Battery and charging

Charging
• Slide the battery (H) into the battery slot until it locks.
• Connect the charger (I) to the charging port (9).
• Connect the charger (I) to the socket outlet.
• The battery status indicator (12) shows the charging status:
Battery status indicator
1 LED flashing
2 LEDs on/flashing
3 LEDs on/flashing
All LEDs off
• When the battery (H) is fully charged, disconnect the charger (I) from the charging
port (9) and then from the socket outlet.
While charging, the product cannot be switched on.
NOTICE
Installing/removing the battery
• To remove: Push both battery release buttons (10) and pull out the battery (H)
backwards.
• To install: Slide the battery (H) into battery slot until it locks.
1
Status
Charging
Charging
Charging
Charging finished
2
3
Charging level
Low
Medium
High
Fully charged
11
