- Page 1 Operation & Service Manual 5/01 5 SAD Series Nutrunners NORTH AMERICA EUROPE CooperTools Cooper Power Tools GmbH & Co. P.O. Box 1410 Postfach 30 Lexington, SC 29071 D-73461 Westhausen...
- Page 2 OPERATION - CLECOMATIC Models GEAR TRAIN DISASSEMBLY — -174 Gear Train No. 5 Series CLECOMATIC CCW screwdrivers are designed for the When pressing the spider assembly out of the rear of the gear case clutch to shut-off in reverse. Accurate torque is achieved by setting the 869162, be sure the idler gears 869163, are in line with the pockets CLECOMATIC clutch to the desired torque.
- Page 3 5 CLECOMATIC CLUTCH 869423 203584 203993 203580 Blue 863455 863455 203579 Green 869140 847104 203575 White 869123 203578 Yellow 203571 203589 842161 203573 617226 869112 869424 203585 204597 203612 203613 869149 203574 842980 PARTS LIST — 5 CLECOMATIC CLUTCH Qty. Part No.
-
Page 4: Gear Train
2, 7 & 10, GEAR TRAINS & 104 1ST REDUCTION GEAR TRAIN 2 GEAR TRAIN 833859 833859 833859 203920 203920 203920 619017 203917 203917 203917 203924 201550 201550 203644 847595 203976 203919 7 GEAR TRAIN 833859 833859 203920 203925 619017 203917 203917 203924... -
Page 5: Name Of Part
17 & 25 GEAR TRAINS & 174, 254 1ST REDUCTION GEAR TRAINS 17 GEAR TRAIN & 174 1ST REDUCTION GEAR TRAIN 869162 869155 619017 833862 847595 869163 203646 PARTS LIST — 7, 174 GEAR TRAIN PART NO. NAME OF PART QTY. - Page 6 5 MOTORS Rev. 847548 203546 -2, -10, -104 Non-Rev. 863036 203545 -7, -25, -254 203547 -17, -174 203506 203615 844897 842768 842768 203506 All Others 203586 203641 203504 203721 Button Rev. PARTS LIST — 5 MOTORS Part No. Name of Part Qty.
- Page 7 5 CLECOMATIC HANDLE 865777 204578 203519 203532 847710 203520 204407 203518 203523 203522 203525 863598 203530 844308 203521 203529 203524 PARTS LIST — 5 CLECOMATIC HANDLE Part No. Name of Part Qty. Part No. Qty. Name of Part 203518 Inlet Bushing (incl. 863598) 203532 Motor Spacer 203519...
- Page 8 CooperTools 670 Industrial Drive Lexington, SC 29072 Phone: (803) 359-1200 Fax: (803) 359-2013 www.cooperindustries.com...
