SAFETY INFORMATION SAFETY WARNINGS TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER (OR BACK). NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This symbol indicates that high voltage is present inside. It is dangerous to make any CAUTION kind of contact with any internal part of this product.
Page 3
PRECAUTIONS 1. Ensure that the AC power supply in your house complies with the power requirements listed on the identification sticker located on the back of your product. Install your product horizontally, on a suitable base (furniture), with enough space around it for ventilation (7~10 cm). Make sure the ventilation slots are not covered. Do not place the unit on amplifiers or other equipment which may become hot.
CHECKING THE COMPONENTS Soundbar Main Unit 3 AC/DC Adapter 4 Power Cord Right Side of the Soundbar Remote Control / Battery Subwoofer Optical Cable 1 AC/DC Adapter Micro USB to USB adapter Cable 2 Power Cord CONNECTING ELECTRICAL POWER Use the power components (1, 2, 3, 4) to connect the power supplies in the following order: Subwoofer ...
Page 5
CONNECTING THE SUBWOOFER TO THE SOUNDBAR MAIN UNIT You can enjoy rich bass tones and better sound quality by linking the subwoofer to the Soundbar main unit. Soundbar Main Unit Subwoofer The Soundbar main unit and subwoofer should link (connect wirelessly) automatically when the Soundbar main unit and subwoofer are turned on.
Page 6
If the connection process fails, the blue indicator will flash continuously. Go to Step 2 and start again. Expand to true wireless surround sound by connecting the Samsung Wireless Rear Speaker Kit (SWA-8000S) to your Soundbar. (Sold separately) c For further information, refer to the Web Manual.
CONNECTING TO YOUR TV You can enjoy TV sound after connecting the Soundbar to your TV with or without a cable. c Important: Before you begin, put the battery into the remote. See page 14 for instructions. Method 1. Connecting with a Cable Check the DIGITAL AUDIO IN (OPTICAL) port of the Soundbar main unit.
Page 8
TV on or off by setting the Bluetooth POWER On function to On. See page 15. c The TV SoundConnect (Soundshare) function is only available in some Samsung TV products released since 2012. c If you want to disconnect the existing connection to your TV and establish a new connection to another TV, press the &...
4. Play music on the connected device. [If failed to connect to the Bluetooth device / If device searching is needed again] • Delete the previous "[AV] Samsung Soundbar Kxxx K-Series" found by the Bluetooth device and have it search for the Soundbar again.
CONNECTING TO AN EXTERNAL DEVICE Optical Cable You can enjoy sound from separate external devices such as a BD player/game console/set-top box, etc. by connecting them to your Soundbar. Soundbar DIGITAL AUDIO IN (OPTICAL) Optical Cable Bottom of Soundbar External Device OPTICAL OUT 1.
USB port on your Soundbar. For more information about how to download update files, go to the Samsung Electronics website at (samsung.com/sec) search for the model name download the firmware from the customer support menu option.
Page 12
c If the markings do not correspond to the 1. Place the Wall Mount Guide against the wall surface. positions of studs, make sure you insert appropriate anchors or mollies into the holes The Wall Mount Guide must be level. ●...
When assembling, make sure the hanger part ● of the Bracket-Wall Mounts faces backwards. Rear Side of Soundbar Right end of Soundbar The left and right mounts are different shapes. ● Make sure to position them correctly. D ETACHING THE SOUNDBAR Wall Mount R Wall Mount L FROM THE WALL...
Page 14
REMOTE CONTROL BUTTONS & FEATURES Inserting Battery before using the Remote Control 1. Use a suitable coin to turn the remote control's battery cover counterclockwise to remove it as shown in the figure below. 2. Insert a 3V lithium battery. Keep the positive (+) pole facing up when inserting the battery.
Page 15
Sets the volume temporarily to 0. Press again to cancel. Mute Adjusts the volume level of the unit. Volume Press the & button to pause a music temporarily. Press the & button again to play the selected music. Play / Pause Selects the next file.
• Nominal specification – Design and specifications are subject to change without prior notice. – Samsung Electronics Co., Ltd reserves the right to change the specifications without notice. – Weight and dimensions are approximate. – For more information about the power supply and power consumption, refer to the label attached to the product.
INFORMAÇÕES DE SEGURANÇA COMPONENTES INCLUÍDOSAVISOS DE SEGURANÇA PARA REDUZIR O RISCO DE CHOQUES ELÉCTRICOS, NÃO RETIRE A TAMPA POSTERIOR. O INTERIOR NÃO CONTÉM PEÇAS PASSÍVEIS DE REPARAÇÃO PELO UTILIZADOR. A MANUTENÇÃO DEVE SER EFECTUADA POR PESSOAL TÉCNICO QUALIFICADO. Este símbolo indica a presença de alta tensão no interior.
Page 19
PRECAUÇÕES 1. Certifique-se de que a fonte de alimentação de CA em sua casa está em conformidade com o indicado no autocolante de identificação, situado na parte de trás do produto. Instale o produto na horizontal, sobre uma base adequada (móvel), com espaço suficiente para permitir a ventilação 7~10 cm. Certifique-se de que os orifícios de ventilação não estão tapados.
