the shaft is fitted and secured correctly PTO shafts are used that the shaft is fitted and secured correctly.
  • Page 24 The following precautions are suggested to help prevent accidents. A careful operator is the best operator. Most accidents can be avoided by observing certain precautions .Read and take the following precautions before operating the Tractor to prevent accidents. Tractor should be operated only by those who are responsible and properly trained to do so.
  • Page 25 ■ Operating the tractor 1. Before starting the tractor apply the parking brake, place the PTO (Power Take Off) lever in the “OFF” position, the hydraulic control levers in the downward position, the remote control valve levers in the neutral position( if fitted) and the transmission in neutral. 2.
  • Page 26 ■ Driving the tractor 1. Watch where you are going especially at row ends, on roads, around trees and low hanging obstacles. 2. To avoid rollovers, drive the tractor with care and at speeds compatible with safety, especially when operating over rough ground, crossing ditches or slopes, and when turning at corners. 3.
  • Page 27 DO’S AND DON’T’S DO’S-For Better performance DO-Ensure that safety shields are in place and in good condition. DO-Read all operating instructions before commencing to operate Tractor. DO Carry out all maintenance tasks without fail DO-Carry out all maintenance tasks without fail. DO-Keep the air cleaner clean.
  • Page 28 DON’T-Use the independent brakes for making turns on the highway or at high speeds. DON’T-Refuel the tractor with the engine running. DON’T-Mount or dismount from the right side of the tractor. DON’T-Temper with the hydraulic control levers’ upper limit stops. DON’T-Use the draft control lever for lifting of implements.

  • Page 29: Safety Signs 25~27

    SAFETY SIGNS (Replace all missing, damaged or illegible signs) GENERAL SAFETY INFORMATION IMPORTANT: This “General safety Information” should be kept with the machine at all times as reference data. This symbol means ATTENTION! YOUR SAFETY IS INVOLVED. The message that follows the symbol contains important information about safety.
  • Page 30 Location: On Radiator Location: On Radiator shroud Part No.: 1200-910-015-0 side LH&RH Part No.: 1200-910-012-0 Location: On cover control Part No.: 1200-910-023-0 CAUTION DANGER Rotating driveline contact can cause TO PROTECT ENGINE AND Death HYDRAULIC COMPONENTS. ● Idle engine for 1 minute KEEP AWAY ! Keep all drive line.
  • Page 31 DANGER BLINDNESS CAN RESULT FROM A BATTERY EXPLOSION A BATTERY EXPLOSION. KEEP SPARKS OR OPEN THE FRAMES AWAY FROM BATTERY. DO NOT JUMP START. BURNS CAN RESULT FROM BATTERY ACID. IN CASE OF CONTACT FLUSH IMMEDIATELY WITH WATER . Location: On Rear fender side Location: On battery RH side Part No.: 1200-910-014-0 part No.: 1260-904-066-0...

  • Page 32: Universal Symbols

    UNIVERSAL SYMBOLS Some of the universal symbols have been shown below with an indication of their meaning Engine speed Engine speed Pressured- Pressured Corrosive Corrosive rev/minX100) open slowly substance Hours, Continuous ”Tortoise” recorded variable Slow or minimum Setting Engine ”Hare” fast or coolant Warning maximum...

  • Page 33: Section A

    It is too late to learn once the Tractor is moving. If in doubt about any aspect of the operation of the tractor consult your TYM co.,Ltd Tractor Dealer/Distributor. Particular attention should be paid to the recommendations for running-in to ensure that your tractor will...
  • Page 34 MAINTENANCE RULES ▶ENGINE Servicing the engine To gain access to engine, the hood must be released initially by pulling the hook release lever which located left on the side at the bottom : This done, lift the front end of the hood and position the stay rod. Important: When opening the hood in windy conditions, put the front of the tractor towards the wind.
  • Page 35 DESCRIPTION OF TRACTOR CONTROLS INSTRUMENT AND SWITCHES ►Main switch [OFF]-The key can be inserted or removed [ON]- The electric circuit is on. [Glow]-Glow plugs preheat the combustion chamber [START]-The starter motor is engaged. When the key is released it will return to the ON position...
  • Page 36 ►LIGHT SWITCH, INDICATORS AND HORN High and low beam are operated On the main switch Position down: High beam Position up: Low beam ►TACHOMETER This meter shows the revolutions of the engine and the PTO shaft as well as the travel speed in top gear (1) Right needle Indicates speed in top gear.
  • Page 37 ►WARNING LIGHTS Charge lamp This light will go off as soon as the engine starts to run to indicate that the alternator is changing. (Please note, as a broken fan belt can cause the light to come on, please stop the engine as overheating can occur if not rectified immediately) Oil pressure lamp Will go out as soon as the engine starts if the oil pressure is correct.
  • Page 38 Draft Control mode light is ON see page (48,49) for complete instructions. Control mode light is ON Turning see page (48,49) for complete instructions Reverse Control mode light is ON see page (48,49) for complete instructions External Control mode light is ON External Control mode light is ON see page (48,49) for complete instructions ►Independent PTO...
  • Page 39 ■ The PTO monitor lamp on the dash panel indicates the state of the PTO shaft. 1. If the monitor glows: The PTO is rotating 2. If the monitor is off: The PTO is off 3. If the monitor blinks: The PTO is presently stationary but will PTO monitor Lamp instantly start rotating when the clutch pedal is released or the implement is lowered...
  • Page 40 First select the specified speed for the PTO by using the PTO shifter on the LHS, below the driver seat. Clutch Pedal. Hydraulic PTO Monitor PTO SHAFT Position ON/OFF Control Lamp on the Control Lever. dash panel Switch Switch Either pressed or Either pressed or Either raised or Either raised or...
  • Page 41 TRACTOR CONTROLS Parking brake pedal Acceleration pedal Clutch pedal Steering wheel Shuttle shift lever Diff-lock pedal Hydraulic flow control knob Throttle lever Sub shift lever Main shift lever 4WD shift lever Position control Dial knob PTO shift lever Joy stick lever for hydraulics Tilt pedal (steering column)
  • Page 42 ►Hand Throttle (Throttle lever) Pulling the hand throttle towards the driver increases revolutions. Pushing it away from the driver decreases revolution. ►Clutch disconnecting arm For long term storage of the Tractor it is possible to latch the clutch in the is possible to latch the clutch in the disengaged position.
  • Page 43 ► Foot operated accelerator and hand throttle Lever This pedal can increase revolutions over a fixed hand throttle setting ► Park brake Connect the brake pedals , push them down to release the brake. Press the parking brake pedal and push the Brake pedal engage the brakes.
  • Page 44 When changing from forward to reverse or back to forward again while in high range make sure the tractor comes to a stop before changing direction. Failure to do so is likely to result in damage to the mechanism and place the driver at risk of important injury.
  • Page 45 Do not use high engine RPM when engaging” Diff lock”. If the diff lock does not release after removing the foot from the “diff lock” pedal alternatively brake with the left and right brake until it gets released. important Never use the “diff lock” at high speed or on the road as this can cause roll over and injury.
  • Page 46 Your tractor is equipped with 2 Speed PTO to suit range of q pp applications and conditions. POSITION MODEL T700 1000(755) Always use the clutch when engaging or disengaging the PTO or changing PTO speed. Let the PTO driven implement come to a complete stop before changing. important Do not operate any implement at a higher speed than is specified for it.
  • Page 47 Operating the hydraulics. The hydraulics are powered with an engine driven hydraulic pump and controlled with a electronic controller mounted beside the driver. ▶ Position control implements can be raised and lowered with the hydraulic position control knob and can be stopped at any position by stopping the knob To ensure a consistent working depth the adjustable stop can be set to ensure that the implement returns to the same depth every time.
  • Page 48 ▶ Joy stick lever This simple joystick lever can control the use of a front-end loader. And lift-retract, dump-rollback smoothly and act as one handle lever. 1. To raise the front end loader: pull the lever to lift position. 2. To lower the front end loader: push the lever to retract position. 3.