VERIFICAÇÃO DOS COMPONENTES Unidade Principal do Soundbar Superior 3 Transformador de CA/CC 4 Cabo de alimentação Lado direito do Soundbar Controlo remoto / Pilha Subwoofer Cabo ótico 1 Transformador de CA/CC Cabo adaptador micro USB para USB 2 Cabo de alimentação LIGAÇÃO À...
Page 21
LIGAÇÃO DO SUBWOOFER À UNIDADE PRINCIPAL DO SOUNDBAR Pode desfrutar de sons graves ricos e de uma melhor qualidade de som, ligando o subwoofer à unidade principal do Soundbar. Unidade Principal do Soundbar Subwoofer A unidade principal e o subwoofer do Soundbar devem ligar-se (sem fios) automaticamente assim que estiverem a funcionar.
Page 22
Indicador de Ligação 1. Ligue os cabos de alimentação da unidade principal e do subwoofer do Soundbar a uma tomada de parede de CA. 2. Prima o botão ID SET no painel posterior do subwoofer com um objecto pontiagudo durante 5 segundos. c O indicador LINK (LED azul) no subwoofer fica intermitente rápido.
LIGAR AO TELEVISOR Pode desfrutar do som do televisor depois de ligar o Soundbar ao seu televisor com/sem cabo. c Importante: antes de começar, coloque a pilha no controlo remoto. Consulte a página 14 para obter instruções. Método 1. Ligar com cabo Verifique a porta DIGITAL AUDIO IN (OPTICAL) Verifique a porta na unidade principal do Soundbar.
Page 24
Método 2. TV SoundConnect (Ligação a um televisor Samsung por Bluetooth) 1. Ligue o televisor Samsung e o Soundbar. 2. Selecione o modo TV no ecrã do Soundbar premindo o botão no lado direito do Soundbar ou o botão SOURCE no controlo remoto. (Os modos são apresentados na seguinte ordem: D.IN → AUX → BT → TV →...
Page 25
4. Reproduza música no dispositivo ligado. [Caso a ligação ao dispositivo Bluetooth falhe/Se for necessário pesquisar o dispositivo novamente] • Elimine o “[AV] Samsung Soundbar Kxxx K-Series” anterior encontrado pelo dispositivo Bluetooth e use-o para pesquisar novamente pelo Soundbar. c Se for solicitado um código PIN ao ligar ao dispositivo Bluetooth, introduza <0000>.
Page 26
LIGAR A UM DISPOSITIVO EXTERNO Cabo ótico Pode desfrutar de som de outros dispositivos externos, como um leitor de BD/uma consola de jogos/um descodificador, etc., ligando-os ao Soundbar. Soundbar DIGITAL AUDIO IN (OPTICAL) Cabo ótico Base do Soundbar Dispositivos OPTICAL OUT Digitais 1.
à porta USB do Soundbar. Para mais informações sobre como transferir os ficheiros de atualização, vá ao website da Samsung Electronics (samsung.com/sec) procure o nome do modelo transfira o firmware a partir da opção de menu de apoio Parafuso de ao cliente.
Page 28
c Se a parede não tiver qualquer suporte adicional 1. Coloque o Guia de suporte de parede encostado à superfície da parede. no local das marcas, certifique-se de que insere as buchas e os parafusos Molly nos orifícios, O Guia de suporte de parede deve ficar ●...
Page 29
Ao montar, certifique-se de que a secção de ● suspensão do Suporte de parede fica virada para trás. Parte traseira do Soundbar Extremidade direita do Soundbar Os suportes esquerdo e direito têm formas ● diferentes. Certifique-se de que os posiciona corretamente.
Page 30
BOTÕES E FUNCIONALIDADES DO CONTROLO REMOTO Inserção da pilha antes de utilizar o controlo remoto 1. Utilize uma moeda com um tamanho adequado para rodar a tampa da pilha do controlo remoto no sentido contrário ao dos ponteiros do relógio para a remover, como se mostra na figura em baixo. 2.
Page 31
Define o volume temporariamente como 0. Prima novamente para cancelar. Silenciar Ajusta o nível de volume da unidade. Volume Prima o botão & para por temporariamente uma música em pausa. Prima novamente o botão & para reproduzir a música selecionada. Reproduzir / Pausa Seleciona o ficheiro seguinte.
Page 32
È Actualize o televisor com a versão mais recente de firmware. Ocorre um erro ao ligar? È Contacte o centro de contacto da Samsung. È Reinicie o TV SoundConnect e ligue novamente. Para reiniciar a ligação do TV SoundConnect, mantenha o botão & premido durante 5 segundos.
Page 33
• Especificação nominal – A conceção e as especificações estão sujeitas a alteração sem aviso prévio. – A Samsung Electronics Co., Ltd reserva-se ao direito de alterar as especificações sem aviso prévio. – O peso e as dimensões indicados são aproximados.