  • Page 49 After finishing the work, always lower the implement to the ground and switch off the engine, Set the parking brake to avoid injuries and accidents . Warning ▶Lowering speed control knob for the 3 point hitch This knob controls the downward speed of the hydraulics three point linkage and is positioned at the front of the driver’s seat.
  • Page 50 Exterior hydraulic Lever (Optional) Move the lever up or down and hold.This will raise or lower the implement (rotavator or hydraulic plow). Lever will return to neutral by itself. Important: -Do not hold the lever in the “pull” or “Push”position once the remote cylinder has reached the end of the stroke as this will cause oil to flow through the relief stroke.as this will cause oil to flow through the relief...
  • Page 51 OPERATING THE 3 POINT LINKAGE (TPL)
  • Page 52 ▶Telescopic stabilizers adjustment The stabilizers are intended for limiting or preventing implement side movement. There should be no clearance (Position A) during implement transport and when working with graders, scrapers, rollers, mowers, seeders, drills and similar implements. However, a slight play is necessary (Position B) when working with ploughs Harrows ditchers cultivators and the like ;...
  • Page 53 ▶The purpose of the 3-point hitch is to link the implements to the tractor and enable them to be lifted hydraulic. Once properly adjusted, it serves to link implements of category 2, and category 1 with the use of reducing bushes.
  • Page 54 Right hand console controls ▶Controller The electronic three point linkage hitch system consists of the operators control panel, the hitch hydraulic control valve, the Hitch position feed back sensor ,external hitch switches, and self check system. In position control the hitch moves by rotating the position control knob.
  • Page 55 Raise control Raise control improves the tractor ride quality when turning with fully mounted hitch implements. It raises the implement automatically when turning or reversing the tractor with specified control knob. 1) Turning control mode switch Th hit h The hitch system will automatically raise ti ll th i the implement when the tractor is...
  • Page 56 Self check system This system is used to check each electronic function individually. Operating the tractor with check system. Sit on the driver’s seat Apply the hand(foot)brake Put the main and sub shift lever in neutral Insert the ignition key and turn in ON position Switch to OFF all the switches in controller Push the external switch ON.
  • Page 57 SELF CHECK FUNCTION AND OPERATION 1) Raise SOL 1-1) Put the self check dial to raise SOL position. 1-2) Insert the ignition key and turn in ON position 1 3) If 1-3) If beeps Control with upper limit knob till it doesn’t sound beeps, Control with upper limit knob till it doesn t sound.
  • Page 58 4) Turn control switch 4-1) Put the self check dial to turn control position. 4-2) Insert the ignition key and turn in ON position. 4-3) Control with Position control knob till the beep sound doesn’t sound. 4-4) Push the turn control switch in ON position. 4-5) Turn the steering wheel to right hand side.
  • Page 59 6) Lift arm sensor 6-1) Put the self check dial to lift arm sensor. 6-2) Insert the ignition key and turn in ON position. 6-3) Control with Position control knob till the beep sound doesn’t sound. 6-4) Push the external hitch switch in ON position. 6-5) Raise the Hitch(Implement) to maximum height.
  • Page 60 DRIVING THE TRACTOR STARTING THE ENGINE Before starting the engine carry out the pre-operational checks as set out on page (1) Sit on the driver seat (2) Apply the footbrake. (3) Put the hydraulic lever in the down position. (4) Push down the clutch to activate the safety-starting switch. (5) Put the main gear lever in neutral (6) Insert the ignition key and turn it on (7) Ensure that the warning lights are working...
  • Page 61 STOPPING THE ENGINE -After light work let the engine idle for a while and turn the key off. After long or heavy work allow the engine to idle for 5- 10 minutes and turn the key off. important important WARMING UP When starting the engine allow it to warm up to operating temperature by allowing it to idle 5-10 minutes to ensure full lubrication and operating temperature.
  • Page 62 Do not ”ride” the clutch to control speed, use a lower gear. Do not travel with your foot on the clutch pedal. Caution Always connect the brake pedals when traveling on the road. Never tow anything except with the drawbar. Do not tow loads which are too large for the tractor’s capacity to brake effectively especially in hilly terrain.
  • Page 63 UPHILL STARTS ON A STEEP SLOPE With the pedals connected together push down on the brake pedals and push down the clutch. Set all gear levers to low and the throttle to medium engine speed. Release the clutch and as it engages release the brake pedals. Adjust the throttle to the required speed.
  • Page 64 ▶Fuel gauge. To avoid excessive condensation in the fuel tank refill at the end of each day’s work and ensure during the day that it does not drop to a low level where the fuel system will require bleeding to expel air in the system after refilling the tank.
  • Page 65 ▶ Track adjustment As some models are front wheel assist the front track can be set in 6 positions. The rear track can be set in 3 positions as illustrated (Tightening Torque) (Tightening Torque) Unit : mm(in)

  • Page 67: Section B

    Section-B Lubrication & Maintenance This section gives full details of the service procedures necessary to maintain your Tractor at peak efficiency while the lubrication and maintenance chart provides a ready reference to these requirements.
  • Page 68 CHECKS AND SERVICE PRE-START CHECKS To avoid problems it is recommended that a range of checks be carried out daily before starting the tractor. For full details of the items and frequency please refer to the tables on page 60,61 and ▶Engine coolant Remove the radiator cap and ensure that the coolant is up to the filler neck and that it is...
  • Page 69 ▶ Fuel Use the fuel gauge to check the fuel level and top up if too low. It is a good practice to refill the tank immediately after use to avoid condensation ▶ Tire pressure The air pressure used in the tires has a direct bearing on the life of the tire and its performance in the field.
  • Page 70 ▶ FRONT WHEEL DRIVE ▶Changing the front axle oil Drain the oil from the left and right drain plugs. Replace and check the drain plugs. Fill with new oil to the correct level in the filler hole Fill with new oil to the correct level in the filler hole [qty 16.5ℓ...
  • Page 71 MAINTENANCE AND ADJUSTMENT SCHEDULE Periodical check and service table ○ Check, Top-up or adjust ● Replace △ Clean or wash ★ Consult the service Dealer Item Service interval(hour meter,mark) Frequency Comment Engine Change every To correct level on ○ ● ● ●...
  • Page 72 Item Service interval(hour meter,mark) Frequency Comment Trans Change every ○ ● ● ● ● 300 hours after mission first 50 hours Free play Check daily (1.18~1.57 in) ○ of clutch pedal Free play ○ Check daily (1.18-1.57 in) of brake of brake pedal State of...
  • Page 73 300 hours after first 50 hours Check the Check every Without loose or ○ ○ electric electric year broken terminals. wiring Without damaged or missing wiring. Correctly clamped DIVISION SIZE Air pressure (Kgf/ MODEL ㎠) Tire Front 11.2~24 T700 Rear 16.9~30...
  • Page 74 FILLING DIAGRAM & CAPACITY TABLE Filling point Fillings Quantity Liter (gal.) MODEL T700 -50/50 : Ethylene Glycol/Water RADIATOR 9ℓ(2.38 US gal) (L.L.C) -ASTM D4985 / D6210 ENGINE API : CD/CE grades 8.5 ℓ Above:25°C(77°F)…SAE30 or 10W- (2.24 us gal) 0°C to 25°C(32°F to 77°F)…SAE20 or 10W30 Below 0°C(32°F)…SAE 10W or...
  • Page 75 Recommended Transmission oil ① RPM Tractor Hydraulic Fluid or Textron TDH Premium (CALTEX) ② TDH Oil or TDH Oil special (TEXACO) ③ Chevron 1000THF (CHEVRON) Opening method of each cover Opening method of each cover ▶ Opening method of Hood With the hood up,the hard nose can be removed by pulling downward,having first detached the hood lamp wiring harness.
  • Page 76 BLEEDING THE FUEL SYSTEM The fuel system needs to be bled whenever the tractor has been run out of the fuel or when the filters pipes or other components have been changed 1. Fuel System 2. Bleed Air System 1.Open the fuel cocks 2.Loosen Air bleed screws.
  • Page 77 CHANGING THE OILS IN THE TRACTOR Always use quality oils as engine or transmission oil (refer to the page 61) Refer to the table on page 60,61 and 62 for the change frequency. ▶ Changing engine oil. Park tractor on level surface, shut-off engine Remove sump plug &...
  • Page 78 ▶Changing Oil in the Front axle 1. Drain the oil from the center diff plug and the drain plug in each drive. 2. Replace and tighten all drain plugs. 3.Remove the top plug(Vent plug)from each final drive to vent air from final drives. 4.
  • Page 79 ■ FUEL FILTER (B) This is the secondary filter .Remove the fuel filter with a filter wrench Replace and tighten Never use petrol (gasoline) thinner or similar inflammable material to wash the primary fuel filter. After replacing the filter always bleed the system (see page 71) important ▶...
  • Page 80 Do not remove the radiator cap on a hot engine. Allow the engine to cool down and then turn the cap slowly to ensure, that there is no excessive pressure in the radiator. Caution Serious burns, can result from the contents of pressurized, hot radiators. Allow the engine to cool down completely before opening radiator cap.
  • Page 81 GREASING THE TRACTOR Grease the tractor according to the service schedule (page 61) Ensure that grease nipples are cleaned well before any attempt is made to grease them. Grease nipple Grease nipple Grease nipple Grease nipple GAP ADJUSTMENT ON THE FRONT AXLE Lift the front with a hydraulic jack to get the wheels of the ground.
  • Page 82 GAP ADJUSTMENT ADJUSTING THE CLUTCH Using the clutch over a period of time will increase the free play. The correct free play of the pedal is 1.18~1.57 in(30-40mm) To adjust, loosen the locknut on the turnbuckle and adjust. Check the adjustment and tighten the locknut if the free play is correct.
  • Page 83 ADJUSTING THE THROTTLE LEVER If this lever is either loose or difficult to move please consult your dealer for rectification of the problem. ADJUSTING TOE-IN If the toe-in adjustment is incorrect it can cause severe shaking of both the steering wheel and the entire tractor.
  • Page 84 ▶BATTERY CHARGING -A boost charge is only for emergencies.It will partially charge the battery at a high rate and in a short time. -When using a boost-charged battery,It is necessary to recharge the battery as early as possible. Failure to do this will shorten the battery’s service life. Always disconnect the negative terminal first when removing the battery and always connect the positive terminal first when fitting the battery.
  • Page 85 SERVICING THE AIR CLEANER To remove the dust from the evacuator valve squeeze it between thumb and fingers to let excess dust out and wipe around the valve to keep it clean from outside. To clean the main element, remove the right engine cover.
  • Page 86 Incorrect wiring or fuses can cause fires to both the tractor and surrounding area so get the dealer to check it annually. Likewise fuel pipes and wiring age with use. important Ask your dealer to check it at least once every 2 years and replace as required ▶...
  • Page 87 3. MAINTENANCE For daily or short term storage Clean the tractor and remove all dirt from field work. Fill the fuel tank to avoid condensation and rust. Lower the implement to the ground.. Keep it in a machinery shed or, if not available cover the unit if left outside. In very cold conditions it is advisable to remove the battery and keep it inside in a warm environment.

  • Page 89: Section C

    Section - C CABIN The cab fully conforms to the international standard as far as safety and soundproofing are concerned. It can be provided with ventilation, heating and air-conditioning system. It is available in the following version.: ● Cab with ventilation and heating systems ●...
  • Page 90 Remember that steering, braking and operational performances are highly influenced by the implements mounted, the trailers transported and the ballasts applied to the tractor. When transporting heavy loads (exceeding the weight of the tractor) reduce the speed under 15 Km/h.. All the implements mounted onto the tractor must be safely secured.
  • Page 91 Working lamps (front and rear) : the working lamps are located on the cab roof (two in the front and two in the rear) .They are switched on by means of the special switches on the roof console Rearview mirrors.: the cab is provided with rearview mirrors on both sides.
  • Page 92 How to operate Control panel. 1,2.Working lamp switch 3.Temperature control 4.Blower control 5.Interior lamp 6.Air conditioner switch 7.Wiper switch(front) 8.Wiper switch(Rear) 9.Air Blower hole VENTILATION The ventilation unit is housed in the cab ceiling. To switch it on and adjust it, turn the electrical fan switch to the desired speed. The cab becomes slightly pressurized when the ventilation system is in operation, so that the fresh air can enter only by way of the filter installed in the rear section of the cab roof.
  • Page 93 1,2) Working lamp Switch The front and rear work lights are ON when push the button .The work light indicator lamp on the instrument cluster will illuminate. 3) Temperature control 3) Temperature control Set temperature control as required,fully clockwise For maximum cool and fully counterclockwise for heat 4) Blower control switch Three position rocker switch 5) Air conditioning switch...
  • Page 94 Heating system General description The heater is switched on and adjusted by rotating the control knob at the roof console, then switching on the blower and setting the selector at the preferred speed . To warn the cab up quickly, the knob should be rotated fully clockwise and the blower set to speed 3. The screen is demisted or defrosted by air directed through a slot vent .
  • Page 95 SYSTEM CONFIGULATION 1.The heating system consist of two units: 1-Electric heater and blower unit installed behind roof console. 2-Power supplying set, consisting of an auxiliary alternator located front of the engine and driven by a belt directly linked to the engine pulley. If the air does not come out from the diffusers right away as soon as the system is started, turn off immediately and identify the fault.
  • Page 96 Air conditioner system The system is designed to ensure optimum temperature inside the cab and maximum comfort and safety for the operator. However, it is advisable to consult our specialized workshops whenever repairs or adjustments need to be performed. Do not approach the system with open flames, as any escape from the circuit may produce a lethal gas. h th l th l 1.Condenser...
  • Page 97 Circulation diffuses With the circulation vent set in any position outside Air will still be pulled into the cab. Cab Air intake filter The《Paper》 filter is not suitable for the treatment of pesticides and so must be replaced by an《ACTIVE CARBON》FILTER available optionally.Once the pesticide treatment is finished it is necessary to once pesticide treatment is finished, it is necessary to once...
  • Page 98 Radio cassette( If equipped) For operation refer to the radio manufacturers instructions. Ash tray Located at left side of near side window in cabin t d t l ft id Cigar light jack Refrigerator For operation Refer to the refrigerator Manufactures Instruction.
  • Page 99 1.SAFETY PROCEDURES. This safety alert symbol indicates important safety messages in this manual. when you see this symbol, carefully read the message that follows and be alert to the possibility of personal injury or death Warning Refrigerant R134a is the most stable and easiest to 3.Keep refrigerant containers in the correct work with refrigerants now in use in air conditioner upright position.
  • Page 100 2. OPERATION The air conditioner system contains five major components: Compressor, receiver drier, expansion valve and evaporator. These components are connected by tubes and hoses and operate as a closed system. The air conditioner system is charged with R-134a refrigerant.. The compressor receives the refrigerant as a low pressure gas.
  • Page 101 3. Checking the air conditioning system. ①Economic friendly refrigerant : R134a 0.75∼0.8 Kg. (Lubricant:265ml) The presence of air and water in the system could jeopardize its efficiency. -The air is uselessly compressed by the compressor and no cooling effect is produced. -The moisture has a tendency rise to obstructions which prevent the cooling efficiency.

  • Page 103: Section D

    The specifications on the following pages are given for your information and guidance. For further information concerning your Tractor and equipment, consult your Authorized Dealer/ Distributor. TYM CO.,LTD policy is one of continuous improvement and the right to change prices, specifications or equipment at any time without notice is reserved.
  • Page 104 SPECIFICATIONS Model: T700 ENGINE CLUTCH : Diaphragm Four strokes, Direct injection, water-cooled Type Outer dia. X Inner dia. : 275X180(10.83X7.09) Diesel Engine. Model :CD3029TF270E TRANSMISSION No. of cylinders Type : synchro mesh Displacement :2,911 Liters No. of gears :16 forward, Bore :106.5mm(4.19”)
  • Page 105 ▶ MAIN SPECIFICATIONS T700 MODEL John Deere Engine Maker CD3029T Model Water cooled 4 cycle 3 cylinder diesel turbo Water cooled 4 cycle 3 cylinder diesel turbo Type Type charged 72/2,500 Out put(ps/rpm) Number of Cylinder 2,911 Displacement(cc) 106X110 mm...
  • Page 106 MODEL T700 Clutch Main Dry single disc,mechanic Multiple wet disk Dimension Overall length(mm) 4,030(158.66”) Overall width (mm) 1,959(77.12”) Overall Height (mm) 2,600102.36”) Wheel base (mm) 2,114(83.23”) (Distance between shafts) Min. Ground Clearance (mm) 340 (16.5”) Tire size Tire size Front Front 11.2-24...
  • Page 107 Traveling speeds:Km/h (Mile/h) Traveling Speed (mile/hour) MODEL T700 Range shift Main shift Forward Reverse 0.86(0.53) 0.81 (0.53 ) 1.08 (0.67 ) 1.02 (0.63 ) 1.46 (0.91 ) 1.38 (0.86 ) 1.92 (1.19 ) 1.81 (1.13 ) 2.21 (1.37 ) 2.09 (1.30 ) 2.78 (1.73 )

  • Page 108: Fuel Saving Tips 104~10

    FUEL SAVING TIPS To save fuel & oil in your tractor, following things should always be kept in mind. A) Air cleaning system 1) Clean the air cleaner regularly so that dust does not settle down. 2) F 2) For every 100 hours & everyday in sandy/dusty conditions. 100 h &...
  • Page 109 E) Engine system 1) Always use recommended grade of oil. 2) Everyday before starting the engine, check the oil level with a dipstick & refill between the minimum & maximum level. 3) Charge the engine oil, Replace filter & “O” ring, as & when required. F) Cooling system 1) Check the fan belt tension regularly.

  • Page 110: Fault Tracing

    FAULT TRACING SYMPTOM CAUSE REMEDY Turning the main switch Clutch not pushed in Push the clutch in will not operate the starter Battery flat Charge or replace the battery Dealer to repair or replace Dealer to repair or replace Switch faulty Contact dealer for repair or replace Starter operates but not...
  • Page 111 SYMPTOM CAUSE REMEDY White smoking from the Oil level too high Reduce to correct quantity exhaust Shortage of or faulty fuel Contact dealer for repair Reduced performance of The injectors are clogged, Contact dealer for repair the engine carbon coated and sticking Low compression Leaking valve seat Contact dealer for repair...
  • Page 112 SYMPTOM CAUSE REMEDY The clutch slips Incorrect adjustment Adjust to correct free play Worm or burnt lining Contact dealer for repair The clutch does not Incorrect adjustment Adjust to correct free play Contact disengage Rusty clutch lining l t h li i d l f dealer for repair Brake not working...
  • Page 113 SYMPTOM CAUSE REMEDY Steering wheel shaking Wrong toe-in Adjust toe-in Unequal tire pressure Inflate both to correct pressure Loose component Tighten or replace if worn Excessive play in the i th Worn steering shaft h ft C t t d l f Contact dealer for repair steering Worn components...
  • Page 115 T700 WIRING DIAGRAM 3...
  • Page 116 CABIN WIRING DIAGRAM 1...
  • Page 117 CABIN WIRING DIAGRAM 2...
  • Page 118 ▶Drawing for fixing position of the fuse ▶Wiring diagram of the electric instrument Head lamp 12V H4 35/35W Turn signal lamp 12V21W Stop lamp back 21/8W light Meta panel light 12V3.4W Working lamp 3H 12V35W Turn signal lamp 12V21W Side lamp 21V8W Rear lamp 12V21W...
  • Page 119 ◎ t700 POWER TRAIN...

  • Page 120: Tractor History Card 111~11

    TRACTOR HISTORY CARD DATE NATURE OF PARTS REPLACEMENT W/CLAIM NO. REMARK CARD NO. DEFECT AND DATE...

  • Page 121: Service Record

    SERVICE RECORD DATE TRACTOR HOURS NATURE/TYPE OF REPAIR/SERVICE CARRIED OUT...

  • Page 122: Daily Operating Log

    DAILY OPERATION LOG DATE MACHINE HOURS FUEL ENGINE DONE CONSUMPTION REMARKS START TOPPED UP...

  • Page 123: Part Replacement Record

    PART REPLACEMENT RECORD DATE PART COST DATE PART COST DESCRIPTION DESCRIPTION...
  • Page 124 T700 Operator’s Manual for Tractors Code No. 1769-912-001-0 Printed on Feb 2008 Printed on Feb. 2008 1st EDITION...

Table of Contents
